1 - MOTOR HOUSING
BSD-3600760015.A36
3600760015
|
£93.88
|
£112.65
|
|
|
2 - STATOR 370W
BSD-3604090002.A35
3604090002
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220002.A50
3604220002
|
£93.88
|
£112.65
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A79
3605700005
|
£54.42
|
£65.30
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A287
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700006.A38
3605700006
|
£72.18
|
£86.62
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A1304
2600905032
|
£5.30
|
£6.36
|
|
|
9 - SPACER RING
BSD-2600202013.A55
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A137
2600202014
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A29
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW
BSD-3603450000.A44
3603450000
|
£7.36
|
£8.83
|
|
|
13 - INTERMEDIATE PIECE
BSD-3602305000.A7
3602305000
|
£37.27
|
£44.72
|
|
|
14 - CYLINDRICAL GEAR
BSD-3606316100.A56
3606316100
|
£21.52
|
£25.83
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A504
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR Z=16
BSD-3606316099.A73
3606316099
|
£21.68
|
£26.01
|
|
|
26 - PINION Z=23
BSD-3606300001.A24
3606300001
|
£27.31
|
£32.77
|
|
|
27 - STOP DISC
BSD-3600101001.A27
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A148
3606334000
|
£102.57
|
£123.08
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337001.A2
3606337001
|
-
|
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A125
3603201000
|
£1.75
|
£2.10
|
|
|
34 - SHIM WASHER
BSD-3600103002.A148
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A158
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A12
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337005.A28
3606337005
|
£120.11
|
£144.13
|
|
|
41 - GROOVE BALL BEARING 12x32x10
BSD-1600905007.A107
1600905007
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING
BSD-3600119000.A29
3600119000
|
£10.10
|
£12.12
|
|
|
56 - VALVE BODY
BSD-3605190004.A6
3605190004
|
-
|
|
|
|
57 - SILENCER
BSD-3605190014.A19
3605190014
|
-
|
|
|
|
58 - FITTING
BSD-3603458001.A10
3603458001
|
-
|
|
|
|
59 - SINTERED-METAL BUSHING
BSD-3600521000.A11
3600521000
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A352
3600002000
|
£3.72
|
£4.47
|
|
|
61 - PLAIN WASHER
BSD-3600101003.A7
3600101003
|
-
|
|
|
|
62 - SUSPENSION LOOP
BSD-2604720004.A97
2604720004
|
£4.26
|
£5.11
|
|
|
63 - STRAIGHT PIN
BSD-3604710002.A15
3604710002
|
£10.10
|
£12.12
|
|
|
64 - UNLOADING VALVE
BSD-3603201021.A4
3603201021
|
-
|
|
|
|
65 - STRAIGHT PIN 3 H 8x6 DIN 7
BSD-2917500074.A11
2917500074
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3604710000.A59
3604710000
|
£5.58
|
£6.70
|
|
|
67 - GUIDE BUSHING
BSD-3600320000.A6
3600320000
|
-
|
|
|
|
69 - COMPRESSION SPRING
BSD-3604643002.A50
3604643002
|
£2.80
|
£3.36
|
|
|
70 - ASSEMBLY OF SERVICE PARTS
BSD-3607031094.A4
3607031094
|
-
|
|
|
|
71 - CONTROL PISTON
BSD-3608750000.A9
3608750000
|
-
|
|
|
|
72 - SLOTTED SPRING PIN 2x12 DIN 1481
BSD-2917760037.A8
2917760037
|
-
|
|
|
|
73 - PUSH-BUTTON
BSD-3603122000.A14
3603122000
|
-
|
|
|
|
74 - COMPRESSION SPRING
BSD-3604611002.A43
3604611002
|
£2.80
|
£3.36
|
|
|
90 - SILENCER
BSD-3603462000.A34
3603462000
|
£16.41
|
£19.69
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A309
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A68
1601110481
|
£2.16
|
£2.59
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A72
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1977
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125019.A17
3605125019
|
-
|
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445031.A2
3606445031
|
£218.41
|
£262.09
|
|
|
102 - DRIVE SHAFT
BSD-3606122008.A74
3606122008
|
£120.11
|
£144.13
|
|
|
103 - SLOTTED SPRING PIN 2x5 DIN 1481
BSD-2917760033.A80
2917760033
|
£1.75
|
£2.10
|
|
|
106 - COMPRESSION SPRING
BSD-3604615001.A50
3604615001
|
£2.61
|
£3.13
|
|
|
107 - COMPRESSION SPRING
BSD-3604610003.A40
3604610003
|
£3.72
|
£4.47
|
|
|
108 - COMPRESSION SPRING
BSD-3604610002.A107
3604610002
|
£3.72
|
£4.47
|
|
|
109 - COMPRESSION SPRING dia 4 MM
BSD-3604619000.A56
3604619000
|
£7.36
|
£8.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A122
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A182
1903230007
|
£1.75
|
£2.10
|
|
|
112 - CLAMPING SLEEVE
BSD-3600311015.A25
3600311015
|
£31.64
|
£37.97
|
|
|
114 - BUSHING
BSD-3600202003.A9
3600202003
|
-
|
|
|
|
115 - SEALING PLATE
BSD-3600001000.A27
3600001000
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A15
3600134000
|
£2.80
|
£3.36
|
|
|
118 - LOCKING BOLT
BSD-3603150203.A82
3603150203
|
£45.67
|
£54.80
|
|
|
119 - COUPLING PLATE
BSD-3600114001.A25
3600114001
|
£18.96
|
£22.75
|
|
|
120 - ROUND NUT
BSD-3603301004.A35
3603301004
|
£21.68
|
£26.01
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A97
3600921000
|
£6.52
|
£7.83
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A139
3600101002
|
£2.16
|
£2.59
|
|
|
125 - RETAINING RING
BSD-3600224001.A2
3600224001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A184
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A127
1903230011
|
£2.61
|
£3.13
|
|
|
132 - SCREW PLUG
BSD-3603463000.A7
3603463000
|
£2.61
|
£3.13
|
|
|
134 - PLAIN WASHER
BSD-3600101055.A38
3600101055
|
£12.04
|
£14.45
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A99
2916600008
|
£2.80
|
£3.36
|
|
|
652 - HOSE FITTING
BSD-2603386002.A163
2603386002
|
£5.30
|
£6.36
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A12
3601329007
|
£4.26
|
£5.11
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A148
3603386001
|
£16.41
|
£19.69
|
|
|
704 - SUPPORT CLAMP
BSD-3608040000.A26
3608040000
|
-
|
|
|
|
705 - AUXILIARY HANDLE M14
BSD-1602025022.A995
1602025022
|
£13.41
|
£16.09
|
|
|
705 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A339
1602025030
|
£18.96
|
£22.75
|
|
|
705 - HANDLE
BSD-3600499000.A20
3600499000
|
-
|
|
|
|
706 - SILENCER
BSD-3607000073.A220
3607000073
|
£18.96
|
£22.75
|
|
|
707 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A26
1907950009
|
£21.68
|
£26.01
|
|
|
708 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A144
1907950513
|
£16.41
|
£19.69
|
|
|
713 - HEXAGON-SOCKET KEY
BSD-3607950001.A207
3607950001
|
£2.80
|
£3.36
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-3607031111.A3
3607031111
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031018.A12
3607031018
|
£410.78
|
£492.94
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A127
3607030248
|
£31.64
|
£37.97
|
|
|
821 - ASSEMBLY OF SERVICE PARTS
BSD-3607031087.A143
3607031087
|
£12.04
|
£14.45
|
|
|
855 - O-RING 10x2 MM
BSD-1900210306.A144
1900210306
|
£1.75
|
£2.10
|
|
|
856 - ASSEMBLY OF SERVICE PARTS
BSD-3607031011.A5
3607031011
|
-
|
|
|
