1 - MOTOR HOUSING
BSD-3605108025.A8
3605108025
|
-
|
|
|
|
2 - STATOR 370W
BSD-3604090003.A5
3604090003
|
£93.88
|
£112.65
|
|
|
3 - ROTOR
BSD-3604220003.A2
3604220003
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A186
3605700005
|
£54.42
|
£65.30
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A33
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700008.A3
3605700008
|
-
|
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A1702
2600905032
|
£5.30
|
£6.36
|
|
|
9 - SPACER RING
BSD-2600202013.A164
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A27
2600202014
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A205
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW DIN 933-M5x8-8.8
BSD-2911061150.A40
2911061150
|
£2.61
|
£3.13
|
|
|
14 - CYLINDRICAL GEAR
BSD-3606316100.A130
3606316100
|
£21.52
|
£25.83
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A251
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR
BSD-3606316101.A3
3606316101
|
£21.68
|
£26.01
|
|
|
26 - PINION
BSD-3606300005.A27
3606300005
|
£31.64
|
£37.97
|
|
|
27 - STOP DISC
BSD-3600101001.A131
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A29
3606334000
|
£102.57
|
£123.08
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337004.A25
3606337004
|
£93.88
|
£112.65
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A469
3603201000
|
£1.75
|
£2.10
|
|
|
34 - SHIM WASHER
BSD-3600103002.A69
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A81
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A220
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337014.A20
3606337014
|
-
|
|
|
|
41 - GROOVE BALL BEARING 12x32x10
BSD-1600905007.A37
1600905007
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING
BSD-3600119000.A89
3600119000
|
£10.10
|
£12.12
|
|
|
54 - FITTING
BSD-3603458008.A116
3603458008
|
£8.67
|
£10.41
|
|
|
56 - VALVE BODY
BSD-3605190008.A2
3605190008
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A115
3600002000
|
£3.72
|
£4.47
|
|
|
65 - O-RING 15.6x1.8 MM
BSD-3600210003.A26
3600210003
|
£1.75
|
£2.10
|
|
|
66 - STRAIGHT PIN
BSD-3604710006.A2
3604710006
|
£8.67
|
£10.41
|
|
|
67 - CONTROL LEVER
BSD-3602053001.A20
3602053001
|
£2.80
|
£3.36
|
|
|
68 - BALL dia9 MM
BSD-3603230004.A10
3603230004
|
£3.72
|
£4.47
|
|
|
69 - COMPRESSION SPRING
BSD-3604616002.A96
3604616002
|
£2.16
|
£2.59
|
|
|
71 - STRAIGHT GROOVED PIN 2.5x16 DIN 1473
BSD-2917601059.A21
2917601059
|
£1.75
|
£2.10
|
|
|
72 - STRAIGHT PIN 3M6x24 DIN 7-C35K
BSD-2917610083.A36
2917610083
|
£1.75
|
£2.10
|
|
|
73 - STRAIGHT PIN
BSD-3604710003.A71
3604710003
|
£6.52
|
£7.83
|
|
|
80 - O-RING 1.8x1.0 MM
BSD-3600210002.A59
3600210002
|
£2.61
|
£3.13
|
|
|
91 - SILENCER
BSD-3601010001.A86
3601010001
|
£2.16
|
£2.59
|
|
|
92 - FILTER SCREEN
BSD-3600002004.A109
3600002004
|
£2.80
|
£3.36
|
|
|
93 - O-RING 14.0x3.0 MM
BSD-3600210009.A56
3600210009
|
£1.32
|
£1.58
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A342
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A591
1601110481
|
£2.16
|
£2.59
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A594
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A959
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125013.A25
3605125013
|
-
|
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445030.A29
3606445030
|
£102.57
|
£123.08
|
|
|
103 - DRIVE SHAFT
BSD-3606122013.A27
3606122013
|
£81.81
|
£98.17
|
|
|
106 - COMPRESSION SPRING
BSD-3604615000.A53
3604615000
|
£1.75
|
£2.10
|
|
|
109 - COMPRESSION SPRING
BSD-3604619004.A19
3604619004
|
£6.52
|
£7.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A65
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A247
1903230003
|
£2.61
|
£3.13
|
|
|
113 - UNION NUT
BSD-3603340000.A58
3603340000
|
£4.26
|
£5.11
|
|
|
114 - BUSHING
BSD-3600322002.A1
3600322002
|
£5.30
|
£6.36
|
|
|
115 - SEALING PLATE
BSD-3600001000.A119
3600001000
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A138
3600134000
|
£2.80
|
£3.36
|
|
|
120 - ROUND NUT
BSD-3603301004.A107
3603301004
|
£21.68
|
£26.01
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A52
3600921000
|
£6.52
|
£7.83
|
|
|
123 - SUPPORT DISC
BSD-3600103004.A28
3600103004
|
£13.12
|
£15.75
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A33
3600101002
|
£2.16
|
£2.59
|
|
|
126 - LEAF SPRING
BSD-2601250001.A96
2601250001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A638
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A354
1903230011
|
£2.61
|
£3.13
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A139
2916600008
|
£2.80
|
£3.36
|
|
|
650 - SILENCER
BSD-3607000073.A53
3607000073
|
£18.96
|
£22.75
|
|
|
651 - GUIDE SLEEVE
BSD-3600329000.A40
3600329000
|
£7.36
|
£8.83
|
|
|
652 - HOSE FITTING
BSD-2603386002.A35
2603386002
|
£5.30
|
£6.36
|
|
|
653 - SILENCER
BSD-3603462000.A214
3603462000
|
£16.41
|
£19.69
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A223
3601329007
|
£4.26
|
£5.11
|
|
|
701 - GUIDE SLEEVE
BSD-3600328003.A32
3600328003
|
-
|
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A27
3603386001
|
£16.41
|
£19.69
|
|
|
704 - SUPPORT CLAMP
BSD-3608040000.A103
3608040000
|
-
|
|
|
|
705 - AUXILIARY HANDLE M14
BSD-1602025022.A1352
1602025022
|
£13.41
|
£16.09
|
|
|
705 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1417
1602025030
|
£18.96
|
£22.75
|
|
|
707 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A104
1907950009
|
£21.68
|
£26.01
|
|
|
708 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A35
1907950513
|
£16.41
|
£19.69
|
|
|
712 - HEXAGON-SOCKET KEY
BSD-3607950001.A59
3607950001
|
£2.80
|
£3.36
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-3607031115.A1
3607031115
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031023.A9
3607031023
|
-
|
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A31
3607030248
|
£31.64
|
£37.97
|
|
|
855 - O-RING 10x2 MM
BSD-1900210306.A94
1900210306
|
£1.75
|
£2.10
|
|
