1 - MOTOR HOUSING
BSD-1605108127.A69
1605108127
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-1604220224.A42
1604220224
|
-
|
|
|
|
3/60 - FAN
BSD-1606610121.A249
1606610121
|
£1.75
|
£2.10
|
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A375
1607200086
|
£11.30
|
£13.56
|
|
|
4/10 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A321
2910110048
|
£1.75
|
£2.10
|
|
|
5 - POWER SUPPLY CORD I/BR 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460277.A3
2604460277
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1008
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A351
2600703013
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A431
1601302017
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-1601110256.A3
1601110256
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328029.A14
1607328029
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A144
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A182
1600905032
|
£5.58
|
£6.70
|
|
|
18 - COMPRESSION SPRING
BSD-1604611026.A441
1604611026
|
£1.75
|
£2.10
|
|
|
21 - GEAR HOUSING
BSD-1605806411.A7
1605806411
|
£21.68
|
£26.01
|
|
|
22 - ADJUSTING SLIDE
BSD-1602319002.A147
1602319002
|
£2.61
|
£3.13
|
|
|
23 - SWITCH HANDLE
BSD-1602026057.A286
1602026057
|
£1.97
|
£2.36
|
|
|
25 - HOUSING COVER
BSD-1600508005.A81
1600508005
|
£3.80
|
£4.56
|
|
|
26 - RUBBER BUSHING
BSD-1600502020.A208
1600502020
|
£2.61
|
£3.13
|
|
|
27 - RUBBER RING
BSD-1600206025.A415
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1601328005.A234
1601328005
|
£2.61
|
£3.13
|
|
|
31 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A241
2916660013
|
£2.16
|
£2.59
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A223
3600210124
|
£2.80
|
£3.36
|
|
|
35 - SHIM 0.2 MM
BSD-1600136010.A1
1600136010
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136011.A322
1600136011
|
£2.16
|
£2.59
|
|
|
35 - SHIM 0.1 MM
BSD-1600136012.A1
1600136012
|
£1.75
|
£2.10
|
|
|
36 - SPRING WASHER
BSD-1600150011.A117
1600150011
|
£1.75
|
£2.10
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A469
1600290016
|
£2.61
|
£3.13
|
|
|
38 - CROWN GEAR Z=36
BSD-1606333601.A73
1606333601
|
£8.49
|
£10.19
|
|
|
39 - SPIRAL SPRING
BSD-1604652013.A586
1604652013
|
£1.75
|
£2.10
|
|
|
40 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A119
2916660009
|
£2.16
|
£2.59
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A786
1600910018
|
£5.30
|
£6.36
|
|
|
42 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A108
1600905006
|
£12.04
|
£14.45
|
|
|
43 - BEVEL GEAR Z=11
BSD-1606333242.A72
1606333242
|
£48.38
|
£58.06
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A54
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A215
2910211018
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A69
2910211005
|
£1.75
|
£2.10
|
|
|
49 - THREAD-FORMING TAP. SCREW
BSD-1603435026.A1
1603435026
|
£2.16
|
£2.59
|
|
|
50 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A33
2912401420
|
£1.75
|
£2.10
|
|
|
53 - CONNECTING CABLE
BSD-1604448015.A21
1604448015
|
£1.75
|
£2.10
|
|
|
54 - CONNECTING CABLE
BSD-1604448016.A128
1604448016
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A32
2912401420
|
£1.75
|
£2.10
|
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A52
1607950052
|
£3.72
|
£4.47
|
|
|
650/50 - CLAMPING-FLANGE dia22.2x42 MM
BSD-1605703099.A349
1605703099
|
£7.45
|
£8.94
|
|
|
650/50/20 - O-RING 20.35x1.78 MM
BSD-1600210039.A491
1600210039
|
£2.16
|
£2.59
|
|
|
650/60 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A270
1907950006
|
£4.26
|
£5.11
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A263
2910022197
|
-
|
|
|
|
700/10/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A264
2910022197
|
-
|
|
|
|
700/20 - GUIDE BLOCK
BSD-1608135004.A0
1608135004
|
-
|
|
|
|
700/20/30 - ROUND-HEAD BOLT DIN 603-M 5x16
BSD-2910281158.A47
2910281158
|
-
|
|
|
|
700/20/40 - WING NUT M 5 DIN 315-G-5
BSD-2915191105.A8
2915191105
|
-
|
|
|
|
700/20/50 - COMPRESSION SPRING
BSD-1604643004.A9
1604643004
|
-
|
|
|
|
750/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A761
160202509T
|
£3.72
|
£4.47
|
|
|
750/20 - ROUND NUT M14
BSD-1603340015.A45
1603340015
|
£3.87
|
£4.64
|
|
|
752 - PROTECTIVE COVER dia 115 MM
BSD-1605510201.A2
1605510201
|
-
|
|
|
|
803 - ARMATURE WITH FAN 230-240V
BSD-1604010259.A61
1604010259
|
-
|
|
|
|
803 - ARMATURE WITH FAN 240V
BSD-1604010262.A3
1604010262
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014116.A128
1607014116
|
£11.30
|
£13.56
|
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A206
1600A003G4
|
£3.72
|
£4.47
|
|
|
828 - BEARING FLANGE
BSD-1607000936.A89
1607000936
|
£27.23
|
£32.68
|
|
|
832 - GRINDING SPINDLE
BSD-1607000D6A.A229
1607000D6A
|
£7.36
|
£8.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1326
160111A3H3
|
£2.61
|
£3.13
|
|
