1/1 - MOTOR HOUSING
BSD-1605102107.A1
1605102107
|
-
|
|
|
|
2 - STATOR 230V/180HZ
BSD-1604229219.A3
1604229219
|
-
|
|
|
|
4 - SEAL
BSD-1601015011.A149
1601015011
|
£3.80
|
£4.56
|
|
|
4/1 - HANDLE
BSD-1605132083.A7
1605132083
|
-
|
|
|
|
5 - GEAR HOUSING
BSD-1605806159.A28
1605806159
|
-
|
|
|
|
6 - BEARING FLANGE
BSD-1605805022.A20
1605805022
|
-
|
|
|
|
7 - CONICAL SPRING WASHER
BSD-1600521013.A158
1600521013
|
-
|
|
|
|
8/1 - SWITCH
BSD-3607200005.A8
3607200005
|
£120.11
|
£144.13
|
|
|
9 - CONTROL LEVER
BSD-1602026038.A28
1602026038
|
£5.30
|
£6.36
|
|
|
11/1 - DRILLING SPINDLE 5/8
BSD-1603523069.A3
1603523069
|
-
|
|
|
|
12 - GUIDE PULLEY
BSD-1600500014.A56
1600500014
|
-
|
|
|
|
13/4 - SCREENED ELECTRIC CABLE
BSD-1604462063.A3
1604462063
|
-
|
|
|
|
15 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A169
1600703009
|
£5.58
|
£6.70
|
|
|
16/1 - FASTENING CLAMP
BSD-1601302013.A457
1601302013
|
£1.75
|
£2.10
|
|
|
17 - SEALING PLATE
BSD-1600113003.A264
1600113003
|
£2.80
|
£3.36
|
|
|
18 - SEAL RING
BSD-1600209009.A29
1600209009
|
£6.52
|
£7.83
|
|
|
19 - O-RING 45x3MM
BSD-1900210146.A215
1900210146
|
£4.26
|
£5.11
|
|
|
20 - SEALING DISK
BSD-1600108048.A165
1600108048
|
£1.75
|
£2.10
|
|
|
21 - PLAIN WASHER
BSD-2100551000.A172
2100551000
|
-
|
|
|
|
22 - SHIM 0.1 MM
BSD-1600101616.A61
1600101616
|
£2.61
|
£3.13
|
|
|
22 - SHIM 0.2 MM
BSD-1600101617.A135
1600101617
|
£1.75
|
£2.10
|
|
|
22 - SHIM 0.3 MM
BSD-1600101618.A61
1600101618
|
£2.61
|
£3.13
|
|
|
22 - SHIM 0.05 MM
BSD-1600101619.A132
1600101619
|
£2.16
|
£2.59
|
|
|
23 - SHIM 0.05 MM
BSD-1600102638.A55
1600102638
|
£3.34
|
£4.01
|
|
|
23 - SHIM 0.1 MM
BSD-1600102639.A179
1600102639
|
-
|
|
|
|
23 - SHIM 0.15 MM
BSD-1600102640.A55
1600102640
|
-
|
|
|
|
24 - NAMEPLATE
BSD-3601106053.A1197
3601106053
|
£5.30
|
£6.36
|
|
|
26 - O-RING
BSD-1120210000.A52
1120210000
|
-
|
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A425
1600910010
|
£45.67
|
£54.80
|
|
|
28 - GROOVE BALL BEARING 17x47x14
BSD-1900900352.A156
1900900352
|
£27.23
|
£32.68
|
|
|
29 - SET SCREW
BSD-1603402004.A176
1603402004
|
£2.61
|
£3.13
|
|
|
30/1 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-8.8
BSD-2910021120.A99
2910021120
|
£1.75
|
£2.10
|
|
|
31 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x50-8.8
BSD-2910141213.A39
2910141213
|
£2.61
|
£3.13
|
|
|
32/1 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A19
2910141170
|
£2.61
|
£3.13
|
|
|
33 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A213
2910141164
|
£2.16
|
£2.59
|
|
|
34 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A171
2910141158
|
£1.75
|
£2.10
|
|
|
35 - RETAINING RING dia22 MM
BSD-2916620011.A4
2916620011
|
£1.75
|
£2.10
|
|
|
36/1 - SPRING WASHER dia4.2 MM
BSD-3600150006.A17
3600150006
|
£2.61
|
£3.13
|
|
|
37 - CLAMPING SADDLE
BSD-3601321001.A29
3601321001
|
£3.72
|
£4.47
|
|
|
38 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A325
3603133001
|
£2.61
|
£3.13
|
|
|
39 - PAN HEAD SCREW DIN 85-MS-M 4x12
BSD-2910110122.A26
2910110122
|
£1.75
|
£2.10
|
|
|
40 - O-RING 74.0x3.0 MM
BSD-1600210006.A222
1600210006
|
£1.75
|
£2.10
|
|
|
41 - FELT WASHER
BSD-1600205027.A18
1600205027
|
£1.75
|
£2.10
|
|
|
42 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A614
2910021118
|
£1.75
|
£2.10
|
|
|
43 - GROMMET
BSD-1600306000.A137
1600306000
|
£1.95
|
£2.34
|
|
|
44 - PROTECTIVE COVER
BSD-1600502004.A125
1600502004
|
£4.26
|
£5.11
|
|
|
45 - SEAL
BSD-1601015011.A150
1601015011
|
£3.80
|
£4.56
|
|
|
46 - INTERMEDIATE FLANGE
BSD-1605700013.A6
1605700013
|
-
|
|
|
|
48 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A557
2910211021
|
£1.75
|
£2.10
|
|
|
49 - CONNECTING TERMINAL
BSD-1601091007.A4
1601091007
|
-
|
|
|
|
50 - BACKUP RING
BSD-1600203000.A2
1600203000
|
-
|
|
|
|
57 - BEARING HOUSING
BSD-1605820145.A43
1605820145
|
-
|
|
|
|
58 - BEARING COVER
BSD-1600501019.A10
1600501019
|
£23.86
|
£28.63
|
|
|
59 - COVER DISC
BSD-1600501024.A373
1600501024
|
£16.41
|
£19.69
|
|
|
60 - FELT DISC
BSD-1600108018.A287
1600108018
|
£2.61
|
£3.13
|
|
|
61 - GROOVE BALL BEARING
BSD-3600900022.A8
3600900022
|
£21.68
|
£26.01
|
|
|
62 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A159
1900905121
|
£18.96
|
£22.75
|
|
|
63 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A106
3603435051
|
£1.75
|
£2.10
|
|
|
64 - RETAINING RING 12 DIN 9045
BSD-2916600007.A26
2916600007
|
£2.80
|
£3.36
|
|
|
65 - BEVEL GEAR Z=27
BSD-1606333048.A0
1606333048
|
-
|
|
|
|
66 - BEVEL GEAR Z=38
BSD-1606333049.A20
1606333049
|
-
|
|
|
|
67 - HEX NUT M12x1.5 MM
BSD-1603300009.A100
1603300009
|
£1.75
|
£2.10
|
|
|
70 - REFERENCE PLATE
BSD-3601119236.A163
3601119236
|
£3.72
|
£4.47
|
|
|
652 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A759
1607950061
|
£5.42
|
£6.50
|
|
|
653 - AUXILIARY HANDLE M14
BSD-1602025022.A1072
1602025022
|
£13.41
|
£16.09
|
|
|
653 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A943
1602025030
|
£18.96
|
£22.75
|
|
|
655 - PROTECTIVE COVER dia180 MM
BSD-1605510199.A43
1605510199
|
-
|
|
|
|
656 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A37
2600501006
|
£16.43
|
£19.72
|
|
|
657 - ROUND NUT M14
BSD-2603345004.A84
2603345004
|
£6.52
|
£7.83
|
|
|
752/1 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A226
2910001052
|
£2.16
|
£2.59
|
|
|
800 - HANDLE
BSD-1605132067.A43
1605132067
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031146.A23
3607031146
|
-
|
|
|
