1 - MOTOR HOUSING
BSD-3605102077.A7
3605102077
|
£179.37
|
£215.24
|
|
|
2 - SEAL RING
BSD-1600209006.A123
1600209006
|
£2.80
|
£3.36
|
|
|
3 - STATOR 200V/300HZ
BSD-1604229089.A40
1604229089
|
£410.78
|
£492.94
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209003.A127
1600209003
|
£8.13
|
£9.76
|
|
|
6 - SWITCH HOUSING
BSD-3605130029.A24
3605130029
|
-
|
|
|
|
8 - SWITCH
BSD-1607200038.A33
1607200038
|
£54.42
|
£65.30
|
|
|
9 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A527
1600703009
|
£5.58
|
£6.70
|
|
|
10 - ASSEMBLY OF SERVICE PARTS
BSD-3607030231.A13
3607030231
|
-
|
|
|
|
11 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A400
1602381001
|
-
|
|
|
|
12 - REVERSING SWITCH
BSD-1607200031.A14
1607200031
|
-
|
|
|
|
13 - FASTENING CLAMP
BSD-1601303003.A363
1601303003
|
£2.16
|
£2.59
|
|
|
16 - SPINDLE BEARING
BSD-3605806110.A3
3605806110
|
-
|
|
|
|
16/2 - NEEDLE BEARING
BSD-1600910013.A85
1600910013
|
£5.58
|
£6.70
|
|
|
17 - COUPLING HALF
BSD-1606432013.A4
1606432013
|
-
|
|
|
|
19 - SPINDLE WITH GEAR
BSD-1606100036.A4
1606100036
|
-
|
|
|
|
19/1 - CYLINDRICAL GEAR Z=39
BSD-1606317057.A3
1606317057
|
-
|
|
|
|
19/2 - AXLE
BSD-1603520003.A4
1603520003
|
-
|
|
|
|
19/3 - ROLLER
BSD-1603100011.A5
1603100011
|
-
|
|
|
|
19/4 - RETAINING SNAP RING
BSD-1600209007.A3
1600209007
|
-
|
|
|
|
20 - COMPRESSION SPRING
BSD-1604619008.A7
1604619008
|
-
|
|
|
|
21 - PLAIN WASHER
BSD-1600101011.A4
1600101011
|
-
|
|
|
|
22 - BUSHING
BSD-1600300010.A7
1600300010
|
-
|
|
|
|
23 - ROUND NUT
BSD-1603345000.A1
1603345000
|
-
|
|
|
|
24 - SHIM 0.5 MM
BSD-1600100631.A358
1600100631
|
£1.75
|
£2.10
|
|
|
25 - SPINDLE WITH GEAR Z=16/29
BSD-1606328065.A1
1606328065
|
-
|
|
|
|
27 - BEARING SLEEVE
BSD-1600460012.A4
1600460012
|
-
|
|
|
|
28 - SEALING DISK
BSD-1600110005.A4
1600110005
|
-
|
|
|
|
29 - COUPLING HALF
BSD-1606455023.A1
1606455023
|
-
|
|
|
|
30 - COMPRESSION SPRING
BSD-1604616012.A3
1604616012
|
-
|
|
|
|
31 - PRESSURE SPINDLE
BSD-1603219019.A6
1603219019
|
-
|
|
|
|
32 - PROTECTION SLEEVE
BSD-1600328001.A3
1600328001
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1604616006.A18
1604616006
|
£7.36
|
£8.83
|
|
|
34 - THRUST RING
BSD-1600200000.A4
1600200000
|
-
|
|
|
|
35 - NAMEPLATE
BSD-3601106053.A397
3601106053
|
£5.30
|
£6.36
|
|
|
36 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A374
3603133001
|
£2.61
|
£3.13
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A32
2910141158
|
£1.75
|
£2.10
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A36
2910141164
|
£2.16
|
£2.59
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A301
2910021116
|
£2.16
|
£2.59
|
|
|
40 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A794
2910211021
|
£1.75
|
£2.10
|
|
|
41 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x60-8.8
BSD-2910141178.A53
2910141178
|
-
|
|
|
|
42 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A162
2910141166
|
£1.75
|
£2.10
|
|
|
43 - PAN HEAD SCREW DIN 85-MS-M 4x12
BSD-2910110122.A163
2910110122
|
£1.75
|
£2.10
|
|
|
44 - BALL DIN 5401-6 G28
BSD-1903230011.A212
1903230011
|
£2.61
|
£3.13
|
|
|
45 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A209
1903230007
|
£1.75
|
£2.10
|
|
|
46 - SLOTTED ROUND NUT DIN 546-M4x3.5
BSD-2915161006.A8
2915161006
|
-
|
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM3x4-5.8
BSD-2910011046.A12
2910011046
|
-
|
|
|
|
48 - SPRING WASHER dia4.2 MM
BSD-3600150006.A663
3600150006
|
£2.61
|
£3.13
|
|
|
49 - PLAIN WASHER DIN 433-4.3-ST
BSD-2916012009.A4
2916012009
|
-
|
|
|
|
50 - RETAINING RING
BSD-1600116001.A11
1600116001
|
-
|
|
|
|
51 - CLAMPING SADDLE
BSD-3601321001.A408
3601321001
|
£3.72
|
£4.47
|
|
|
54 - END SPLICE
BSD-3604477009.A272
3604477009
|
£2.61
|
£3.13
|
|
|
55 - END SPLICE DIN 46 228-A2.5-7
BSD-1900452003.A104
1900452003
|
£2.61
|
£3.13
|
|
|
56 - ROTOR WITHOUT WINDING
BSD-1604080082.A8
1604080082
|
-
|
|
|
|
57 - CONICAL SPRING WASHER
BSD-1600501025.A69
1600501025
|
£33.74
|
£40.49
|
|
|
58 - SEALING DISK
BSD-1600108030.A5
1600108030
|
£3.72
|
£4.47
|
|
|
59 - BEARING HOUSING
BSD-3605820050.A4
3605820050
|
-
|
|
|
|
59/2 - NEEDLE BEARING
BSD-1600910013.A86
1600910013
|
£5.58
|
£6.70
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A264
2910021125
|
£1.75
|
£2.10
|
|
|
62 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A393
1900905121
|
£18.96
|
£22.75
|
|
|
62 - GROOVE BALL BEARING 12x28x8
BSD-2600905013.A22
2600905013
|
-
|
|
|
|
63 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A15
1610900025
|
£16.41
|
£19.69
|
|
|
64 - CABLE CLIP
BSD-3601025001.A4
3601025001
|
-
|
|
|
|
66 - SET SCREW
BSD-1603402002.A97
1603402002
|
£1.75
|
£2.10
|
|
|
69 - O-RING 22.0x1.5 MM
BSD-3600210016.A41
3600210016
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1072
3601119236
|
£3.72
|
£4.47
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A687
1602025030
|
£18.96
|
£22.75
|
|
|
651 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A161
2603101035
|
£2.80
|
£3.36
|
|
|
652 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A635
2607950511
|
£4.26
|
£5.11
|
|
|
800 - HANDLE
BSD-3605133009.A3
3605133009
|
£30.28
|
£36.33
|
|
|
801 - MOTOR HOUSING
BSD-3605102040.A95
3605102040
|
£218.41
|
£262.09
|
|
|
850 - ASSEMBLY OF SERVICE PARTS
BSD-3607030231.A15
3607030231
|
-
|
|
|
