1 - MOTOR HOUSING
BSD-3605102055.A5
3605102055
|
£352.76
|
£423.31
|
|
|
2 - STATOR 135V/200HZ.200V/300HZ
BSD-1604229192.A2
1604229192
|
£410.78
|
£492.94
|
|
|
5 - SEAL RING
BSD-1600209004.A8
1600209004
|
£2.80
|
£3.36
|
|
|
6 - AIR-DEFLECTOR RING
BSD-1600209002.A4
1600209002
|
£5.30
|
£6.36
|
|
|
7 - NEEDLE BEARING
BSD-1600910007.A6
1600910007
|
£13.12
|
£15.75
|
|
|
8 - BEARING COVER
BSD-3605808006.A5
3605808006
|
£218.41
|
£262.09
|
|
|
9 - CYLINDRICAL GEAR
BSD-1606320040.A7
1606320040
|
£102.57
|
£123.08
|
|
|
10 - GRINDING SPINDLE
BSD-1603523059.A1
1603523059
|
£80.61
|
£96.73
|
|
|
11 - BEARING COVER
BSD-1605808041.A5
1605808041
|
£41.62
|
£49.95
|
|
|
12 - SHIM 0.4 MM
BSD-1600102641.A1
1600102641
|
£5.01
|
£6.01
|
|
|
13 - FELT WASHER
BSD-3600205002.A33
3600205002
|
£2.61
|
£3.13
|
|
|
14 - INTERMEDIATE RING
BSD-1600202027.A3
1600202027
|
£10.82
|
£12.99
|
|
|
15 - AUXILIARY HANDLE M14
BSD-1602025022.A3
1602025022
|
£13.41
|
£16.09
|
|
|
15 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A683
1602025030
|
£18.96
|
£22.75
|
|
|
16 - SEALING PLATE
BSD-3601038010.A1
3601038010
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026030.A55
1602026030
|
£10.10
|
£12.12
|
|
|
19/1 - FELT WASHER
BSD-1600205008.A167
1600205008
|
£1.75
|
£2.10
|
|
|
21 - FASTENING CLAMP
BSD-1601303003.A328
1601303003
|
£2.16
|
£2.59
|
|
|
22 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A23
3607030236
|
£61.98
|
£74.38
|
|
|
23 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A545
1600703009
|
£5.58
|
£6.70
|
|
|
24 - SEALING PLATE
BSD-1600113003.A122
1600113003
|
£2.80
|
£3.36
|
|
|
25 - SPRING WASHER DIN 137-A4
BSD-1600150006.A234
1600150006
|
-
|
|
|
|
26 - NAMEPLATE
BSD-3601106053.A408
3601106053
|
£5.30
|
£6.36
|
|
|
27 - GROOVE BALL BEARING 15x35x11
BSD-1900905226.A13
1900905226
|
£27.23
|
£32.68
|
|
|
29 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x18-8.8
BSD-2910141160.A50
2910141160
|
£2.16
|
£2.59
|
|
|
30 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A106
2910021154
|
£1.75
|
£2.10
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM5x10-5.8
BSD-2910011152.A20
2910011152
|
£1.75
|
£2.10
|
|
|
32 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A615
2910211006
|
£1.75
|
£2.10
|
|
|
33 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1379
2910021118
|
£1.75
|
£2.10
|
|
|
34 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x35-8.8
BSD-2910141168.A1
2910141168
|
£3.80
|
£4.56
|
|
|
35 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A395
2910091118
|
£1.75
|
£2.10
|
|
|
36 - PAN HEAD SCREW DIN 85-MS-M 4x12
BSD-2910110122.A155
2910110122
|
£1.75
|
£2.10
|
|
|
38 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A387
3603133001
|
£2.61
|
£3.13
|
|
|
39 - CLAMPING SADDLE
BSD-3601321001.A392
3601321001
|
£3.72
|
£4.47
|
|
|
41 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A430
2916011005
|
£1.75
|
£2.10
|
|
|
42 - MANUFACTURER'S NAMEPLATE
BSD-3601110104.A10
3601110104
|
£5.01
|
£6.01
|
|
|
43 - SPRING WASHER dia4.2 MM
BSD-3600150006.A676
3600150006
|
£2.61
|
£3.13
|
|
|
45 - ROTOR WITHOUT WINDING
BSD-1604080079.A7
1604080079
|
£357.27
|
£428.72
|
|
|
46 - BEARING COVER
BSD-1600501019.A497
1600501019
|
£23.86
|
£28.63
|
|
|
47 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A186
1600900001
|
-
|
|
|
|
48 - INTERMEDIATE RING
BSD-1600420003.A6
1600420003
|
£36.63
|
£43.96
|
|
|
49 - BEARING HOUSING
BSD-1605820152.A6
1605820152
|
£216.12
|
£259.35
|
|
|
50 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A1
1610900025
|
£16.41
|
£19.69
|
|
|
51 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A242
2910021125
|
£1.75
|
£2.10
|
|
|
52 - FELT WASHER
BSD-3600205002.A32
3600205002
|
£2.61
|
£3.13
|
|
|
60 - SEALING CORD
BSD-1601014000.A24
1601014000
|
£2.80
|
£3.36
|
|
|
67 - SEALING PLATE
BSD-1602388006.A51
1602388006
|
£5.58
|
£6.70
|
|
|
68 - GROMMET
BSD-1600306001.A260
1600306001
|
£2.61
|
£3.13
|
|
|
69 - SOCKET HEAD CAP SCREW DIN 84-AM8x10-8.8
BSD-2910021232.A1
2910021232
|
£1.75
|
£2.10
|
|
|
70 - SET SCREW
BSD-1603402002.A85
1603402002
|
£1.75
|
£2.10
|
|
|
71 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A786
2910211021
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1025
3601119236
|
£3.72
|
£4.47
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A614
2607950511
|
£4.26
|
£5.11
|
|
|
652 - LIFTING EYE BOLT DIN 580-M 8
BSD-2912521237.A15
2912521237
|
£11.78
|
£14.13
|
|
|
653 - SPRING LOCK WASHER DIN 127-B12
BSD-2916680011.A15
2916680011
|
-
|
|
|
|
654 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A90
1907950513
|
£16.41
|
£19.69
|
|
|
800 - SEALING PLATE
BSD-1602388007.A210
1602388007
|
£12.04
|
£14.45
|
|
|
803 - SWITCH KIT
BSD-1607000036.A137
1607000036
|
-
|
|
|
|
805 - HANDLE
BSD-3605132048.A2
3605132048
|
£63.50
|
£76.20
|
|
