2 - FIELD 110V
BSD-1614220175.A8
1614220175
|
£21.68
|
£26.01
|
|
|
3/60 - FAN
BSD-1616610095.A31
1616610095
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-1617200058.A0
1617200058
|
£54.42
|
£65.30
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A277
2600703018
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-1611035005.A179
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110683.A0
1611110683
|
£3.72
|
£4.47
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110684.A1
1611110684
|
£3.34
|
£4.01
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328040.A154
1607328040
|
£6.52
|
£7.83
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A144
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A309
1610905048
|
£8.67
|
£10.41
|
|
|
16 - BRUSH HOLDER
BSD-1617000344.A2
1617000344
|
-
|
|
|
|
17 - HOUSING COVER
BSD-1615132098.A5
1615132098
|
£5.30
|
£6.36
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522009.A52
1610522009
|
£1.32
|
£1.58
|
|
|
22 - CYLINDRICAL GEAR Z=50
BSD-1616317602.A75
1616317602
|
£12.04
|
£14.45
|
|
|
24 - TOOTHED SHAFT Z=3/9
BSD-1617000518.A90
1617000518
|
£40.80
|
£48.96
|
|
|
26 - HAMMER PISTON
BSD-1618700062.A85
1618700062
|
£14.91
|
£17.89
|
|
|
27 - STRIKER
BSD-1618710057.A70
1618710057
|
£16.41
|
£19.69
|
|
|
28 - STRIKER PIN
BSD-1613124040.A50
1613124040
|
£5.30
|
£6.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A327
1613105012
|
£3.72
|
£4.47
|
|
|
31 - PROTECTIVE GRILLE
BSD-1615510003.A31
1615510003
|
£2.61
|
£3.13
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A201
1610508008
|
£2.16
|
£2.59
|
|
|
35 - RUBBER RING
BSD-1610206021.A245
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390017.A82
1610390017
|
£5.30
|
£6.36
|
|
|
38 - SUPPORTING DISC
BSD-1610102026.A124
1610102026
|
£2.61
|
£3.13
|
|
|
41 - SHIM WASHER 1.2 MM
BSD-1610101011.A148
1610101011
|
£1.75
|
£2.10
|
|
|
42 - PLAIN BEARING
BSD-1610202015.A135
1610202015
|
£2.80
|
£3.36
|
|
|
43 - TAB WASHER
BSD-1611098005.A72
1611098005
|
£2.80
|
£3.36
|
|
|
44 - SWITCHING ELEMENT
BSD-1615820092.A89
1615820092
|
£2.61
|
£3.13
|
|
|
45 - SWITCH SPRING
BSD-1614651014.A94
1614651014
|
£1.75
|
£2.10
|
|
|
46 - DRIVER PIN
BSD-1614690002.A64
1614690002
|
£1.75
|
£2.10
|
|
|
48 - HOLDING PLATE
BSD-1611016003.A212
1611016003
|
£2.16
|
£2.59
|
|
|
49 - SWITCH BUTTON
BSD-1612026054.A7
1612026054
|
£2.61
|
£3.13
|
|
|
60 - NEEDLE-ROLLER BEARING
BSD-1610910073.A54
1610910073
|
£11.30
|
£13.56
|
|
|
61 - NEEDLE BEARING
BSD-1610910098.A107
1610910098
|
£3.72
|
£4.47
|
|
|
62 - NEEDLE BEARING
BSD-1610910074.A68
1610910074
|
£3.72
|
£4.47
|
|
|
63 - NEEDLE BEARING
BSD-1610910064.A164
1610910064
|
£2.52
|
£3.02
|
|
|
64 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913010.A75
1610913010
|
£4.26
|
£5.11
|
|
|
65 - PLAIN BEARING
BSD-1610591016.A32
1610591016
|
£2.80
|
£3.36
|
|
|
67 - GROOVE BALL BEARING
BSD-1610905016.A54
1610905016
|
£10.10
|
£12.12
|
|
|
70 - SHAFT SEAL
BSD-1610283019.A85
1610283019
|
£7.36
|
£8.83
|
|
|
71 - SCRAPER
BSD-1610290029.A64
1610290029
|
£3.72
|
£4.47
|
|
|
72 - O-RING 24.0x2.5 MM
BSD-1610210068.A187
1610210068
|
£1.75
|
£2.10
|
|
|
73 - O-RING
BSD-1610210187.A221
1610210187
|
£2.16
|
£2.59
|
|
|
74 - O-RING 11.0x3.5 MM
BSD-1610210104.A85
1610210104
|
£2.61
|
£3.13
|
|
|
75 - O-RING 18.0x3.5 MM
BSD-1610210105.A50
1610210105
|
£4.26
|
£5.11
|
|
|
76 - O-RING 10.5x2.7 MM
BSD-1610210046.A91
1610210046
|
£2.16
|
£2.59
|
|
|
77 - O-RING 60.0x3.0 MM
BSD-1610210106.A85
1610210106
|
£2.61
|
£3.13
|
|
|
80 - COMPRESSION SPRING
BSD-1614634005.A52
1614634005
|
£1.75
|
£2.10
|
|
|
81 - COMPRESSION SPRING
BSD-1614611009.A41
1614611009
|
£1.75
|
£2.10
|
|
|
83 - COMPRESSION SPRING
BSD-1614611010.A13
1614611010
|
-
|
|
|
|
85 - RETAINING RING
BSD-1614601011.A129
1614601011
|
£1.75
|
£2.10
|
|
|
86 - RETAINING RING
BSD-1614601024.A44
1614601024
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A153
2916540012
|
-
|
|
|
|
88 - ROLLER
BSD-1613200007.A93
1613200007
|
£1.75
|
£2.10
|
|
|
89 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A697
1903230013
|
£2.16
|
£2.59
|
|
|
90 - TAPPING SCREW 4.8x78 MM. TORX T-20
BSD-1603435036.A34
1603435036
|
£1.75
|
£2.10
|
|
|
91 - LENS HEAD SCREW 4x32
BSD-2603490026.A186
2603490026
|
£1.75
|
£2.10
|
|
|
92 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A97
2603490023
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A503
2910211005
|
£1.75
|
£2.10
|
|
|
94 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A573
2603435015
|
£2.16
|
£2.59
|
|
|
95 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2759
2603410001
|
£1.75
|
£2.10
|
|
|
96 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A125
2912401018
|
£1.75
|
£2.10
|
|
|
100 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A140
2604465086
|
£5.58
|
£6.70
|
|
|
101 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A38
2604465097
|
£5.58
|
£6.70
|
|
|
102 - CABLE L=130 MM
BSD-2604448005.A131
2604448005
|
£1.75
|
£2.10
|
|
|
103 - CONNECTING CABLE L=55 MM
BSD-1614448017.A102
1614448017
|
£2.16
|
£2.59
|
|
|
104 - CONNECTING CABLE L=78 MM
BSD-2604448137.A51
2604448137
|
-
|
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025041.A48
1612025041
|
£21.42
|
£25.71
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040064.A13
1618040064
|
£8.49
|
£10.19
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A338
1613490002
|
£4.26
|
£5.11
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A183
1611316006
|
£2.61
|
£3.13
|
|
|
150 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A166
1900452012
|
£1.75
|
£2.10
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430009.A26
1615430009
|
£13.12
|
£15.75
|
|
|
691 - CARRYING CASE
BSD-1615438285.A0
1615438285
|
-
|
|
|
|
720/8 - AUXILIARY HANDLE dia43 MM
BSD-1612025047.A14
1612025047
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-1617000V10.A1
1617000V10
|
£21.42
|
£25.71
|
|
|
803 - ARMATURE WITH FAN 100-110V
BSD-1614010228.A0
1614010228
|
£81.81
|
£98.17
|
|
|
805 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460061.A2
1614460061
|
£21.68
|
£26.01
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014127.A0
1617014127
|
£10.10
|
£12.12
|
|
|
819 - GEAR HOUSING
BSD-1615190066.A1
1615190066
|
£40.80
|
£48.96
|
|
|
820 - INTERMEDIATE FLANGE
BSD-1617000981.A40
1617000981
|
£27.23
|
£32.68
|
|
|
821/01 - RATCHET SLEEVE SDS-PLUS
BSD-1616490061.A35
1616490061
|
£59.53
|
£71.44
|
|
|
821/01/1 - RATCHET SLEEVE SDS-PLUS
BSD-1616490060.A62
1616490060
|
£72.18
|
£86.62
|
|
|
823 - GEAR SLEEVE Z=26/6
BSD-1616328042.A67
1616328042
|
£40.80
|
£48.96
|
|
|
826 - TOOTHED SHAFT Z=3/9
BSD-1617000517.A34
1617000517
|
£72.18
|
£86.62
|
|
|
830 - DRIVE BEARING
BSD-1615819018.A57
1615819018
|
£51.22
|
£61.47
|
|
|
832 - CLAMP HANDLE
BSD-1612026059.A7
1612026059
|
£7.36
|
£8.83
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A197
1617000163
|
£7.36
|
£8.83
|
|
|
847 - GUIDE RING
BSD-1617000348.A28
1617000348
|
£14.91
|
£17.89
|
|
|
879 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A155
1613001009
|
£3.72
|
£4.47
|
|
|
888 - NAMEPLATE
BSD-160111A3HD.A108
160111A3HD
|
£2.61
|
£3.13
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000274.A0
1617000274
|
£21.68
|
£26.01
|
|
