An exploded drawing and listing for the Bosch PWS 1000-125 / 3603CA2630 / CH 230 Volt
Ex VAT Inc VAT
1 - HOUSING BSD-2609006792.A4 2609006792 £13.12 £15.75
2 - FIELD 220-240V BSD-1604220283.A29 1604220283 £27.31 £32.77
3 - ARMATURE 220-240V BSD-2609006965.A3 2609006965 £48.38 £58.06
4 - SWITCH BSD-1607200146.A45 1607200146 £10.10 £12.12
5 - POWER SUPPLY CORD CH 2.65m 2 x 0.75mm H05 VV-F BSD-1604460433.A16 1604460433 £11.30 £13.56
6 - GROMMET dia6.4-dia7.2x76 MM BSD-2609006376.A22 2609006376 £1.75 £2.10
7 - CABLE CLIP BSD-2601035001.A833 2601035001 £1.75 £2.10
9 - MANUFACTURER'S NAMEPLATE PWS 1000-125 BSD-2609006826.A5 2609006826 £2.61 £3.13
12 - SUPPRESSION FILTER BSD-2609007029.A2 2609007029 £6.52 £7.83
14 - GROOVE BALL BEARING BSD-2600905078.A34 2600905078 £6.52 £7.83
16 - BRUSH HOLDER BSD-1601323023.A4 1601323023 £3.72 £4.47
17 - SPIRAL SPRING BSD-1604652013.A763 1604652013 £1.75 £2.10
18 - COMPRESSION SPRING BSD-2609007523.A4 2609007523 £1.75 £2.10
19 - SCREW 4x16 BSD-2603490022.A1110 2603490022 £1.75 £2.10
22 - LEVER BSD-2609006794.A4 2609006794 £1.75 £2.10
23 - SWITCH BUTTON BSD-1600A007UL.A12 1600A007UL £1.75 £2.10
25 - HOUSING COVER BSD-2609006793.A1 2609006793 £10.10 £12.12
26 - RUBBER RING BSD-1600206036.A85 1600206036 £1.75 £2.10
27 - RUBBER RING BSD-1600206025.A808 1600206025 £2.16 £2.59
29 - AIR-DEFLECTOR RING BSD-2609006367.A12 2609006367 £1.75 £2.10
30 - BAFFLE BSD-2609006366.A3 2609006366 £2.16 £2.59
31 - LEAF SPRING BSD-2609002205.A34 2609002205 £5.30 £6.36
35 - SHIM 0.1 MM BSD-2609002208.A4 2609002208 £1.75 £2.10
35 - SHIM 0.2 MM BSD-2609002209.A44 2609002209 £1.75 £2.10
35 - SHIM 0.3 MM BSD-2609002210.A4 2609002210 £2.16 £2.59
35 - SHIM 1.5 MM BSD-1600A00RE3.A31 1600A00RE3 £1.75 £2.10
36 - VIBRATION DAMPER BSD-2609007464.A3 2609007464 £1.75 £2.10
39 - BEVEL GEAR BSD-2609006725.A11 2609006725 £6.52 £7.83
40 - RETAINING CLIP BSD-1600119011.A451 1600119011 £2.16 £2.59
45 - HEX NUT M7. SW10 BSD-1603300016.A294 1603300016 £1.75 £2.10
48 - TORX OVAL-HEAD SCREW 3x10 BSD-2603490017.A944 2603490017 £2.16 £2.59
49 - THREAD-FORMING TAP. SCREW M4x16 BSD-2914491410.A242 2914491410 £1.75 £2.10
52 - CONNECTING CABLE BSD-2609006788.A1 2609006788 £1.75 £2.10
55 - TORX OVAL-HEAD SCREW 4x20 BSD-2609001403.A6 2609001403 £1.75 £2.10
56 - COVERING HOOD BSD-2609006795.A0 2609006795 £1.75 £2.10
200 - PROTECTIVE COVER dia125 MM BSD-2609002204.A5 2609002204 £16.41 £19.69
680 - HANDLE BSD-2609002198.A0 2609002198 £10.10 £12.12
681 - ROUND NUT M14 BSD-1603345043.A1025 1603345043 £8.67 £10.41
682 - CLAMPING FLANGE dia22.3xdia42 MM BSD-2605703014.A1314 2605703014 £7.36 £8.83
683 - PIN-TYPE FACE-WRENCH BSD-1619P08927.A71 1619P08927 £4.26 £5.11
808 - NAMEPLATE BSD-2609006830.A0 2609006830 £2.61 £3.13
810 - CARBON-BRUSH SET BSD-1607014176.A265 1607014176 £13.12 £15.75
821 - GEAR HOUSING BSD-2609007332.A11 2609007332 £27.23 £32.68
828 - BEARING FLANGE BSD-2609007333.A0 2609007333 £27.23 £32.68
