1 - MOTOR HOUSING
BSD-3600760097.A3
3600760097
|
£70.24
|
£84.29
|
|
|
2 - STATOR 120W
BSD-3604090058.A22
3604090058
|
£135.25
|
£162.30
|
|
|
3 - ROTOR
BSD-3604220087.A4
3604220087
|
£102.57
|
£123.08
|
|
|
5 - BEARING FLANGE
BSD-3605700111.A4
3605700111
|
£40.80
|
£48.96
|
|
|
6 - GROOVE BALL BEARING 7x19x6
BSD-1900905044.A139
1900905044
|
£7.36
|
£8.83
|
|
|
7 - BEARING FLANGE
BSD-3605700112.A20
3605700112
|
£48.38
|
£58.06
|
|
|
8 - GROOVE BALL BEARING 7x14x5
BSD-1900905030.A64
1900905030
|
£33.74
|
£40.49
|
|
|
26 - PINION Z=15
BSD-3606300015.A17
3606300015
|
-
|
|
|
|
27 - STOP DISC
BSD-3600101008.A5
3600101008
|
£1.75
|
£2.10
|
|
|
28 - RING GEAR Z=42/54
BSD-3606334083.A8
3606334083
|
£21.52
|
£25.83
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337181.A11
3606337181
|
£48.38
|
£58.06
|
|
|
30 - SPACER RING
BSD-3600209013.A49
3600209013
|
£5.58
|
£6.70
|
|
|
31 - CYLINDRICAL GEAR Z=13
BSD-3606316010.A13
3606316010
|
-
|
|
|
|
32 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A158
3600913000
|
£4.26
|
£5.11
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A295
3603201000
|
£1.75
|
£2.10
|
|
|
35 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A98
1903201042
|
£2.16
|
£2.59
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337191.A8
3606337191
|
£63.50
|
£76.20
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316114.A78
3606316114
|
£13.12
|
£15.75
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905023.A46
3600905023
|
£21.52
|
£25.83
|
|
|
43 - SPRING RETAINING RING
BSD-3600118006.A42
3600118006
|
£2.61
|
£3.13
|
|
|
53 - O-RING
BSD-3600210092.A38
3600210092
|
£2.16
|
£2.59
|
|
|
54 - COMPRESSION SPRING
BSD-3604611017.A66
3604611017
|
£2.61
|
£3.13
|
|
|
56 - VALVE HOUSING
BSD-3605190180.A4
3605190180
|
£40.80
|
£48.96
|
|
|
58 - O-RING 4.3x2.4 MM
BSD-3600210084.A34
3600210084
|
£2.61
|
£3.13
|
|
|
60 - STRAINER
BSD-3600002000.A24
3600002000
|
£3.72
|
£4.47
|
|
|
61 - O-RING 9.0x1.5 MM
BSD-2600210021.A107
2600210021
|
£1.75
|
£2.10
|
|
|
62 - FITTING
BSD-3603458016.A26
3603458016
|
£11.30
|
£13.56
|
|
|
63 - STRAIGHT PIN 75 MM
BSD-3603201006.A22
3603201006
|
£3.72
|
£4.47
|
|
|
65 - STRAIGHT PIN
BSD-3603201001.A4
3603201001
|
£4.26
|
£5.11
|
|
|
66 - STRAIGHT PIN
BSD-3604710044.A22
3604710044
|
£8.67
|
£10.41
|
|
|
68 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A50
1903230014
|
£1.75
|
£2.10
|
|
|
71 - CONTROL PISTON
BSD-3608750038.A16
3608750038
|
£23.86
|
£28.63
|
|
|
72 - COILED SPRING PIN DIN 7343-1.5x10
BSD-2917800016.A73
2917800016
|
£1.75
|
£2.10
|
|
|
73 - VALVE BUSHING
BSD-3600340008.A46
3600340008
|
£45.67
|
£54.80
|
|
|
74 - COMPRESSION SPRING
BSD-3604611007.A23
3604611007
|
£2.16
|
£2.59
|
|
|
75 - STRAIGHT PIN DIN6325-2M6X6
BSD-2917550034.A51
2917550034
|
£1.75
|
£2.10
|
|
|
76 - O-RING
BSD-3600210094.A67
3600210094
|
£2.80
|
£3.36
|
|
|
77 - CONTROL LEVER
BSD-3601902007.A12
3601902007
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A115
2917700040
|
£2.80
|
£3.36
|
|
|
79 - O-RING
BSD-3600210093.A6
3600210093
|
£1.75
|
£2.10
|
|
|
82 - O-RING 26.0x1.0 MM
BSD-3600210056.A35
3600210056
|
£1.75
|
£2.10
|
|
|
83 - CONTROL PIN
BSD-3608750048.A39
3608750048
|
£5.30
|
£6.36
|
|
|
85 - O-RING 4.0x1.0 MM
BSD-3600210015.A31
3600210015
|
£3.72
|
£4.47
|
|
|
86 - BUSHING
BSD-3600300064.A6
3600300064
|
£10.10
|
£12.12
|
|
|
87 - SILENCER
BSD-3601010010.A57
3601010010
|
£2.16
|
£2.59
|
|
|
88 - SILENCER
BSD-3601010037.A72
3601010037
|
£11.30
|
£13.56
|
|
|
89 - SILENCER
BSD-3601010044.A4
3601010044
|
£7.36
|
£8.83
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A662
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601119055.A132
3601119055
|
£3.72
|
£4.47
|
|
|
98 - STICKER
BSD-3601110204.A53
3601110204
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601110574.A69
3601110574
|
£2.61
|
£3.13
|
|
|
100 - HOUSING
BSD-3605125056.A8
3605125056
|
£59.53
|
£71.44
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445043.A98
3606445043
|
£102.57
|
£123.08
|
|
|
102 - OUTPUT SHAFT
BSD-3603124022.A22
3603124022
|
£102.57
|
£123.08
|
|
|
106 - COMPRESSION SPRING
BSD-3604610011.A50
3604610011
|
£2.80
|
£3.36
|
|
|
107 - COMPRESSION SPRING
BSD-3604615004.A53
3604615004
|
£1.75
|
£2.10
|
|
|
108 - COMPRESSION SPRING
BSD-3604610057.A32
3604610057
|
£2.16
|
£2.59
|
|
|
109 - COMPRESSION SPRING
BSD-3604619003.A97
3604619003
|
£5.58
|
£6.70
|
|
|
110 - RETAINING RING
BSD-3600224053.A86
3600224053
|
£1.75
|
£2.10
|
|
|
113 - CLAMP BUSHING
BSD-3600499023.A126
3600499023
|
£18.96
|
£22.75
|
|
|
114 - PLAIN BEARING
BSD-3600921001.A67
3600921001
|
£10.10
|
£12.12
|
|
|
115 - SEALING PLATE
BSD-3601023011.A180
3601023011
|
£2.61
|
£3.13
|
|
|
116 - SETTING RING
BSD-3600134014.A129
3600134014
|
£31.64
|
£37.97
|
|
|
117 - PLAIN WASHER 0.5 MM
BSD-1600101023.A67
1600101023
|
£1.75
|
£2.10
|
|
|
118 - ROD
BSD-3603003005.A38
3603003005
|
£13.12
|
£15.75
|
|
|
119 - SUPPORT DISC
BSD-3600190038.A28
3600190038
|
£18.96
|
£22.75
|
|
|
120 - CATCH DISK
BSD-3603344047.A55
3603344047
|
£23.86
|
£28.63
|
|
|
124 - RING
BSD-3600250004.A35
3600250004
|
£8.67
|
£10.41
|
|
|
125 - BACKUP RING
BSD-3600202020.A70
3600202020
|
£8.67
|
£10.41
|
|
|
126 - RETAINING RING
BSD-3600224006.A142
3600224006
|
£2.80
|
£3.36
|
|
|
127 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A10
1903230006
|
£2.16
|
£2.59
|
|
|
128 - BALL 4.5 MM III DIN 5401-ST
BSD-1903230008.A21
1903230008
|
£1.75
|
£2.10
|
|
|
129 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A60
1903230003
|
£2.61
|
£3.13
|
|
|
133 - WASHER
BSD-3600190024.A28
3600190024
|
£2.16
|
£2.59
|
|
|
135 - RETAINING RING
BSD-3600224059.A20
3600224059
|
£3.72
|
£4.47
|
|
|
136 - PLAIN WASHER
BSD-2600101513.A34
2600101513
|
£1.75
|
£2.10
|
|
|
140 - LOCKING WASHER DIN 6799-9-FSt
BSD-2916080012.A36
2916080012
|
£1.75
|
£2.10
|
|
|
141 - PROTECTION SLEEVE
BSD-3600400030.A5
3600400030
|
£7.36
|
£8.83
|
|
|
143 - O-RING 9.0x1.2 MM
BSD-3600210038.A70
3600210038
|
£2.61
|
£3.13
|
|
|
144 - BALL 2 MM III DIN 5401 ST
BSD-1903230002.A101
1903230002
|
£2.16
|
£2.59
|
|
|
145 - O-RING
BSD-3600210116.A34
3600210116
|
£2.80
|
£3.36
|
|
|
652 - HOSE FITTING
BSD-3603386066.A63
3603386066
|
£14.91
|
£17.89
|
|
|
657 - SCREWDRIVER
BSD-3607950027.A214
3607950027
|
£14.91
|
£17.89
|
|
|
701 - HOUSING
BSD-3605125058.A6
3605125058
|
£81.81
|
£98.17
|
|
|
702 - HANDLE
BSD-3600499002.A31
3600499002
|
£21.68
|
£26.01
|
|
|
706 - COMPRESSION SPRING
BSD-3604618003.A131
3604618003
|
£7.36
|
£8.83
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A69
3607950001
|
£2.80
|
£3.36
|
|
|
760 - SUSPENSION LOOP
BSD-2604720004.A48
2604720004
|
£4.26
|
£5.11
|
|
|
801 - CUTOFF COUPLING SP SET
BSD-3607031500.A4
3607031500
|
£357.27
|
£428.72
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031303.A15
3607031303
|
£410.78
|
£492.94
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031305.A3
3607031305
|
£23.86
|
£28.63
|
|
|
808 - ASSEMBLY OF SERVICE PARTS
BSD-3607031424.A2
3607031424
|
£283.50
|
£340.20
|
|
|
809 - ASSEMBLY OF SERVICE PARTS
BSD-3607031421.A0
3607031421
|
£156.22
|
£187.46
|
|
|
821 - ASSEMBLY OF SERVICE PARTS
BSD-3603201080.A38
3603201080
|
£48.38
|
£58.06
|
|
|
859 - HOLDING BELT
BSD-3604710062.A96
3604710062
|
£1.75
|
£2.10
|
|
|
882 - PARTS SET
BSD-3607031524.A8
3607031524
|
£10.10
|
£12.12
|
|
|
890 - AUXILIARY HANDLE
BSD-3607031352.A19
3607031352
|
£93.88
|
£112.65
|
|
|
891 - AIR HOSE
BSD-3607000083.A7
3607000083
|
£59.53
|
£71.44
|
|
|
899 - AIR HOSE
BSD-3607000064.A65
3607000064
|
£27.23
|
£32.68
|
|
