1 - MOTOR HOUSING
BSD-2605104548.A14
2605104548
|
£30.28
|
£36.33
|
|
|
2 - FIELD 230-240V
BSD-2604220480.A50
2604220480
|
£21.68
|
£26.01
|
|
|
3/60 - FAN
BSD-2606610049.A165
2606610049
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-2607200084.A122
2607200084
|
£10.10
|
£12.12
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460417.A15
1604460417
|
£9.49
|
£11.39
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A555
2600703017
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2806
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE PBS 75A
BSD-2601118959.A2
2601118959
|
£1.32
|
£1.58
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A77
1607328028
|
£5.30
|
£6.36
|
|
|
13 - FLANGED BEARING
BSD-2605805008.A54
2605805008
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905011.A80
1610905011
|
£14.91
|
£17.89
|
|
|
16 - BRUSH HOLDER
BSD-2604449026.A57
2604449026
|
£1.75
|
£2.10
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2115
2603410001
|
£1.75
|
£2.10
|
|
|
20 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A261
2603490023
|
£1.75
|
£2.10
|
|
|
25 - INTERMEDIATE RING
BSD-1600502011.A464
1600502011
|
£2.61
|
£3.13
|
|
|
26 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A67
2600910001
|
£4.26
|
£5.11
|
|
|
28 - GROOVE BALL BEARING 8x22x7
BSD-1900905041.A66
1900905041
|
£13.12
|
£15.75
|
|
|
30 - SHIM
BSD-2600100099.A19
2600100099
|
£2.16
|
£2.59
|
|
|
31 - TOOTHED BELT WHEEL
BSD-2606625037.A2
2606625037
|
£2.61
|
£3.13
|
|
|
33 - TOOTHED BELT Z=75
BSD-2604736010.A12
2604736010
|
£11.30
|
£13.56
|
|
|
35 - INTERMEDIATE RING
BSD-1600206024.A14
1600206024
|
£1.75
|
£2.10
|
|
|
37 - COVERING HOOD
BSD-1605510150.A19
1605510150
|
£4.26
|
£5.11
|
|
|
40 - COMPRESSION SPRING
BSD-2604630002.A30
2604630002
|
£1.75
|
£2.10
|
|
|
41 - WING NUT
BSD-2603339005.A4
2603339005
|
£2.80
|
£3.36
|
|
|
44 - BASE
BSD-1608005003.A20
1608005003
|
-
|
|
|
|
45 - ROLLER
BSD-2606625900.A10
2606625900
|
£18.96
|
£22.75
|
|
|
46 - AXLE
BSD-1603521027.A27
1603521027
|
£10.10
|
£12.12
|
|
|
47 - BASE PLATE
BSD-2601098040.A25
2601098040
|
£7.36
|
£8.83
|
|
|
48 - SOCKET HEAD CAP SCREW DIN 84-M5x10-4.8
BSD-2603410045.A6
2603410045
|
£2.16
|
£2.59
|
|
|
49 - BRUSH-COVER
BSD-1605500122.A31
1605500122
|
£5.58
|
£6.70
|
|
|
50 - SOCKET HEAD CAP SCREW DIN 84-BM5x40-5.8
BSD-2910011170.A37
2910011170
|
£1.75
|
£2.10
|
|
|
51 - SINTERED-METAL BUSHING DIN 1850-J12x18x12
BSD-1900301018.A33
1900301018
|
-
|
|
|
|
52 - BEARING BRACKET
BSD-1605807013.A15
1605807013
|
£8.67
|
£10.41
|
|
|
53 - TENSIONING LEVER
BSD-1602098006.A10
1602098006
|
£2.71
|
£3.25
|
|
|
54 - COMPRESSION SPRING
BSD-1604619017.A79
1604619017
|
£2.16
|
£2.59
|
|
|
55 - BUTTON-HEAD RIVET
BSD-2917030110.A29
2917030110
|
£2.61
|
£3.13
|
|
|
56 - LOCKING WASHER
BSD-1600146001.A25
1600146001
|
£1.75
|
£2.10
|
|
|
60 - SOCKET HEAD CAP SCREW DIN 84-AM4x16-8.8
BSD-2910021126.A32
2910021126
|
£1.75
|
£2.10
|
|
|
61 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A153
2915011005
|
£1.75
|
£2.10
|
|
|
63 - SEAL RING
BSD-2600290033.A12
2600290033
|
£3.72
|
£4.47
|
|
|
64 - SHIM 0.3 MM
BSD-1600101618.A84
1600101618
|
£2.61
|
£3.13
|
|
|
66 - CERAMIC PLATE
BSD-1601010007.A10
1601010007
|
£2.61
|
£3.13
|
|
|
67 - HANDLE
BSD-1605133036.A50
1605133036
|
£7.36
|
£8.83
|
|
|
68 - CONNECTING CABLE L=410 MM
BSD-1604438018.A28
1604438018
|
£1.75
|
£2.10
|
|
|
69 - CONNECTING CABLE L=373 MM
BSD-1604448000.A48
1604448000
|
£2.16
|
£2.59
|
|
|
70 - HOUSING COVER
BSD-1605500120.A14
1605500120
|
£2.61
|
£3.13
|
|
|
71 - FAN
BSD-1606610120.A14
1606610120
|
£2.61
|
£3.13
|
|
|
72 - HEX NUT
BSD-2603300015.A17
2603300015
|
£1.75
|
£2.10
|
|
|
654 - DUST BAG
BSD-2605411170.A6
2605411170
|
£23.86
|
£28.63
|
|
|
655 - FITTING
BSD-2605702029.A6
2605702029
|
-
|
|
|
|
800 - HANDLE
BSD-1605133036.A51
1605133036
|
£7.36
|
£8.83
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A200
2604321905
|
£11.30
|
£13.56
|
|
|
819 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A81
2910611020
|
£1.75
|
£2.10
|
|
|
827 - CROWN GEAR Z=45
BSD-2606333900.A36
2606333900
|
£21.52
|
£25.83
|
|
|
830 - ARMATURE 230-240V
BSD-2604010935.A8
2604010935
|
£81.81
|
£98.17
|
|
|
831 - TOOTHED BELT WHEEL
BSD-2606625907.A20
2606625907
|
£2.80
|
£3.36
|
|
|
838 - HOUSING
BSD-2605190900.A32
2605190900
|
£48.38
|
£58.06
|
|
|
843 - ROLLER
BSD-2606625905.A8
2606625905
|
£23.86
|
£28.63
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3526
160111A3H3
|
£2.61
|
£3.13
|
|
