2 - STATOR 265V/200HZ
BSD-3604229077.A0
3604229077
|
-
|
|
|
|
3/6 - FAN
BSD-1606610069.A15
1606610069
|
£31.64
|
£37.97
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A105
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209006.A56
3600209006
|
£5.58
|
£6.70
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A246
3600905095
|
£21.52
|
£25.83
|
|
|
7 - BEARING FLANGE
BSD-3605805009.A154
3605805009
|
£59.53
|
£71.44
|
|
|
14 - THREADED RING
BSD-3603344024.A207
3603344024
|
£16.41
|
£19.69
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A143
1600210037
|
£2.61
|
£3.13
|
|
|
16 - SPACER SLEEVE
BSD-3600328035.A12
3600328035
|
-
|
|
|
|
20 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A34
2914451079
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW
BSD-2914451080.A149
2914451080
|
£3.72
|
£4.47
|
|
|
23 - COMPRESSION SPRING
BSD-3604611019.A194
3604611019
|
£2.61
|
£3.13
|
|
|
27 - SEALING DISC
BSD-3600100049.A153
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A122
3600100048
|
£2.80
|
£3.36
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A179
3604462017
|
£54.42
|
£65.30
|
|
|
61 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A20
1603435008
|
£1.32
|
£1.58
|
|
|
62 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A316
2910211020
|
£2.16
|
£2.59
|
|
|
63 - CABLE ROUTING
BSD-1602388027.A232
1602388027
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303002.A52
3601303002
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303004.A73
3601303004
|
£5.58
|
£6.70
|
|
|
65 - STORAGE LEDGE
BSD-1602388029.A381
1602388029
|
£1.75
|
£2.10
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A351
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A1144
3601106053
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A42
3601110047
|
£2.80
|
£3.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A278
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A82
3601119236
|
£3.72
|
£4.47
|
|
|
105 - NEEDLE BEARING
BSD-2600914018.A24
2600914018
|
£8.67
|
£10.41
|
|
|
106 - GROOVE BALL BEARING
BSD-3600905025.A113
3600905025
|
£16.41
|
£19.69
|
|
|
107 - SEAL RING
BSD-1600290020.A73
1600290020
|
£1.75
|
£2.10
|
|
|
108 - BEVEL GEAR Z=14/29
BSD-3606333047.A15
3606333047
|
£68.42
|
£82.10
|
|
|
109 - CROWN GEAR Z=61
BSD-3606334059.A0
3606334059
|
£102.57
|
£123.08
|
|
|
113 - SHIM 0.1 MM
BSD-1600190022.A189
1600190022
|
£1.75
|
£2.10
|
|
|
113 - SHIM 0.15 MM
BSD-1600190020.A188
1600190020
|
£1.75
|
£2.10
|
|
|
113 - SHIM 0.3 MM
BSD-1600190021.A639
1600190021
|
£2.61
|
£3.13
|
|
|
114 - RETAINING CLIP
BSD-1600119010.A571
1600119010
|
£1.75
|
£2.10
|
|
|
117 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A346
2910141201
|
£2.61
|
£3.13
|
|
|
118 - PLAIN WASHER
BSD-3600100043.A156
3600100043
|
£3.72
|
£4.47
|
|
|
119 - O-RING 79.0x1.78 MM
BSD-1600210033.A861
1600210033
|
£1.75
|
£2.10
|
|
|
120 - THREAD-FORMING TAP. SCREW
BSD-1603435076.A104
1603435076
|
£2.61
|
£3.13
|
|
|
651 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1024
1602025030
|
£18.96
|
£22.75
|
|
|
653 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A190
2605703014
|
£7.36
|
£8.83
|
|
|
655 - ROUND NUT M14
BSD-1603345043.A149
1603345043
|
£8.67
|
£10.41
|
|
|
657 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A138
2607950511
|
£4.26
|
£5.11
|
|
|
658 - PROTECTIVE COVER dia180 MM
BSD-1605510176.A7
1605510176
|
-
|
|
|
|
659 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A138
1907950007
|
£5.30
|
£6.36
|
|
|
700/10 - AUXILIARY HANDLE
BSD-160202507H.A247
160202507H
|
£11.30
|
£13.56
|
|
|
700/20 - ADAPTER M8/M14
BSD-3603523013.A170
3603523013
|
£16.41
|
£19.69
|
|
|
800 - GEAR HOUSING
BSD-3607020075.A42
3607020075
|
£179.37
|
£215.24
|
|
|
801 - MOTOR HOUSING GR.88
BSD-3605108160.A87
3605108160
|
£179.37
|
£215.24
|
|
|
803 - ROTOR
BSD-3604080028.A2
3604080028
|
-
|
|
|
|
810/020 - BEARING FLANGE
BSD-3607031343.A41
3607031343
|
£48.38
|
£58.06
|
|
|
810/030 - GRINDING SPINDLE M14
BSD-3607031346.A72
3607031346
|
£54.42
|
£65.30
|
|
|
810/077 - SET OF EARTLING MATERIAL
BSD-3607031299.A82
3607031299
|
£8.67
|
£10.41
|
|
|
823 - SPRING SET
BSD-3607031296.A194
3607031296
|
£16.41
|
£19.69
|
|
|
856 - SWITCH KIT
BSD-3607031298.A106
3607031298
|
£81.81
|
£98.17
|
|
|
858 - HANDLE
BSD-3607031297.A77
3607031297
|
£37.27
|
£44.72
|
|
|
859 - GROMMET
BSD-3607031550.A68
3607031550
|
£13.12
|
£15.75
|
|
|
865/20 - ASSEMBLY OF SERVICE PARTS
BSD-3607030289.A71
3607030289
|
£12.04
|
£14.45
|
|
|
865/30 - FASTENING PARTS KIT
BSD-3607030290.A22
3607030290
|
£13.12
|
£15.75
|
|
