2 - FIELD 110-120V
BSD-2604220428.A24
2604220428
|
£27.23
|
£32.68
|
|
|
3/50 - FAN
BSD-1616610072.A118
1616610072
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-1617200052.A2
1617200052
|
£37.72
|
£45.27
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460061.A33
1614460061
|
£21.68
|
£26.01
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A649
2600703011
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A560
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-1611035005.A33
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110423.A5
1611110423
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110424.A7
1611110424
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A213
1607328028
|
£5.30
|
£6.36
|
|
|
17 - HOUSING COVER
BSD-1615132034.A30
1615132034
|
£5.01
|
£6.01
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A70
1610522008
|
£1.75
|
£2.10
|
|
|
18 - COVER DISC
BSD-2601328033.A217
2601328033
|
-
|
|
|
|
20 - IMPACT MECHANISM
BSD-1617000353.A25
1617000353
|
£88.07
|
£105.68
|
|
|
21 - RATCHET SLEEVE
BSD-1616490027.A6
1616490027
|
-
|
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A73
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320002.A126
1616320002
|
£24.45
|
£29.34
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A22
1613060010
|
£54.42
|
£65.30
|
|
|
25 - BEARING SLEEVE
BSD-1610400022.A7
1610400022
|
-
|
|
|
|
26 - HAMMER PISTON
BSD-1618700050.A6
1618700050
|
-
|
|
|
|
28 - STRIKER PIN
BSD-1613124026.A91
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A201
1613105012
|
£3.72
|
£4.47
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A27
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A71
1610100003
|
£1.75
|
£2.10
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A128
1612026023
|
£2.61
|
£3.13
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A129
1612026023
|
£2.61
|
£3.13
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A17
1610508008
|
£2.16
|
£2.59
|
|
|
35 - RUBBER RING
BSD-1610206021.A80
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390008.A1
1610390008
|
-
|
|
|
|
38 - SUPPORTING DISC
BSD-1610102020.A3
1610102020
|
-
|
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A150
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A148
1614690001
|
£1.75
|
£2.10
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A66
1610920003
|
£4.26
|
£5.11
|
|
|
42 - INTERMEDIATE RING
BSD-1610202012.A2
1610202012
|
£7.78
|
£9.33
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A8
1614633001
|
£2.52
|
£3.02
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A78
1614614001
|
£1.75
|
£2.10
|
|
|
47 - RETAINING RING
BSD-1614601001.A3
1614601001
|
-
|
|
|
|
49 - CABLE L=130 MM
BSD-2604448005.A216
2604448005
|
£1.75
|
£2.10
|
|
|
52 - SHIM WASHER
BSD-1610101614.A3
1610101614
|
-
|
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A127
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A93
1610206023
|
£2.80
|
£3.36
|
|
|
56 - O-RING 13.0x3.0 MM
BSD-1610210057.A5
1610210057
|
-
|
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A2
1610210058
|
£2.61
|
£3.13
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A61
1610210069
|
£1.75
|
£2.10
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A43
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A57
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A161
1610202026
|
£5.30
|
£6.36
|
|
|
63 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A387
1610905048
|
£8.67
|
£10.41
|
|
|
64 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A224
1610905025
|
£6.52
|
£7.83
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A151
1900900228
|
£6.61
|
£7.93
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A303
1610910064
|
£2.52
|
£3.02
|
|
|
68 - ROLLER-CAGE ASSEMBLY
BSD-1610920002.A8
1610920002
|
£3.72
|
£4.47
|
|
|
69 - SUPPORT DISC 1.0 MM
BSD-1610102617.A6
1610102617
|
£2.16
|
£2.59
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A386
1903230013
|
£2.16
|
£2.59
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A28
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A1
2916540018
|
£3.72
|
£4.47
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A144
1614601009
|
£1.95
|
£2.34
|
|
|
75 - SOCKET HEAD CAP SCREW DIN 84-AM5x16-8.8
BSD-2910021158.A92
2910021158
|
£1.32
|
£1.58
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A129
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A305
2910211021
|
£1.75
|
£2.10
|
|
|
78 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A105
1603435050
|
£2.33
|
£2.80
|
|
|
79 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A389
2910211005
|
£1.75
|
£2.10
|
|
|
79 - TAPPING SCREW DIN 7971-B 2.9x13
BSD-2910211206.A8
2910211206
|
£1.32
|
£1.58
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A312
2603435015
|
£2.16
|
£2.59
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2656
2603410001
|
£1.75
|
£2.10
|
|
|
82 - LUBRICATING FELT
BSD-1610205004.A3
1610205004
|
-
|
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A41
1903230309
|
£1.75
|
£2.10
|
|
|
85 - PROTECTION SLEEVE
BSD-1617000163.A39
1617000163
|
£7.36
|
£8.83
|
|
|
86 - PROTECTION SLEEVE
BSD-1617000163.A40
1617000163
|
£7.36
|
£8.83
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A454
2916540012
|
-
|
|
|
|
92 - ROTARY SHAFT LIP SEAL
BSD-1610283018.A4
1610283018
|
-
|
|
|
|
94 - DETENT PIN
BSD-1613120017.A55
1613120017
|
£1.75
|
£2.10
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A468
1612025019
|
£6.52
|
£7.83
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040048.A74
1618040048
|
£8.67
|
£10.41
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A577
1613490002
|
£4.26
|
£5.11
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A303
1611316006
|
£2.61
|
£3.13
|
|
|
123/1 - CLAMPING BAND dia43 MM
BSD-1611316003.A55
1611316003
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A47
1613100012
|
£2.61
|
£3.13
|
|
|
700 - DRILL CHUCK SHANK
BSD-1617000132.A110
1617000132
|
£16.84
|
£20.21
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A159
2603421226
|
£1.75
|
£2.10
|
|
|
701 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A434
1608571069
|
£23.86
|
£28.63
|
|
|
701/10 - CHUCK WRENCH SG2
BSD-2607950007.A449
2607950007
|
£6.52
|
£7.83
|
|
|
711 - PARTS SET
BSD-1617000133.A89
1617000133
|
-
|
|
|
|
711/10/2 - RETAINING RING
BSD-2604601004.A103
2604601004
|
£1.75
|
£2.10
|
|
|
711/20 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A111
1608521004
|
-
|
|
|
|
711/30 - SCREWDRIVER BIT
BSD-2607000248.A30
2607000248
|
-
|
|
|
|
711/40 - SCREWDRIVER BLADE GR.1.0x6. 1/4
BSD-1608511020.A18
1608511020
|
-
|
|
|
|
720 - AUXILIARY HANDLE dia43 MM
BSD-2602025070.A53
2602025070
|
£14.91
|
£17.89
|
|
|
720/8 - PARTS SET
BSD-1617000925.A30
1617000925
|
£16.41
|
£19.69
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A272
1613001009
|
£3.72
|
£4.47
|
|
|
801 - PARTS SET
BSD-1615108045.A8
1615108045
|
-
|
|
|
|
803 - ARMATURE 110-120V
BSD-1614010037.A0
1614010037
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3133
160111A3H3
|
£2.61
|
£3.13
|
|
|
811 - CARBON BRUSH
BSD-1607014117.A119
1607014117
|
£10.10
|
£12.12
|
|
|
814 - BRUSH HOLDER
BSD-1617000130.A7
1617000130
|
£3.80
|
£4.56
|
|
|
816 - GEAR HOUSING
BSD-1615806077.A71
1615806077
|
£45.67
|
£54.80
|
|
|
827 - STRIKER
BSD-1617000338.A120
1617000338
|
£27.23
|
£32.68
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A41
1617000163
|
£7.36
|
£8.83
|
|
|
843 - BRUSH PLATE
BSD-2601015047.A143
2601015047
|
-
|
|
|
|
899 - IMPACT MECHANISM
BSD-1617000353.A28
1617000353
|
£88.07
|
£105.68
|
|
