1 - NAMEPLATE
BSD-1601118452.A0
1601118452
|
-
|
|
|
|
2 - HANDLE
BSD-1609350316.A0
1609350316
|
-
|
|
|
|
2/10 - REFERENCE PLATE
BSD-1601118479.A1
1601118479
|
-
|
|
|
|
3 - RAISED CTSK TAPPING SCREW
BSD-1609350317.A1
1609350317
|
-
|
|
|
|
4 - GUIDE RAIL
BSD-1609350318.A0
1609350318
|
-
|
|
|
|
5 - O-RING
BSD-1609350319.A1
1609350319
|
-
|
|
|
|
6 - RECTANGULAR TUBE
BSD-1609350320.A0
1609350320
|
-
|
|
|
|
7 - CARRYING HANDLE
BSD-1609350321.A1
1609350321
|
-
|
|
|
|
8 - RAISED CTSK TAPPING SCREW
BSD-1609350322.A0
1609350322
|
-
|
|
|
|
9 - BOTTLE CARRIER
BSD-1609350323.A1
1609350323
|
-
|
|
|
|
10 - CLEANING PIN
BSD-1609350324.A0
1609350324
|
-
|
|
|
|
11 - RAISED CTSK TAPPING SCREW dia6x20 MM
BSD-1609350006.A3
1609350006
|
-
|
|
|
|
12 - RELEASE LEVER
BSD-1609350325.A1
1609350325
|
-
|
|
|
|
12/10 - COILED SPRING
BSD-1609350413.A0
1609350413
|
-
|
|
|
|
13 - UPPER HOUSING
BSD-1609350326.A0
1609350326
|
-
|
|
|
|
14 - PUSH-BUTTON
BSD-1609350327.A1
1609350327
|
£36.63
|
£43.96
|
|
|
14/10 - AXLE
BSD-1609350328.A0
1609350328
|
-
|
|
|
|
14/20 - SPIRAL SPRING
BSD-1609350406.A0
1609350406
|
-
|
|
|
|
15 - POWER SUPPLY CORD L=5 M
BSD-1609350372.A0
1609350372
|
-
|
|
|
|
15/10 - TAPPING SCREW ST dia3x20 MM
BSD-1609350142.A23
1609350142
|
-
|
|
|
|
15/20 - STRAIN-RELIEF CLAMP
BSD-1609350025.A18
1609350025
|
-
|
|
|
|
15/30 - CORD GUARD
BSD-1609350166.A24
1609350166
|
-
|
|
|
|
15/40 - OVAL-HEAD SCREW DIN 7985-M5x8-8.8-Z
BSD-2912311150.A8
2912311150
|
-
|
|
|
|
16 - RAISED CTSK TAPPING SCREW
BSD-1609350329.A1
1609350329
|
-
|
|
|
|
17 - PIPE
BSD-1609350330.A0
1609350330
|
-
|
|
|
|
18 - HOSE GUIDE
BSD-1609350331.A1
1609350331
|
-
|
|
|
|
19 - HOSE GUIDE
BSD-1609350332.A0
1609350332
|
-
|
|
|
|
20 - CONTROL LEVER
BSD-1609350333.A1
1609350333
|
-
|
|
|
|
21 - INTERMEDIATE HOUSING
BSD-1609350334.A0
1609350334
|
-
|
|
|
|
22 - RECTANGULAR TUBE
BSD-1609350335.A1
1609350335
|
-
|
|
|
|
23 - AXLE
BSD-1609350336.A0
1609350336
|
-
|
|
|
|
24 - HOUSING BASE
BSD-1609350337.A1
1609350337
|
-
|
|
|
|
24/10 - RUBBER COLLAR
BSD-1609350407.A1
1609350407
|
-
|
|
|
|
25 - RAISED CTSK TAPPING SCREW
BSD-1609350338.A0
1609350338
|
-
|
|
|
|
26 - CONNECTOR
BSD-1609350339.A1
1609350339
|
-
|
|
|
|
27 - WHEEL SET
BSD-1609350340.A0
1609350340
|
-
|
|
|
|
28 - CIRCUIT UNIT
BSD-1609350341.A1
1609350341
|
-
|
|
|
|
28/10 - UPPER HOUSING
BSD-1609350364.A0
1609350364
|
-
|
|
|
|
28/20 - COVER PLATE
BSD-1609350365.A1
1609350365
|
-
|
|
|
|
28/30 - ON-OFF SWITCH
BSD-1609350366.A0
1609350366
|
-
|
|
|
|
28/40 - HOUSING
BSD-1609350367.A1
1609350367
|
-
|
|
|
|
28/50 - SPRING WASHER
BSD-1609350368.A0
1609350368
|
-
|
|
|
|
28/60 - CONDENSER
BSD-1609350369.A1
1609350369
|
-
|
|
|
|
28/70 - CONDENSER
BSD-1609350370.A0
1609350370
|
-
|
|
|
|
28/80 - BASE PLATE
BSD-1609350371.A1
1609350371
|
-
|
|
|
|
29 - MOTOR 230V
BSD-1609350342.A0
1609350342
|
-
|
|
|
|
29/10 - REPAIR KIT
BSD-1609350343.A1
1609350343
|
-
|
|
|
|
31 - REPAIR KIT
BSD-1609350344.A0
1609350344
|
-
|
|
|
|
32 - SPRING RETAINING RING
BSD-1609350016.A18
1609350016
|
-
|
|
|
|
33 - FAN WHEEL
BSD-1609350017.A18
1609350017
|
-
|
|
|
|
35 - CYLINDER BLOCK
BSD-1609350345.A1
1609350345
|
-
|
|
|
|
35/10 - REPAIR KIT
BSD-1609350410.A1
1609350410
|
£10.82
|
£12.99
|
|
|
35/20 - O-RING 80x2 MM
BSD-1609350098.A35
1609350098
|
-
|
|
|
|
35/30 - PLUG
BSD-1609350308.A18
1609350308
|
-
|
|
|
|
35/40 - CYLINDER BLOCK
BSD-1609350377.A1
1609350377
|
-
|
|
|
|
35/50 - FILTER SCREEN
BSD-1609350032.A19
1609350032
|
-
|
|
|
|
35/60 - RETAINING RING
BSD-1609350378.A0
1609350378
|
-
|
|
|
|
35/70 - THREADED FITTING
BSD-1609350379.A1
1609350379
|
-
|
|
|
|
35/80 - SEAL
BSD-1609350380.A0
1609350380
|
-
|
|
|
|
35/90 - O-RING
BSD-1609350381.A1
1609350381
|
-
|
|
|
|
35/100 - O-RING
BSD-1609350382.A0
1609350382
|
-
|
|
|
|
35/110 - RUBBER COLLAR
BSD-1609350035.A18
1609350035
|
-
|
|
|
|
35/120 - THRUST RING
BSD-1609350036.A18
1609350036
|
-
|
|
|
|
35/130 - SEAL
BSD-1609350383.A1
1609350383
|
-
|
|
|
|
36 - REPAIR KIT
BSD-1609350408.A0
1609350408
|
-
|
|
|
|
37 - INTERMEDIATE FLANGE
BSD-1609350347.A0
1609350347
|
-
|
|
|
|
38 - CYLINDER HEAD
BSD-1609350348.A1
1609350348
|
-
|
|
|
|
38/10 - O-RING
BSD-1609350384.A0
1609350384
|
-
|
|
|
|
38/20 - O-RING
BSD-1609350385.A1
1609350385
|
-
|
|
|
|
38/30 - SLEEVE
BSD-1609350386.A0
1609350386
|
£13.12
|
£15.75
|
|
|
38/40 - SLEEVE
BSD-1609350387.A1
1609350387
|
-
|
|
|
|
38/50 - THRUST RING
BSD-1609350388.A0
1609350388
|
-
|
|
|
|
38/60 - VALVE
BSD-1609350389.A1
1609350389
|
-
|
|
|
|
38/70 - CONNECTOR
BSD-1609350390.A0
1609350390
|
-
|
|
|
|
38/80 - CYLINDER HEAD
BSD-1609350391.A1
1609350391
|
-
|
|
|
|
38/90 - SCREW
BSD-1609350392.A0
1609350392
|
-
|
|
|
|
38/100 - PARTS SET dia1.6xdia15.1 MM
BSD-1609350038.A19
1609350038
|
-
|
|
|
|
40 - PRESSURE GAUGE
BSD-1609350307.A27
1609350307
|
-
|
|
|
|
40/10 - O-RING
BSD-1609350350.A0
1609350350
|
-
|
|
|
|
41 - PLUG
BSD-1609350308.A19
1609350308
|
-
|
|
|
|
42 - SLEEVE
BSD-1609350351.A1
1609350351
|
-
|
|
|
|
43 - TRAILER-CONTROL VALVE
BSD-1609350352.A0
1609350352
|
-
|
|
|
|
43/10 - VALVE HOUSING
BSD-1609350393.A1
1609350393
|
-
|
|
|
|
43/20 - FLOW THROTTLE
BSD-1609350394.A0
1609350394
|
-
|
|
|
|
43/30 - VALVE CONE
BSD-1609350400.A0
1609350400
|
-
|
|
|
|
43/40 - PLUG
BSD-1609350395.A1
1609350395
|
-
|
|
|
|
43/50 - LENGTHENING PIECE
BSD-1609350396.A0
1609350396
|
-
|
|
|
|
43/70 - PLUG
BSD-1609350398.A0
1609350398
|
-
|
|
|
|
43/80 - SCREW
BSD-1609350399.A1
1609350399
|
-
|
|
|
|
43/90 - HOSE FITTING
BSD-1609350401.A0
1609350401
|
-
|
|
|
|
43/100 - NIPPLE
BSD-1609350402.A1
1609350402
|
-
|
|
|
|
43/110 - UNION NUT
BSD-1609350403.A0
1609350403
|
-
|
|
|
|
43/120 - O-RING
BSD-1609350350.A1
1609350350
|
-
|
|
|
|
44 - DOSING UNIT
BSD-1609350353.A0
1609350353
|
-
|
|
|
|
45 - HOSE
BSD-1609350354.A1
1609350354
|
-
|
|
|
|
46 - COMPRESSION GLAND
BSD-1609350355.A0
1609350355
|
-
|
|
|
|
47 - HOSE
BSD-1609350356.A1
1609350356
|
-
|
|
|
|
48 - FILTER
BSD-1609350357.A0
1609350357
|
-
|
|
|
|
650 - SET OF HANDLES
BSD-1609350310.A0
1609350310
|
-
|
|
|
|
650/12 - CONNECTING TUBE
BSD-1609350089.A0
1609350089
|
-
|
|
|
|
650/15 - TAPPING SCREW ST dia3x20 MM
BSD-1609350142.A22
1609350142
|
-
|
|
|
|
650/18 - PLASTIC HOSE L=9 M. MAX. 150 BAR
BSD-1609350504.A25
1609350504
|
-
|
|
|
|
650/18/12 - PARTS SET dia2xdia11 MM
BSD-1609350074.A46
1609350074
|
-
|
|
|
|
650/18/17 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A230
1609350078
|
-
|
|
|
|
650/19 - REPAIR KIT
BSD-1609350080.A19
1609350080
|
-
|
|
|
|
650/20 - PARTS SET
BSD-1609350176.A27
1609350176
|
-
|
|
|
|
650/40 - GUIDE SLEEVE
BSD-1609350198.A34
1609350198
|
-
|
|
|
|
651 - HIGH PRESS CLEAN NOZZLE
BSD-1609350311.A1
1609350311
|
-
|
|
|
|
651/10 - NOZZLE RETAINING NUT
BSD-1609350145.A11
1609350145
|
-
|
|
|
|
651/11 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A231
1609350078
|
-
|
|
|
|
651/20 - PARTS SET dia2.0xdia18.0 MM
BSD-1609350182.A27
1609350182
|
-
|
|
|
|
651/30 - PARTS SET dia1.78xdia18.77 MM
BSD-1609350181.A11
1609350181
|
-
|
|
|
|
653 - NOZZLE
BSD-F016102635.A1
F016102635
|
-
|
|
|
|
653/10 - NOZZLE RETAINING NUT
BSD-1609350414.A0
1609350414
|
-
|
|
|
|
653/11 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A235
1609350078
|
-
|
|
|
|
653/12 - CONNECTING TUBE
BSD-1609350411.A0
1609350411
|
-
|
|
|
|
653/13 - REPAIR KIT
BSD-1609350412.A1
1609350412
|
-
|
|
|
|
653/20 - PARTS SET dia2.0xdia18.0 MM
BSD-1609350182.A26
1609350182
|
-
|
|
|
|
653/30 - PARTS SET dia1.78xdia18.77 MM
BSD-1609350181.A12
1609350181
|
-
|
|
|
|
678 - TAP CONNECTION PIECE 3/4
BSD-0600800001.A40
0600800001
|
-
|
|
|
|
678/10 - GASKET dia15xdia24x4.5=3/4
BSD-1609351029.A67
1609351029
|
£1.75
|
£2.10
|
|
|
700 - FLEXIBLE CONNECTION L=7 M
BSD-2609200276.A17
2609200276
|
-
|
|
|
|
700/10 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A234
1609350078
|
-
|
|
|
|
702 - EXTENSION TUBE
BSD-1609350053.A40
1609350053
|
-
|
|
|
|
702/80 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A232
1609350078
|
-
|
|
|
|
703 - CLEANING BRUSH
BSD-1609350156.A12
1609350156
|
-
|
|
|
|
703/20 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A96
1609351002
|
-
|
|
|
|
703/30 - ADAPTER
BSD-1609350159.A56
1609350159
|
-
|
|
|
|
703/40 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A233
1609350078
|
-
|
|
|
|
704 - ROTARY CLEANING BRUSH
BSD-1609350126.A10
1609350126
|
-
|
|
|
|
704/20 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A97
1609351002
|
-
|
|
|
|
704/30 - CONNECTING PIECE
BSD-1609351014.A48
1609351014
|
£21.52
|
£25.83
|
|
|
704/40 - ADAPTER
BSD-1609350159.A57
1609350159
|
-
|
|
|
|
704/50 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A240
1609350078
|
-
|
|
|
|
705 - PIPE CLEANING SET L=7 M
BSD-1609350054.A0
1609350054
|
-
|
|
|
|
705/1 - PIPE CLEANING SET L=15 M
BSD-1609350055.A34
1609350055
|
-
|
|
|
|
705/10 - PIPE NOZZLE
BSD-1609350137.A30
1609350137
|
-
|
|
|
|
705/20 - PARTS SET dia1.6xdia10 MM
BSD-1609350088.A40
1609350088
|
-
|
|
|
|
705/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A241
1609350078
|
-
|
|
|
|
706 - PIPE CLEANING SET L=7 M
BSD-2609200277.A0
2609200277
|
-
|
|
|
|
706/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A238
1609350078
|
-
|
|
|
|
707 - JET PIPE
BSD-1609350057.A40
1609350057
|
-
|
|
|
|
707/10 - NOZZLE RETAINING NUT
BSD-1609350136.A10
1609350136
|
-
|
|
|
|
707/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A239
1609350078
|
-
|
|
|
|
708 - SPACER
BSD-1609350119.A10
1609350119
|
-
|
|
|
|
708/10 - CLAMP SCREW
BSD-1609350120.A30
1609350120
|
-
|
|
|
|
708/20 - CLAMPING PIECE
BSD-1609350121.A10
1609350121
|
-
|
|
|
|
708/30 - WHEEL
BSD-1609350122.A30
1609350122
|
-
|
|
|
|
708/40 - SEALING CAP
BSD-1609350123.A10
1609350123
|
-
|
|
|
|
709 - SAND BLAST EQUIPMENT
BSD-1609350188.A19
1609350188
|
-
|
|
|
|
709/10 - NOZZLE-HOLDER ASSEMBLY
BSD-1609350146.A28
1609350146
|
-
|
|
|
|
709/11 - SUCTION CONNECTION PIECE
BSD-1609350135.A34
1609350135
|
-
|
|
|
|
709/12 - CONNECTING TUBE
BSD-1609350192.A19
1609350192
|
-
|
|
|
|
709/13 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A237
1609350078
|
-
|
|
|
|
709/20 - OVAL-HEAD SCREW DIN 7985-M4x20-8.8-Z
BSD-2912311130.A32
2912311130
|
-
|
|
|
|
709/30 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A346
2915011005
|
£1.75
|
£2.10
|
|
|
709/40 - TAPPING SCREW DIN7981-ST2.9x9.5C-Z
BSD-2912401005.A324
2912401005
|
£1.75
|
£2.10
|
|
|
709/50 - NOZZLE
BSD-1609350134.A11
1609350134
|
-
|
|
|
|
709/60 - PARTS SET dia2xdia11 MM
BSD-1609350074.A45
1609350074
|
-
|
|
|
|
712 - NON-RETURN VALVE
BSD-1609350060.A20
1609350060
|
-
|
|
|
|
712/10 - GASKET dia15xdia24x3=3/4
BSD-1609351002.A98
1609351002
|
-
|
|
|
|
717 - EXTENSION TUBE 410 MM
BSD-1609350164.A11
1609350164
|
-
|
|
|
|
717/60 - PARTS SET dia2.4xdia9.6 MM
BSD-1609350078.A236
1609350078
|
-
|
|
|
|
754 - CLEANING AGENT 1x0.55 LITER
BSD-1609350153.A25
1609350153
|
-
|
|
|
|
754/1 - CLEANING AGENT 1x2.5 LITER
BSD-1609350155.A27
1609350155
|
-
|
|
|
|
755 - STRAIN-RELIEF CLAMP
BSD-2601398012.A0
2601398012
|
-
|
|
|
|
760 - WAX 1x0.55 LITER
BSD-1609350161.A11
1609350161
|
-
|
|
|
|
760/1 - WAX 1x2.5 LITER
BSD-1609350162.A33
1609350162
|
-
|
|
|
|
898 - CONTAINER 0.55 LITER. 12 STCK.
BSD-1609350189.A0
1609350189
|
-
|
|
|
