2 - FIELD 220-240V
BSD-2604220423.A3
2604220423
|
£24.45
|
£29.34
|
|
|
3 - ARMATURE 220-240V
BSD-2604010558.A50
2604010558
|
-
|
|
|
|
4 - SWITCH
BSD-2607200084.A27
2607200084
|
£10.10
|
£12.12
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A13
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1386
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110529.A3
2601110529
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329120.A1
2607329120
|
-
|
|
|
|
13 - SINTERED-METAL BUSHING
BSD-1600301900.A312
1600301900
|
-
|
|
|
|
16 - CARB BRUSH HOLD W-SUPR
BSD-2604465076.A55
2604465076
|
-
|
|
|
|
17 - BRUSH HOLDER
BSD-2604465079.A3
2604465079
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1170
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A167
2603490022
|
£1.75
|
£2.10
|
|
|
20 - STICKER
BSD-2601110530.A1
2601110530
|
-
|
|
|
|
26 - LIFTING ROD
BSD-2600780038.A34
2600780038
|
-
|
|
|
|
27 - CLAMP SCREW
BSD-2603400000.A271
2603400000
|
£4.26
|
£5.11
|
|
|
28 - SINTERED-METAL BUSHING
BSD-2600302006.A40
2600302006
|
-
|
|
|
|
30 - BEARING BOLT
BSD-2603105034.A9
2603105034
|
-
|
|
|
|
32 - GUIDE SLEEVE
BSD-2600400024.A100
2600400024
|
£2.80
|
£3.36
|
|
|
33 - SUPPORTING DISC
BSD-2600103013.A12
2600103013
|
£1.32
|
£1.58
|
|
|
34 - FELT WASHER
BSD-1600205023.A33
1600205023
|
£1.32
|
£1.58
|
|
|
35 - O-RING 8.0x2.5 MM
BSD-1610210014.A401
1610210014
|
-
|
|
|
|
36 - HOLDING SPRING
BSD-1619P09928.A87
1619P09928
|
£1.75
|
£2.10
|
|
|
37 - BASE PLATE
BSD-2601016012.A101
2601016012
|
£8.67
|
£10.41
|
|
|
42 - FIXING PLATE
BSD-2601030006.A4
2601030006
|
-
|
|
|
|
43 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A810
2910021122
|
£2.16
|
£2.59
|
|
|
44 - PROFILE BEADING
BSD-2602317025.A11
2602317025
|
-
|
|
|
|
47 - CABLE L=249 MM
BSD-2604448057.A81
2604448057
|
£1.32
|
£1.58
|
|
|
48 - DAMPING PLATE
BSD-2601022000.A646
2601022000
|
£1.75
|
£2.10
|
|
|
51 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A14
2604448032
|
-
|
|
|
|
52 - BEARING BOLT
BSD-2603201020.A85
2603201020
|
£1.75
|
£2.10
|
|
|
54 - COMPRESSION SPRING
BSD-2604613000.A287
2604613000
|
£1.75
|
£2.10
|
|
|
56 - GUIDE BRACKET
BSD-2601322014.A29
2601322014
|
-
|
|
|
|
57 - STRAIGHT PIN
BSD-2609002725.A29
2609002725
|
£1.75
|
£2.10
|
|
|
58 - STRAIGHT PIN 4M6x12DIN6325
BSD-2917530095.A10
2917530095
|
-
|
|
|
|
59 - SHIM 0.5 MM
BSD-2600101612.A104
2600101612
|
£1.75
|
£2.10
|
|
|
59 - SHIM 0.3 MM
BSD-2600116012.A24
2600116012
|
-
|
|
|
|
61 - COUNTERWEIGHT
BSD-2601098005.A22
2601098005
|
£3.80
|
£4.56
|
|
|
62 - NEEDLE BEARING
BSD-2600917900.A449
2600917900
|
£8.67
|
£10.41
|
|
|
63 - SPACER SLEEVE
BSD-2600200022.A19
2600200022
|
£1.75
|
£2.10
|
|
|
64 - SEALING PLATE
BSD-2601015057.A71
2601015057
|
£3.80
|
£4.56
|
|
|
65 - FIXING PLATE 0.6 MM
BSD-2601015008.A28
2601015008
|
£2.16
|
£2.59
|
|
|
66 - SWITCH HANDLE
BSD-2602026035.A3
2602026035
|
-
|
|
|
|
67 - SHIM 0.3 MM
BSD-2600101083.A2
2600101083
|
-
|
|
|
|
68 - RATCHET CAP
BSD-2600590006.A1322
2600590006
|
£1.75
|
£2.10
|
|
|
69 - SHIM 0.5 MM
BSD-2600100568.A137
2600100568
|
£1.75
|
£2.10
|
|
|
69 - SHIM 0.3 MM
BSD-2600100607.A1107
2600100607
|
£1.75
|
£2.10
|
|
|
70 - FORK LEVER
BSD-2601923003.A39
2601923003
|
-
|
|
|
|
71 - STICKER
BSD-2601110573.A3
2601110573
|
-
|
|
|
|
72 - SHIM 0.3 MM
BSD-2600100570.A195
2600100570
|
£1.75
|
£2.10
|
|
|
73 - SPEED GOVERNOR 220-240V
BSD-2607230008.A9
2607230008
|
-
|
|
|
|
74 - SHIM 0.5 MM
BSD-2600102014.A2
2600102014
|
-
|
|
|
|
75 - CONNECTING CABLE L=220 MM
BSD-2604448127.A6
2604448127
|
£1.32
|
£1.58
|
|
|
76 - PRESS-IN SOCKET
BSD-2600506008.A17
2600506008
|
-
|
|
|
|
77 - SUPPORT PLATE
BSD-2601098006.A10
2601098006
|
£1.75
|
£2.10
|
|
|
78 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1360
2603490017
|
£2.16
|
£2.59
|
|
|
79 - COMPRESSION SPRING
BSD-2604610009.A83
2604610009
|
-
|
|
|
|
80 - DETENT PIN
BSD-2603120019.A9
2603120019
|
£1.75
|
£2.10
|
|
|
81 - SUCTION DEVICE
BSD-2607001068.A2
2607001068
|
-
|
|
|
|
82 - COVERING HOOD
BSD-2605730028.A2
2605730028
|
-
|
|
|
|
84 - NEEDLE-ROLLER ASSEMBLY
BSD-2600913002.A2
2600913002
|
-
|
|
|
|
85 - SPRING RETAINING RING
BSD-2603105050.A13
2603105050
|
-
|
|
|
|
86 - SPACER SLEEVE
BSD-2600203001.A2
2600203001
|
-
|
|
|
|
90 - FAN
BSD-2606610022.A116
2606610022
|
£4.26
|
£5.11
|
|
|
655 - SPLINTERING PROTECTOR
BSD-2601016065.A4
2601016065
|
£5.30
|
£6.36
|
|
|
801 - HOUSING SECTION
BSD-2605104982.A6
2605104982
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A62
1607000386
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2600
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321904.A100
2604321904
|
£10.10
|
£12.12
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A131
2600905039
|
£12.04
|
£14.45
|
|
|
825 - LOCKING WASHER DIN 6799-2.3
BSD-2916080005.A267
2916080005
|
-
|
|
|
|
829 - BEARING BRACKET
BSD-2605807908.A21
2605807908
|
-
|
|
|
|
831 - SCREW AND WASHER ASSEMBLY DIN7985-M4x18Z1-4.8
BSD-2914500009.A11
2914500009
|
-
|
|
|
|
838 - ROLLER LEVER
BSD-2601321900.A10
2601321900
|
-
|
|
|
|
846 - ECCENTRIC COG WHEEL Z=39
BSD-2606319900.A33
2606319900
|
-
|
|
|
|
849 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A587
2912401020
|
£2.16
|
£2.59
|
|
|
850 - TAPPING SCREW DIN 7981-ST3.9x13-C-H
BSD-2910611018.A221
2910611018
|
-
|
|
|
|
853 - SUPPORT PLATE
BSD-2602316902.A14
2602316902
|
-
|
|
|
|
860 - NEEDLE BEARING
BSD-2600917900.A450
2600917900
|
£8.67
|
£10.41
|
|
|
883 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A201
2916080008
|
-
|
|
|
