1 - MOTOR HOUSING
BSD-3605108072.A0
3605108072
|
£31.64
|
£37.97
|
|
|
2 - STATOR 320-400W
BSD-3604090044.A1
3604090044
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220058.A10
3604220058
|
£81.81
|
£98.17
|
|
|
5 - BEARING FLANGE
BSD-3605700076.A18
3605700076
|
£48.38
|
£58.06
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A64
3600905039
|
£12.04
|
£14.45
|
|
|
8 - GROOVE BALL BEARING 7x17x5
BSD-1900905028.A209
1900905028
|
£33.74
|
£40.49
|
|
|
27 - PINION Z=12
BSD-3606300071.A3
3606300071
|
£33.74
|
£40.49
|
|
|
28 - RING GEAR Z=42
BSD-3606334054.A12
3606334054
|
£10.10
|
£12.12
|
|
|
29 - CARRIER
BSD-3606337115.A8
3606337115
|
£31.64
|
£37.97
|
|
|
31 - CYLINDRICAL GEAR Z=16
BSD-3606316075.A0
3606316075
|
£13.41
|
£16.09
|
|
|
32 - NEEDLE-ROLLER CAGE
BSD-3600913006.A6
3600913006
|
£7.36
|
£8.83
|
|
|
33 - NEEDLE ROLLER
BSD-3603201047.A8
3603201047
|
£1.75
|
£2.10
|
|
|
34 - SHIM 0.20 MM
BSD-2600100586.A67
2600100586
|
£1.75
|
£2.10
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337118.A9
3606337118
|
£68.42
|
£82.10
|
|
|
39 - CYLINDRICAL GEAR
BSD-3606316116.A11
3606316116
|
£21.68
|
£26.01
|
|
|
41 - GROOVE BALL BEARING
BSD-3600905045.A40
3600905045
|
£16.41
|
£19.69
|
|
|
42 - NON-WOVEN FABRIC
BSD-3601010028.A0
3601010028
|
-
|
|
|
|
43 - STOP DISC
BSD-3600102021.A24
3600102021
|
£3.72
|
£4.47
|
|
|
44 - O-RING 26.0x1.5 MM
BSD-2600210018.A96
2600210018
|
£3.72
|
£4.47
|
|
|
45 - GEAR HOUSING
BSD-3605125038.A18
3605125038
|
£48.38
|
£58.06
|
|
|
47 - SPIGOT
BSD-3600700032.A29
3600700032
|
£21.68
|
£26.01
|
|
|
48 - STOP DISC
BSD-3600101040.A10
3600101040
|
£2.16
|
£2.59
|
|
|
49 - SILENCER
BSD-3601010006.A19
3601010006
|
£1.75
|
£2.10
|
|
|
50 - RETAINING WASHER
BSD-3600101036.A10
3600101036
|
£4.26
|
£5.11
|
|
|
51 - UNION NUT
BSD-3603313001.A18
3603313001
|
£14.91
|
£17.89
|
|
|
53 - NEEDLE ROLLER
BSD-3603201050.A6
3603201050
|
£1.75
|
£2.10
|
|
|
54 - COMPRESSION SPRING
BSD-3604611006.A175
3604611006
|
£2.16
|
£2.59
|
|
|
55 - VALVE CONE
BSD-3603132000.A2
3603132000
|
£2.80
|
£3.36
|
|
|
56 - FITTING
BSD-3603458008.A104
3603458008
|
£8.67
|
£10.41
|
|
|
57 - SEALING DISK
BSD-3600206006.A36
3600206006
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A105
3600002000
|
£3.72
|
£4.47
|
|
|
61 - O-RING 10x2 MM
BSD-1900210306.A42
1900210306
|
£1.75
|
£2.10
|
|
|
62 - SUSPENSION LOOP
BSD-3604720004.A30
3604720004
|
£2.80
|
£3.36
|
|
|
64 - PLAIN WASHER DIN 125-A3.2-ST
BSD-2916011006.A182
2916011006
|
£1.75
|
£2.10
|
|
|
65 - O-RING 2.4x1.9 MM
BSD-2600210007.A2
2600210007
|
£2.16
|
£2.59
|
|
|
66 - O-RING 16x1.25 MM
BSD-3600210036.A8
3600210036
|
£2.16
|
£2.59
|
|
|
68 - BALL DIN 5401-9.5MM-III-ST
BSD-1903230528.A80
1903230528
|
£1.75
|
£2.10
|
|
|
69 - COMPRESSION SPRING
BSD-3604616008.A27
3604616008
|
-
|
|
|
|
70 - SILENCER
BSD-3600105002.A57
3600105002
|
£10.10
|
£12.12
|
|
|
71 - CONTROL PISTON
BSD-3608750023.A2
3608750023
|
£45.67
|
£54.80
|
|
|
72 - THREADED RING
BSD-3603344023.A6
3603344023
|
£31.64
|
£37.97
|
|
|
73 - VALVE BUSHING
BSD-3600340005.A0
3600340005
|
£54.42
|
£65.30
|
|
|
74 - COMPRESSION SPRING
BSD-3604611006.A177
3604611006
|
£2.16
|
£2.59
|
|
|
75 - RETAINING SNAP RING
BSD-3600202012.A1
3600202012
|
£10.10
|
£12.12
|
|
|
76 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A385
2910611006
|
£1.75
|
£2.10
|
|
|
77 - CONTROL LEVER
BSD-3601902001.A13
3601902001
|
£6.52
|
£7.83
|
|
|
78 - GROOVED PIN DIN 1475-2x18-ST
BSD-2917700040.A137
2917700040
|
£2.80
|
£3.36
|
|
|
79 - O-RING 9.0x1.2 MM
BSD-3600210038.A115
3600210038
|
£2.61
|
£3.13
|
|
|
80 - SEALING PLATE
BSD-3600054004.A3
3600054004
|
£6.52
|
£7.83
|
|
|
81 - O-RING 8.0x1.5 MM
BSD-1900210103.A30
1900210103
|
£2.80
|
£3.36
|
|
|
82 - INTERMEDIATE PIECE
BSD-3608750027.A27
3608750027
|
£14.91
|
£17.89
|
|
|
91 - INTERMEDIATE RING
BSD-3600209005.A0
3600209005
|
£6.52
|
£7.83
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A468
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110039.A32
3601110039
|
£5.30
|
£6.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A858
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125035.A1
3605125035
|
£16.41
|
£19.69
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445032.A6
3606445032
|
£135.25
|
£162.30
|
|
|
102 - DRIVE SHAFT
BSD-3606122013.A19
3606122013
|
£81.81
|
£98.17
|
|
|
103 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A170
1903230003
|
£2.61
|
£3.13
|
|
|
106 - COMPRESSION SPRING
BSD-3604615009.A2
3604615009
|
£2.16
|
£2.59
|
|
|
109 - COMPRESSION SPRING dia 4 MM
BSD-3604619000.A1
3604619000
|
£7.36
|
£8.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A27
3604601001
|
£2.16
|
£2.59
|
|
|
113 - CLAMPING SLEEVE
BSD-3600422005.A3
3600422005
|
£8.67
|
£10.41
|
|
|
115 - SEALING PLATE
BSD-3609992353.A2
3609992353
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A95
3600134000
|
£2.80
|
£3.36
|
|
|
119 - SUPPORT DISC
BSD-3600103004.A20
3600103004
|
£13.12
|
£15.75
|
|
|
120 - ROUND NUT
BSD-3603301004.A86
3603301004
|
£21.68
|
£26.01
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A7
3600921000
|
£6.52
|
£7.83
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A56
3600101002
|
£2.16
|
£2.59
|
|
|
126 - RETAINING RING
BSD-3600224006.A146
3600224006
|
£2.80
|
£3.36
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A626
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A320
1903230011
|
£2.61
|
£3.13
|
|
|
129 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A328
1903230004
|
£2.16
|
£2.59
|
|
|
133 - KNURLED NUT
BSD-3603340019.A0
3603340019
|
£16.41
|
£19.69
|
|
|
134 - STOP DISC dia11.15xdia12.85 MM
BSD-3600101039.A19
3600101039
|
£2.16
|
£2.59
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A145
2916600008
|
£2.80
|
£3.36
|
|
|
653 - ANGLE PIECE
BSD-3601329007.A216
3601329007
|
£4.26
|
£5.11
|
|
|
701 - SCREW CAP
BSD-3600508014.A1
3600508014
|
£10.10
|
£12.12
|
|
|
702 - UNION NUT
BSD-3603313002.A15
3603313002
|
£16.41
|
£19.69
|
|
|
703 - COMPRESSION SPRING
BSD-3604615000.A94
3604615000
|
£1.75
|
£2.10
|
|
|
704 - GUIDE SLEEVE
BSD-3600329000.A2
3600329000
|
£7.36
|
£8.83
|
|
|
705 - AIR HOSE SET
BSD-3607030024.A17
3607030024
|
£37.72
|
£45.27
|
|
|
752 - HOSE FITTING
BSD-2603386002.A62
2603386002
|
£5.30
|
£6.36
|
|
|
754 - AUXILIARY HANDLE
BSD-3602025009.A0
3602025009
|
£18.96
|
£22.75
|
|
|
800 - PLANETARY-GEAR CARRIER
BSD-3606337111.A12
3606337111
|
£68.42
|
£82.10
|
|
|
811 - ASSEMBLY OF SERVICE PARTS
BSD-3607030066.A0
3607030066
|
-
|
|
|
|
813 - ASSEMBLY OF SERVICE PARTS
BSD-3607030057.A6
3607030057
|
£27.23
|
£32.68
|
|
|
815 - ROTOR LAMELLA
BSD-3607030030.A51
3607030030
|
£31.64
|
£37.97
|
|
|
817 - CONTROL LEVER
BSD-3607030032.A7
3607030032
|
£13.12
|
£15.75
|
|
|
818 - ASSEMBLY OF SERVICE PARTS
BSD-3607030033.A23
3607030033
|
£31.64
|
£37.97
|
|
|
822 - ASSEMBLY OF SERVICE PARTS
BSD-3607030070.A0
3607030070
|
£306.65
|
£367.98
|
|
|
823 - ASSEMBLY OF SERVICE PARTS
BSD-3607030062.A12
3607030062
|
£37.27
|
£44.72
|
|
|
825 - ASSEMBLY OF SERVICE PARTS
BSD-3607030064.A4
3607030064
|
£14.91
|
£17.89
|
|
|
859 - HOLDING BELT
BSD-3604710062.A77
3604710062
|
£1.75
|
£2.10
|
|
|
899 - AIR HOSE
BSD-3607000027.A26
3607000027
|
£33.74
|
£40.49
|
|
