2 - FIELD
BSD-2604220722.A2
2604220722
|
£23.86
|
£28.63
|
|
|
4 - SWITCH
BSD-1617200077.A27
1617200077
|
£33.74
|
£40.49
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460049.A11
1614460049
|
-
|
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A304
2600703018
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-1611035005.A160
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110628.A0
1611110628
|
£2.33
|
£2.80
|
|
|
10 - REFERENCE PLATE
BSD-1611110632.A3
1611110632
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328026.A40
1617328026
|
£7.36
|
£8.83
|
|
|
13 - BALL BEARING
BSD-1610900037.A7
1610900037
|
£2.61
|
£3.13
|
|
|
16 - BRUSH HOLDER
BSD-1617000343.A55
1617000343
|
£11.30
|
£13.56
|
|
|
22 - CYLINDRICAL GEAR Z=50
BSD-1616317602.A34
1616317602
|
£12.04
|
£14.45
|
|
|
24 - TOOTHED SHAFT Z=3/9
BSD-1617000518.A73
1617000518
|
£40.80
|
£48.96
|
|
|
25 - SHIM WASHER
BSD-1610121002.A1
1610121002
|
£1.75
|
£2.10
|
|
|
26 - HAMMER PISTON
BSD-1618700062.A31
1618700062
|
£14.91
|
£17.89
|
|
|
27 - STRIKER
BSD-1618710057.A3
1618710057
|
£16.41
|
£19.69
|
|
|
28 - STRIKER PIN
BSD-1613124040.A2
1613124040
|
£5.30
|
£6.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A277
1613105012
|
£3.72
|
£4.47
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A150
1610508008
|
£2.16
|
£2.59
|
|
|
35 - RUBBER RING
BSD-1610206021.A225
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390017.A9
1610390017
|
£5.30
|
£6.36
|
|
|
38 - SUPPORTING DISC
BSD-1610102026.A78
1610102026
|
£2.61
|
£3.13
|
|
|
41 - SHIM WASHER 1.2 MM
BSD-1610101011.A204
1610101011
|
£1.75
|
£2.10
|
|
|
42 - PLAIN BEARING
BSD-1610202015.A49
1610202015
|
£2.80
|
£3.36
|
|
|
43 - TAB WASHER
BSD-1611098005.A39
1611098005
|
£2.80
|
£3.36
|
|
|
44 - SWITCHING ELEMENT
BSD-1615820092.A17
1615820092
|
£2.61
|
£3.13
|
|
|
45 - SWITCH SPRING
BSD-1614651014.A104
1614651014
|
£1.75
|
£2.10
|
|
|
46 - DRIVER PIN
BSD-1614690002.A10
1614690002
|
£1.75
|
£2.10
|
|
|
48 - HOLDING PLATE
BSD-1611016003.A233
1611016003
|
£2.16
|
£2.59
|
|
|
49 - SWITCH BUTTON
BSD-1612026035.A27
1612026035
|
£1.75
|
£2.10
|
|
|
60 - NEEDLE-ROLLER BEARING
BSD-1610910073.A34
1610910073
|
£11.30
|
£13.56
|
|
|
61 - NEEDLE BEARING
BSD-1610910098.A137
1610910098
|
£3.72
|
£4.47
|
|
|
62 - NEEDLE BEARING
BSD-1610910074.A90
1610910074
|
£3.72
|
£4.47
|
|
|
63 - NEEDLE BEARING
BSD-1610910064.A211
1610910064
|
£2.52
|
£3.02
|
|
|
64 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913010.A127
1610913010
|
£4.26
|
£5.11
|
|
|
65 - PLAIN BEARING
BSD-1610591016.A59
1610591016
|
£2.80
|
£3.36
|
|
|
67 - GROOVE BALL BEARING
BSD-1610905016.A5
1610905016
|
£10.10
|
£12.12
|
|
|
70 - SHAFT SEAL
BSD-1610283019.A59
1610283019
|
£7.36
|
£8.83
|
|
|
71 - SCRAPER
BSD-1610290029.A123
1610290029
|
£3.72
|
£4.47
|
|
|
72 - O-RING 24.0x2.5 MM
BSD-1610210068.A160
1610210068
|
£1.75
|
£2.10
|
|
|
73 - O-RING
BSD-1610210187.A165
1610210187
|
£2.16
|
£2.59
|
|
|
74 - O-RING 11.0x3.5 MM
BSD-1610210104.A139
1610210104
|
£2.61
|
£3.13
|
|
|
75 - O-RING 18.0x3.5 MM
BSD-1610210105.A6
1610210105
|
£4.26
|
£5.11
|
|
|
76 - O-RING 10.5x2.7 MM
BSD-1610210046.A12
1610210046
|
£2.16
|
£2.59
|
|
|
77 - O-RING 60.0x3.0 MM
BSD-1610210106.A139
1610210106
|
£2.61
|
£3.13
|
|
|
80 - COMPRESSION SPRING
BSD-1614634005.A29
1614634005
|
£1.75
|
£2.10
|
|
|
81 - COMPRESSION SPRING
BSD-1614611009.A63
1614611009
|
£1.75
|
£2.10
|
|
|
83 - COMPRESSION SPRING
BSD-1614611006.A322
1614611006
|
£3.72
|
£4.47
|
|
|
85 - RETAINING RING
BSD-1614601011.A86
1614601011
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A211
2916540012
|
-
|
|
|
|
88 - ROLLER
BSD-1613200007.A135
1613200007
|
£1.75
|
£2.10
|
|
|
89 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A716
1903230013
|
£2.16
|
£2.59
|
|
|
90 - SOCKET HEAD CAP SCREW DIN 84-M5x65-4.8
BSD-1613410004.A2
1613410004
|
-
|
|
|
|
91 - LENS HEAD SCREW 4x32
BSD-2603490026.A160
2603490026
|
£1.75
|
£2.10
|
|
|
92 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A122
2603490023
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A448
2910211005
|
£1.75
|
£2.10
|
|
|
94 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A521
2603435015
|
£2.16
|
£2.59
|
|
|
95 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2805
2603410001
|
£1.75
|
£2.10
|
|
|
96 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A155
2912401018
|
£1.75
|
£2.10
|
|
|
100 - CONNECTING CABLE L=55 MM
BSD-1614448017.A76
1614448017
|
£2.16
|
£2.59
|
|
|
101 - CONNECTING CABLE L=78 MM
BSD-2604448137.A46
2604448137
|
-
|
|
|
|
102 - CABLE L=130 MM
BSD-2604448005.A71
2604448005
|
£1.75
|
£2.10
|
|
|
103 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A17
2604465097
|
£5.58
|
£6.70
|
|
|
104 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A146
2604465086
|
£5.58
|
£6.70
|
|
|
105 - EARTH CONDUCTOR
BSD-1614449011.A5
1614449011
|
-
|
|
|
|
107 - BLOWER CASING
BSD-1615190042.A3
1615190042
|
-
|
|
|
|
108 - FAN HOUSING
BSD-1615190044.A11
1615190044
|
£27.31
|
£32.77
|
|
|
113 - PROFILE PLATE
BSD-1611038017.A1
1611038017
|
-
|
|
|
|
118 - SEALING DISK 609 AV NILOS-RING
BSD-2916130027.A10
2916130027
|
£5.01
|
£6.01
|
|
|
119 - O-RING 23.0x3.0 MM
BSD-1610210045.A21
1610210045
|
£2.61
|
£3.13
|
|
|
120 - AUXILIARY HANDLE dia43 MM
BSD-2602025070.A124
2602025070
|
£14.91
|
£17.89
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040048.A97
1618040048
|
£8.67
|
£10.41
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A425
1613490002
|
£4.26
|
£5.11
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A160
1611316006
|
£2.61
|
£3.13
|
|
|
125 - SOCKET HEAD CAP SCREW DIN 84-AM5x35-8.8
BSD-2910021168.A8
2910021168
|
-
|
|
|
|
126 - REC CT-SUNK TAPPING SCREW
BSD-1613435005.A11
1613435005
|
£2.33
|
£2.80
|
|
|
130 - STICKER
BSD-1611110640.A4
1611110640
|
-
|
|
|
|
131 - SEALING FRAME
BSD-1611015039.A13
1611015039
|
£3.80
|
£4.56
|
|
|
653 - PLUG
BSD-1610591008.A20
1610591008
|
£5.87
|
£7.04
|
|
|
801 - MOTOR HOUSING
BSD-1617000477.A19
1617000477
|
£18.96
|
£22.75
|
|
|
802 - FIELD 220-230V
BSD-2604220514.A0
2604220514
|
-
|
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1614010796.A1
1614010796
|
-
|
|
|
|
806 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A646
2600703013
|
£2.61
|
£3.13
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A161
160111A3H5
|
£2.61
|
£3.13
|
|
|
811 - CARBON BRUSH
BSD-1607014117.A141
1607014117
|
£10.10
|
£12.12
|
|
|
812 - SUPPRESSION FILTER
BSD-1607328040.A129
1607328040
|
£6.52
|
£7.83
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A264
1610905048
|
£8.67
|
£10.41
|
|
|
816 - BRUSH HOLDER
BSD-2604337016.A74
2604337016
|
£1.75
|
£2.10
|
|
|
817 - HOUSING COVER
BSD-1615132047.A10
1615132047
|
-
|
|
|
|
819 - GEAR HOUSING
BSD-1615806093.A6
1615806093
|
£48.38
|
£58.06
|
|
|
820 - INTERMEDIATE FLANGE
BSD-1617000981.A47
1617000981
|
£27.23
|
£32.68
|
|
|
821 - RATCHET SLEEVE SDS-PLUS
BSD-1616490061.A90
1616490061
|
£59.53
|
£71.44
|
|
|
821/01 - RATCHET SLEEVE SDS-PLUS
BSD-1616490060.A7
1616490060
|
£72.18
|
£86.62
|
|
|
823 - GEAR SLEEVE Z=26/6
BSD-1616328042.A7
1616328042
|
£40.80
|
£48.96
|
|
|
826 - TOOTHED SHAFT Z=3/9
BSD-1617000517.A50
1617000517
|
£72.18
|
£86.62
|
|
|
830 - DRIVE BEARING
BSD-1615819018.A29
1615819018
|
£51.22
|
£61.47
|
|
|
832 - CLAMP HANDLE
BSD-1612026037.A192
1612026037
|
£10.82
|
£12.99
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A129
1617000163
|
£7.36
|
£8.83
|
|
|
847 - GUIDE RING
BSD-1617000348.A73
1617000348
|
£14.91
|
£17.89
|
|
|
886 - RETAINING RING
BSD-1614601024.A68
1614601024
|
£1.75
|
£2.10
|
|
|
890 - CONNECTING CABLE L = 123 MM
BSD-2604448145.A34
2604448145
|
-
|
|
|
|
891 - CONNECTING CABLE L=176 MM
BSD-2604448004.A35
2604448004
|
£1.32
|
£1.58
|
|
|
892 - SUPPRESSION FILTER L= 156 MM
BSD-2604465087.A0
2604465087
|
£5.01
|
£6.01
|
|
|
893 - PLATE
BSD-2600034003.A34
2600034003
|
-
|
|
|
|
899 - MODIFICATION SET
BSD-1617000682.A2
1617000682
|
-
|
|
|
