1 - HOUSING SECTION
BSD-2605104227.A0
2605104227
|
£16.74
|
£20.09
|
|
|
4 - ON-OFF SWITCH
BSD-2607200196.A14
2607200196
|
£11.78
|
£14.13
|
|
|
9 - STICKER
BSD-2601110816.A3
2601110816
|
-
|
|
|
|
25 - BEARING HOUSING
BSD-2605806394.A7
2605806394
|
£27.31
|
£32.77
|
|
|
26 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A359
2603490023
|
£1.75
|
£2.10
|
|
|
28 - DRIVER DISC
BSD-2606440000.A4
2606440000
|
£3.72
|
£4.47
|
|
|
29 - PAN HEAD SCREW
BSD-2603490000.A4
2603490000
|
£11.78
|
£14.13
|
|
|
30 - BLADE HOLDER
BSD-2608042013.A5
2608042013
|
-
|
|
|
|
32 - ROUND-HEAD SCREW
BSD-2603430002.A2
2603430002
|
£1.95
|
£2.34
|
|
|
33 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A128
3600905039
|
£12.04
|
£14.45
|
|
|
34 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A6
2916660008
|
£2.16
|
£2.59
|
|
|
35 - CYLINDRICAL GEAR Z=33
BSD-2606329001.A4
2606329001
|
-
|
|
|
|
38 - OUTPUT SHAFT
BSD-2603124043.A0
2603124043
|
-
|
|
|
|
39 - SCREW 4x16
BSD-2603490022.A2433
2603490022
|
£1.75
|
£2.10
|
|
|
40 - CONTACT RETAINER
BSD-2608018003.A4
2608018003
|
£2.16
|
£2.59
|
|
|
41 - CONTACT RETAINER
BSD-2608018001.A10
2608018001
|
£1.75
|
£2.10
|
|
|
42 - ADJUSTING SLIDE
BSD-2601099028.A5
2601099028
|
£2.52
|
£3.02
|
|
|
43 - SWITCH HANDLE
BSD-1602026060.A4
1602026060
|
£2.33
|
£2.80
|
|
|
44 - CABLE
BSD-2604412019.A5
2604412019
|
-
|
|
|
|
45 - CABLE
BSD-2604412020.A6
2604412020
|
-
|
|
|
|
46 - CONNECTING CABLE L = 52 MM
BSD-2604412021.A5
2604412021
|
£1.32
|
£1.58
|
|
|
48 - CONTACT SPRING
BSD-2601324012.A154
2601324012
|
£1.75
|
£2.10
|
|
|
49 - COMPRESSION SPRING
BSD-2604616003.A5
2604616003
|
£1.75
|
£2.10
|
|
|
50 - LUBRICATING FELT
BSD-2603212001.A3
2603212001
|
£1.32
|
£1.58
|
|
|
51 - FAN
BSD-2606610052.A3
2606610052
|
-
|
|
|
|
52 - GROOVE BALL BEARING 6x19x6
BSD-1900905019.A264
1900905019
|
£14.91
|
£17.89
|
|
|
53 - RUBBER BUFFER
BSD-1603100036.A45
1603100036
|
£1.75
|
£2.10
|
|
|
54 - SINTERED-METAL BUSHING 4x8x4 MM
BSD-1900301403.A0
1900301403
|
-
|
|
|
|
55 - DRIVE SHAFT
BSD-2606338001.A3
2606338001
|
-
|
|
|
|
58 - HOLDING SPRING dia8.7 MM
BSD-2601251002.A6
2601251002
|
-
|
|
|
|
62 - COMPRESSION SPRING
BSD-2604610024.A6
2604610024
|
-
|
|
|
|
63 - COUNTERSUNK-HEAD SCREW DIN 7991-M4x8-8.8
BSD-2910541118.A5
2910541118
|
£2.80
|
£3.36
|
|
|
64 - PROTECTING COVER
BSD-2605510057.A1
2605510057
|
£1.95
|
£2.34
|
|
|
65 - SET SCREW DIN 551-M4x10-5.8
BSD-2912031120.A3
2912031120
|
£1.32
|
£1.58
|
|
|
66 - SET SCREW DIN 551-M4x18-5.8
BSD-2912031128.A5
2912031128
|
£1.75
|
£2.10
|
|
|
67 - KNURLED NUT DIN 466-M4x5MM
BSD-2915111004.A6
2915111004
|
£5.87
|
£7.04
|
|
|
68 - PINION Z=11
BSD-2606316112.A215
2606316112
|
£4.26
|
£5.11
|
|
|
73 - SPACER BUSHING
BSD-2600320001.A3
2600320001
|
£3.72
|
£4.47
|
|
|
74 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A130
2603490025
|
£1.75
|
£2.10
|
|
|
75 - STICKER
BSD-2601110461.A84
2601110461
|
-
|
|
|
|
76 - GUARD PLATE
BSD-2605510058.A7
2605510058
|
£7.78
|
£9.33
|
|
|
730 - SLIDE-IN ACCU PACKAGE 7.2V. 1.4Ah. NiCd
BSD-2607300001.A40
2607300001
|
-
|
|
|
|
755 - STRIP CUTTER
BSD-2607000087.A5
2607000087
|
-
|
|
|
|
756 - EDGE CUTTER
BSD-2607000088.A3
2607000088
|
-
|
|
|
|
802 - DC MOTOR 7.2V
BSD-2607022903.A0
2607022903
|
-
|
|
|
|
827 - UPPER BLADE
BSD-2608635126.A2
2608635126
|
£34.16
|
£40.99
|
|
|
831 - LOWER BLADE
BSD-2608635125.A7
2608635125
|
£20.18
|
£24.22
|
|
|
836 - PARTS SET
BSD-2607001084.A7
2607001084
|
£7.36
|
£8.83
|
|
|
899 - CORDLESS FABRIC SHEAR
BSD-0601925023.A5
0601925023
|
-
|
|
|
|
899 - CORDLESS FABRIC SHEAR
BSD-0601925061.A0
0601925061
|
-
|
|
|
