2 - FIELD 100V
BSD-2604220446.A0
2604220446
|
£21.52
|
£25.83
|
|
|
3/50 - FAN
BSD-2606610022.A53
2606610022
|
£4.26
|
£5.11
|
|
|
4 - SWITCH
BSD-2607200210.A19
2607200210
|
£48.38
|
£58.06
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H07 RN-F
BSD-1604460125.A22
1604460125
|
-
|
|
|
|
10 - BRUSH PLATE
BSD-2604337122.A6
2604337122
|
£21.52
|
£25.83
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A301
1610905025
|
£6.52
|
£7.83
|
|
|
14/1 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A474
1610905048
|
£8.67
|
£10.41
|
|
|
15 - DAMPING RUBBER
BSD-1610026001.A18
1610026001
|
£1.75
|
£2.10
|
|
|
20 - CATCH DISK
BSD-1616409012.A75
1616409012
|
£5.87
|
£7.04
|
|
|
22 - CYLINDRICAL GEAR Z=51
BSD-1616317608.A32
1616317608
|
£6.52
|
£7.83
|
|
|
27 - STRIKER
BSD-1618710068.A57
1618710068
|
£7.78
|
£9.33
|
|
|
30 - DRIVE LEVER
BSD-1611911000.A91
1611911000
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-1614632001.A8
1614632001
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1614634008.A73
1614634008
|
£1.95
|
£2.34
|
|
|
34 - BEARING PIN
BSD-1613100021.A59
1613100021
|
£2.33
|
£2.80
|
|
|
36 - SUPPORTING DISC
BSD-1610190021.A21
1610190021
|
£2.16
|
£2.59
|
|
|
39 - PROTECTIVE CAP
BSD-1610508021.A74
1610508021
|
£1.95
|
£2.34
|
|
|
43 - SUPPORTING DISC
BSD-1610190020.A56
1610190020
|
£1.95
|
£2.34
|
|
|
44 - CLAMP HANDLE
BSD-1612026075.A5
1612026075
|
£3.34
|
£4.01
|
|
|
53 - NEEDLE BEARING
BSD-1610910077.A96
1610910077
|
£4.26
|
£5.11
|
|
|
55 - ROLLER THRUST BEARING
BSD-1610920012.A29
1610920012
|
£3.34
|
£4.01
|
|
|
56 - SUPPORT DISC 1.0 MM
BSD-1610102030.A54
1610102030
|
£2.61
|
£3.13
|
|
|
57 - ROLLER THRUST BEARING
BSD-1610920009.A69
1610920009
|
£3.34
|
£4.01
|
|
|
60 - SEAL RING
BSD-1610280006.A55
1610280006
|
£3.34
|
£4.01
|
|
|
62 - O-RING 18.0x2.5 MM
BSD-1610210125.A90
1610210125
|
£1.95
|
£2.34
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A341
1903230013
|
£2.16
|
£2.59
|
|
|
65 - RETAINING RING
BSD-1614601018.A64
1614601018
|
£1.66
|
£1.99
|
|
|
67 - SPRING RETAINING RING
BSD-1614601077.A58
1614601077
|
£1.75
|
£2.10
|
|
|
72 - SHIM WASHER 1.0 MM
BSD-1610100007.A98
1610100007
|
£1.75
|
£2.10
|
|
|
74 - SEALING FRAME
BSD-1611015040.A7
1611015040
|
-
|
|
|
|
75 - SEALING FRAME
BSD-1611015041.A31
1611015041
|
£1.95
|
£2.34
|
|
|
76 - SEALING FRAME
BSD-1611015042.A15
1611015042
|
-
|
|
|
|
78/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A428
2915011007
|
-
|
|
|
|
78/30 - WING SCREW M6x(15)55
BSD-1613480007.A157
1613480007
|
£1.75
|
£2.10
|
|
|
78/50 - CLAMPING PLATE M6
BSD-2608040014.A109
2608040014
|
-
|
|
|
|
78/60 - WING SCREW M6x20 MM
BSD-1613480008.A279
1613480008
|
£1.75
|
£2.10
|
|
|
86 - CONNECTING CABLE L=85 MM
BSD-2604448147.A66
2604448147
|
£1.75
|
£2.10
|
|
|
87 - CONNECTING CABLE L=115MM
BSD-2604448096.A78
2604448096
|
-
|
|
|
|
88 - CONNECTING CABLE L=88 MM
BSD-2604448034.A64
2604448034
|
£1.75
|
£2.10
|
|
|
89 - CABLE L=173 MM
BSD-2604448060.A270
2604448060
|
-
|
|
|
|
92 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A174
2912401021
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A173
2912401019
|
£1.75
|
£2.10
|
|
|
94 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A838
2603490017
|
£2.16
|
£2.59
|
|
|
95 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1764
2603410001
|
£1.75
|
£2.10
|
|
|
110 - REFERENCE PLATE
BSD-1601118B75.A23
1601118B75
|
£1.95
|
£2.34
|
|
|
700 - DRILL CHUCK SHANK 1/2
BSD-1617000154.A1
1617000154
|
£31.64
|
£37.97
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A410
2603421226
|
£1.75
|
£2.10
|
|
|
701 - CHUCK
BSD-1608571088.A282
1608571088
|
£27.23
|
£32.68
|
|
|
701/7 - CHUCK WRENCH SG2
BSD-2607950007.A278
2607950007
|
£6.52
|
£7.83
|
|
|
702 - PARTS SET
BSD-1617000133.A44
1617000133
|
-
|
|
|
|
702/10/2 - RETAINING RING
BSD-2604601004.A322
2604601004
|
£1.75
|
£2.10
|
|
|
702/20 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A127
1608521004
|
-
|
|
|
|
702/30 - SCREWDRIVER BIT
BSD-2607000248.A19
2607000248
|
-
|
|
|
|
702/40 - SCREWDRIVER BLADE GR.1.0x6. 1/4
BSD-1608511020.A2
1608511020
|
-
|
|
|
|
703 - DUST TRAY
BSD-1615439003.A130
1615439003
|
-
|
|
|
|
703/30 - RUBBER BUSHING dia5-7 MM
BSD-1610312001.A91
1610312001
|
-
|
|
|
|
703/651 - RUBBER BUSHING dia8-10 MM
BSD-1610312002.A48
1610312002
|
-
|
|
|
|
752 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001006.A20
1613001006
|
-
|
|
|
|
754 - DRILL HOLDER
BSD-2607000122.A2
2607000122
|
-
|
|
|
|
754 - DRILL HOLDER
BSD-2607018117.A29
2607018117
|
-
|
|
|
|
778 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A185
1619P10682
|
£12.49
|
£14.99
|
|
|
778 - AUXILIARY HANDLE dia 43 MM
BSD-1612025034.A5
1612025034
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-1617000362.A9
1617000362
|
-
|
|
|
|
803 - ARMATURE WITH FAN 100V
BSD-1614010145.A1
1614010145
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A246
160111A3H5
|
£2.61
|
£3.13
|
|
|
810/040 - CARBON-BRUSH SET
BSD-2604321905.A26
2604321905
|
£11.30
|
£13.56
|
|
|
810/060 - RATCHET CAP
BSD-2601322017.A11
2601322017
|
£1.75
|
£2.10
|
|
|
810/060 - RATCHET CAP
BSD-2601322013.A482
2601322013
|
£1.75
|
£2.10
|
|
|
816 - CHANGE-OVER SWITCH
BSD-2607200231.A42
2607200231
|
£16.41
|
£19.69
|
|
|
821 - HAMMER PIPE
BSD-1617000320.A44
1617000320
|
-
|
|
|
|
821/01 - HAMMER PIPE
BSD-1617000349.A22
1617000349
|
-
|
|
|
|
824 - JACK SHAFT
BSD-1617000972.A5
1617000972
|
-
|
|
|
|
841 - PROTECTION SLEEVE
BSD-1617000303.A32
1617000303
|
£14.91
|
£17.89
|
|
|
844 - CLAMP HANDLE
BSD-1617000322.A19
1617000322
|
£3.72
|
£4.47
|
|
|
844/1 - CLAMP HANDLE
BSD-1617000974.A12
1617000974
|
-
|
|
|
|
850 - BUSHING
BSD-1617000975.A58
1617000975
|
£6.61
|
£7.93
|
|
|
864 - STRAIGHT PIN DIN6325-2.5x12-RIKO
BSD-1613100019.A97
1613100019
|
£1.75
|
£2.10
|
|
