30 - CABLE CLEAT
BSD-F016T46305.A20
F016T46305
|
£1.75
|
£2.10
|
|
|
32 - STUD BOLT M6x25 MM
BSD-F016L11371.A6
F016L11371
|
£2.61
|
£3.13
|
|
|
35 - PLAIN WASHER 8.5 MM
BSD-F016L35316.A4
F016L35316
|
£1.75
|
£2.10
|
|
|
39/11 - CLAMPING PIECE
BSD-F016L61793.A3
F016L61793
|
£3.34
|
£4.01
|
|
|
39/16 - CABLE CLIP
BSD-F016L59236.A18
F016L59236
|
£1.32
|
£1.58
|
|
|
39/17 - PIVOT PIN
BSD-F016L62095.A13
F016L62095
|
£2.33
|
£2.80
|
|
|
39/20 - TRUNNION M6 x48
BSD-F016T49623.A26
F016T49623
|
£2.80
|
£3.36
|
|
|
40 - HOUSING BASE
BSD-F016L59301.A8
F016L59301
|
£30.28
|
£36.33
|
|
|
43/01 - HOUSING
BSD-F016L62161.A5
F016L62161
|
£30.28
|
£36.33
|
|
|
43/04 - SEALING CAP
BSD-F016L59186.A11
F016L59186
|
£3.34
|
£4.01
|
|
|
43/06 - NAMEPLATE
BSD-F016L62108.A1
F016L62108
|
-
|
|
|
|
43/07 - CLAMPING LEVER
BSD-F016L59334.A8
F016L59334
|
£1.95
|
£2.34
|
|
|
43/08 - GUARD PLATE
BSD-F016L59311.A8
F016L59311
|
£7.78
|
£9.33
|
|
|
43/09 - HINGE BOLT
BSD-F016L59353.A2
F016L59353
|
£1.75
|
£2.10
|
|
|
43/10 - COILED SPRING
BSD-F016L59352.A16
F016L59352
|
£1.75
|
£2.10
|
|
|
52/01 - AXLE
BSD-F016L59315.A15
F016L59315
|
-
|
|
|
|
52/02 - ADJUSTING LEVER
BSD-F016L59324.A22
F016L59324
|
-
|
|
|
|
52/03 - SPACER
BSD-F016L59373.A25
F016L59373
|
-
|
|
|
|
55 - CUTTER BLADE
BSD-F016L59314.A10
F016L59314
|
-
|
|
|
|
57 - FAN
BSD-F016102372.A5
F016102372
|
£14.91
|
£17.89
|
|
|
58 - SPACER
BSD-F016L61473.A5
F016L61473
|
-
|
|
|
|
61/01 - AXLE
BSD-F016L59315.A14
F016L59315
|
-
|
|
|
|
61/03 - SPACER
BSD-F016L59325.A9
F016L59325
|
£1.75
|
£2.10
|
|
|
75/01 - HANDLE
BSD-F016L57062.A1
F016L57062
|
£21.42
|
£25.71
|
|
|
75/06 - CLAMPING PIECE
BSD-F016T56180.A0
F016T56180
|
£5.30
|
£6.36
|
|
|
75/07 - ON-OFF SWITCH
BSD-F016L59288.A8
F016L59288
|
£5.87
|
£7.04
|
|
|
75/08 - POSITIONING LEVER
BSD-F016L66238.A99
F016L66238
|
£5.98
|
£7.18
|
|
|
75/09 - SPRING LEVER
BSD-F016T49845.A3
F016T49845
|
-
|
|
|
|
75/11 - COMPRESSION SPRING
BSD-F016T49226.A11
F016T49226
|
-
|
|
|
|
75/14 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A19
F016T49429
|
£1.75
|
£2.10
|
|
|
75/15 - REFERENCE PLATE
BSD-F016L62122.A1
F016L62122
|
-
|
|
|
|
80 - CATCHER CONTAINER
BSD-F016L62806.A1
F016L62806
|
£14.91
|
£17.89
|
|
|
83 - SEALING CAP
BSD-F016L61773.A4
F016L61773
|
£19.45
|
£23.34
|
|
|
86 - SEALING CAP
BSD-F016L62104.A1
F016L62104
|
£2.33
|
£2.80
|
|
|
91 - LINKAGE PART
BSD-F016L61882.A13
F016L61882
|
-
|
|
|
|
95 - COVER
BSD-F016L59318.A9
F016L59318
|
£6.52
|
£7.83
|
|
|
97 - BATTERY CHARGER GB 230/12V
BSD-F016L63305.A1
F016L63305
|
£102.57
|
£123.08
|
|
|
98 - PROTECTIVE SHIELD
BSD-F016L61602.A7
F016L61602
|
-
|
|
|
|
99 - SPRING
BSD-F016L59327.A241
F016L59327
|
£2.80
|
£3.36
|
|
|
100 - COILED SPRING
BSD-F016L61597.A4
F016L61597
|
£1.75
|
£2.10
|
|
|
103/03 - RELAY MOUNTING
BSD-F016102198.A5
F016102198
|
-
|
|
|
|
103/05 - CONNECTOR HOUSING
BSD-F016L61468.A2
F016L61468
|
£1.32
|
£1.58
|
|
|
103/07 - CONNECTING CABLE
BSD-F016L62049.A2
F016L62049
|
£10.82
|
£12.99
|
|
|
103/08 - SET RING
BSD-F016L61796.A2
F016L61796
|
-
|
|
|
|
110 - COVER
BSD-F016L59377.A5
F016L59377
|
-
|
|
|
|
450 - DISPLAY
BSD-F016L59346.A17
F016L59346
|
-
|
|
|
|
453 - REFERENCE PLATE
BSD-F016L61442.A2
F016L61442
|
-
|
|
|
|
454 - REFERENCE PLATE
BSD-F016L61268.A11
F016L61268
|
-
|
|
|
|
500 - PICKUP CLIP
BSD-F016L61747.A12
F016L61747
|
£1.75
|
£2.10
|
|
|
501 - SPRING RETAINING RING
BSD-F016T46941.A8
F016T46941
|
£1.75
|
£2.10
|
|
|
502 - PLAIN WASHER M5
BSD-F016T48428.A12
F016T48428
|
£1.32
|
£1.58
|
|
|
503 - SELF-CUTTING SCREW 4x19 MM
BSD-F016T49429.A20
F016T49429
|
£1.75
|
£2.10
|
|
|
510 - PLAIN WASHER
BSD-F016L57338.A11
F016L57338
|
-
|
|
|
|
801 - MOTOR
BSD-F016L59389.A2
F016L59389
|
£135.25
|
£162.30
|
|
|
839/18 - WING NUT
BSD-F016L66136.A155
F016L66136
|
£4.26
|
£5.11
|
|
|
839/19 - ADAPTER
BSD-F016102173.A4
F016102173
|
-
|
|
|
|
839/37 - FUSE
BSD-F016102176.A2
F016102176
|
£3.34
|
£4.01
|
|
|
859 - STUD BOLT
BSD-F016102169.A6
F016102169
|
£5.01
|
£6.01
|
|
|
861/2 - VERTICAL ADJUSTMENT
BSD-F016102101.A5
F016102101
|
£3.34
|
£4.01
|
|
|
875/03 - CONNECTING CABLE
BSD-F016102174.A0
F016102174
|
-
|
|
|
|
875/04 - ASSEMBLY KIT
BSD-F016103136.A46
F016103136
|
-
|
|
|
|
878 - HANDLE
BSD-F016102263.A0
F016102263
|
£8.49
|
£10.19
|
|
|
885 - AXLE
BSD-F016102106.A9
F016102106
|
-
|
|
|
|
888 - WHEEL
BSD-F016102102.A3
F016102102
|
-
|
|
|
|
889 - WHEEL
BSD-F016102103.A1
F016102103
|
-
|
|
|
|
896 - BATTERY SET 12Ah
BSD-F016102757.A3
F016102757
|
-
|
|
|
|
8103/1 - BATTERY PROTECTIVE COVER
BSD-F016102270.A3
F016102270
|
£61.98
|
£74.38
|
|
|
8103/04 - RELAY
BSD-F016102286.A8
F016102286
|
£9.49
|
£11.39
|
|
|
8107 - RELAY MOUNTING
BSD-F016102198.A6
F016102198
|
-
|
|
|
