1 - MOTOR HOUSING
BSD-3605108066.A19
3605108066
|
£31.64
|
£37.97
|
|
|
2 - STATOR 400W
BSD-3604090046.A19
3604090046
|
£102.57
|
£123.08
|
|
|
3 - ROTOR
BSD-3604220063.A2
3604220063
|
£93.88
|
£112.65
|
|
|
5 - BEARING FLANGE
BSD-3605700076.A78
3605700076
|
£48.38
|
£58.06
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A248
3600905039
|
£12.04
|
£14.45
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A97
1900905028
|
£33.74
|
£40.49
|
|
|
28 - RING GEAR Z=42
BSD-3606334054.A5
3606334054
|
£10.10
|
£12.12
|
|
|
31 - CYLINDRICAL GEAR Z=16
BSD-3606316075.A48
3606316075
|
£13.41
|
£16.09
|
|
|
32 - NEEDLE-ROLLER CAGE
BSD-3600913006.A55
3600913006
|
£7.36
|
£8.83
|
|
|
33 - NEEDLE ROLLER
BSD-3603201047.A65
3603201047
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.20 MM
BSD-2600100586.A20
2600100586
|
£1.75
|
£2.10
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337117.A0
3606337117
|
£68.42
|
£82.10
|
|
|
39 - CYLINDRICAL GEAR Z=16
BSD-3606316075.A49
3606316075
|
£13.41
|
£16.09
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905045.A9
3600905045
|
£16.41
|
£19.69
|
|
|
43 - STOP DISC
BSD-3600102021.A1
3600102021
|
£3.72
|
£4.47
|
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A62
2600210018
|
£3.72
|
£4.47
|
|
|
45 - GEAR HOUSING
BSD-3605125038.A19
3605125038
|
£48.38
|
£58.06
|
|
|
46 - SLOTTED SPRING PIN DIN 1481-1.5x4
BSD-2917760012.A23
2917760012
|
£1.75
|
£2.10
|
|
|
47 - SPIGOT
BSD-3600700033.A32
3600700033
|
£27.23
|
£32.68
|
|
|
48 - STOP DISC
BSD-3600101040.A49
3600101040
|
£2.16
|
£2.59
|
|
|
49 - SILENCER
BSD-3601010006.A60
3601010006
|
£1.75
|
£2.10
|
|
|
50 - RETAINING WASHER
BSD-3600101036.A52
3600101036
|
£4.26
|
£5.11
|
|
|
56 - FITTING
BSD-3603462007.A11
3603462007
|
£7.36
|
£8.83
|
|
|
57 - SEALING DISK
BSD-3600206005.A50
3600206005
|
£5.30
|
£6.36
|
|
|
60 - STRAINER
BSD-3600002006.A11
3600002006
|
£3.72
|
£4.47
|
|
|
62 - STRAINER
BSD-3600002005.A29
3600002005
|
£2.80
|
£3.36
|
|
|
63 - STRAIGHT PIN
BSD-3604710055.A19
3604710055
|
£7.36
|
£8.83
|
|
|
65 - O-RING 15x2 MM
BSD-1900210112.A16
1900210112
|
£2.61
|
£3.13
|
|
|
67 - STRAIGHT PIN
BSD-3603201048.A2
3603201048
|
£10.10
|
£12.12
|
|
|
70 - NEEDLE ROLLER
BSD-3603201058.A3
3603201058
|
£2.16
|
£2.59
|
|
|
71 - BALL
BSD-3603230013.A6
3603230013
|
£2.16
|
£2.59
|
|
|
73 - COMPRESSION SPRING
BSD-3604643014.A2
3604643014
|
£2.80
|
£3.36
|
|
|
74 - O-RING 23.0x2.0 MM
BSD-3600210032.A31
3600210032
|
£4.75
|
£5.70
|
|
|
75 - O-RING 18x2 MM
BSD-1900210315.A0
1900210315
|
£2.80
|
£3.36
|
|
|
76 - PUSH-BUTTON
BSD-1600A00HZ4.A4
1600A00HZ4
|
£3.72
|
£4.47
|
|
|
77 - PUSH-BUTTON
BSD-1600A00HZ5.A29
1600A00HZ5
|
£3.72
|
£4.47
|
|
|
79 - PILOT-VALVE BUSHING
BSD-3600313008.A0
3600313008
|
£2.80
|
£3.36
|
|
|
82 - INTERMEDIATE PIECE
BSD-3600390018.A0
3600390018
|
£5.30
|
£6.36
|
|
|
83 - COMPRESSION SPRING
BSD-3604643013.A2
3604643013
|
£2.16
|
£2.59
|
|
|
84 - CONNECTION COVER
BSD-3605500046.A2
3605500046
|
£4.26
|
£5.11
|
|
|
86 - O-RING 12.0x2.0 MM
BSD-1610210233.A25
1610210233
|
£2.80
|
£3.36
|
|
|
90 - BACKUP RING
BSD-3600221000.A2
3600221000
|
£10.10
|
£12.12
|
|
|
91 - INTERMEDIATE RING
BSD-3600209007.A0
3600209007
|
-
|
|
|
|
92 - SHIM 0.2 MM
BSD-1600101617.A63
1600101617
|
£1.75
|
£2.10
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A219
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110038.A32
3601110038
|
£5.30
|
£6.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1919
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125035.A16
3605125035
|
£16.41
|
£19.69
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445032.A43
3606445032
|
£135.25
|
£162.30
|
|
|
102 - DRIVE SHAFT
BSD-3606122008.A48
3606122008
|
£120.11
|
£144.13
|
|
|
103 - COILED SPRING PIN DIN 7343-2x5
BSD-2917800033.A39
2917800033
|
£1.75
|
£2.10
|
|
|
106 - COMPRESSION SPRING
BSD-3604615009.A27
3604615009
|
£2.16
|
£2.59
|
|
|
107 - COMPRESSION SPRING
BSD-3604610003.A38
3604610003
|
£3.72
|
£4.47
|
|
|
108 - COMPRESSION SPRING
BSD-3604610002.A116
3604610002
|
£3.72
|
£4.47
|
|
|
109 - COMPRESSION SPRING
BSD-3604619004.A30
3604619004
|
£6.52
|
£7.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A97
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A187
1903230007
|
£1.75
|
£2.10
|
|
|
113 - CLAMPING SLEEVE
BSD-3600422005.A16
3600422005
|
£8.67
|
£10.41
|
|
|
115 - SEALING PLATE
BSD-3600001000.A1
3600001000
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A3
3600134000
|
£2.80
|
£3.36
|
|
|
118 - LOCKING BOLT
BSD-3603150203.A118
3603150203
|
£45.67
|
£54.80
|
|
|
119 - COUPLING PLATE
BSD-3600114001.A2
3600114001
|
£18.96
|
£22.75
|
|
|
120 - ROUND NUT
BSD-3603301004.A0
3603301004
|
£21.68
|
£26.01
|
|
|
121 - STRAIGHT PIN 37.0 MM
BSD-3603201025.A24
3603201025
|
£5.58
|
£6.70
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A81
3600921000
|
£6.52
|
£7.83
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A127
3600101002
|
£2.16
|
£2.59
|
|
|
126 - RETAINING RING
BSD-3600224006.A41
3600224006
|
£2.80
|
£3.36
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A205
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A111
1903230011
|
£2.61
|
£3.13
|
|
|
129 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A78
1903230004
|
£2.16
|
£2.59
|
|
|
132 - SCREW PLUG
BSD-3603463001.A21
3603463001
|
£2.16
|
£2.59
|
|
|
133 - KNURLED NUT
BSD-3603340019.A16
3603340019
|
£16.41
|
£19.69
|
|
|
134 - STOP DISC dia11.15xdia12.85 MM
BSD-3600101039.A0
3600101039
|
£2.16
|
£2.59
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A52
2916600008
|
£2.80
|
£3.36
|
|
|
650 - SILENCER
BSD-3603462000.A4
3603462000
|
£16.41
|
£19.69
|
|
|
652 - HOSE FITTING
BSD-2603386002.A137
2603386002
|
£5.30
|
£6.36
|
|
|
653 - ANGLE PIECE
BSD-3601329007.A54
3601329007
|
£4.26
|
£5.11
|
|
|
654 - AUXILIARY HANDLE
BSD-3602025009.A42
3602025009
|
£18.96
|
£22.75
|
|
|
701 - SCREW CAP
BSD-3600508014.A16
3600508014
|
£10.10
|
£12.12
|
|
|
702 - UNION NUT
BSD-3603313002.A16
3603313002
|
£16.41
|
£19.69
|
|
|
703 - COMPRESSION SPRING
BSD-3604615000.A0
3604615000
|
£1.75
|
£2.10
|
|
|
704 - GUIDE SLEEVE
BSD-3600329000.A101
3600329000
|
£7.36
|
£8.83
|
|
|
755 - SILENCER
BSD-3607000073.A237
3607000073
|
£18.96
|
£22.75
|
|
|
800 - ASSEMBLY OF SERVICE PARTS
BSD-3607030062.A16
3607030062
|
£37.27
|
£44.72
|
|
|
811 - ASSEMBLY OF SERVICE PARTS
BSD-3607030100.A2
3607030100
|
£357.27
|
£428.72
|
|
|
815 - ROTOR LAMELLA
BSD-3607030030.A22
3607030030
|
£31.64
|
£37.97
|
|
|
821 - CONTROL PIN
BSD-3607030083.A1
3607030083
|
£33.74
|
£40.49
|
|
|
822 - ASSEMBLY OF SERVICE PARTS
BSD-3607030084.A1
3607030084
|
-
|
|
|
|
825 - ASSEMBLY OF SERVICE PARTS
BSD-3607030064.A0
3607030064
|
£14.91
|
£17.89
|
|
|
827 - PLANETARY-GEAR CARRIER
BSD-3606337112.A0
3606337112
|
£81.81
|
£98.17
|
|
|
844 - ASSEMBLY OF SERVICE PARTS
BSD-3607030101.A0
3607030101
|
£21.68
|
£26.01
|
|
|
868 - VALVE CONE
BSD-3608750042.A10
3608750042
|
£6.52
|
£7.83
|
|
