2 - FIELD 220-230V
BSD-2604220429.A89
2604220429
|
£23.86
|
£28.63
|
|
|
3/50 - FAN
BSD-1616610072.A85
1616610072
|
£2.16
|
£2.59
|
|
|
4 - SWITCH
BSD-2607200209.A32
2607200209
|
£40.80
|
£48.96
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A627
2600703011
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-1611035005.A13
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110416.A1
1611110416
|
-
|
|
|
|
10 - REFERENCE PLATE
BSD-1611110417.A4
1611110417
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329096.A194
2607329096
|
£7.36
|
£8.83
|
|
|
17 - HOUSING COVER
BSD-1615132034.A2
1615132034
|
£5.01
|
£6.01
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A46
1610522008
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE FLANGE
BSD-1615700037.A110
1615700037
|
£40.80
|
£48.96
|
|
|
21 - RATCHET SLEEVE SDS-PLUS
BSD-1616490058.A103
1616490058
|
£218.41
|
£262.09
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A38
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320006.A8
1616320006
|
-
|
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A6
1613060010
|
£54.42
|
£65.30
|
|
|
26 - HAMMER PISTON
BSD-1618700052.A91
1618700052
|
£13.12
|
£15.75
|
|
|
28 - STRIKER PIN
BSD-1613124026.A109
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A218
1613105012
|
£3.72
|
£4.47
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A4
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A50
1610100003
|
£1.75
|
£2.10
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A120
1612026023
|
£2.61
|
£3.13
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A43
1610508008
|
£2.16
|
£2.59
|
|
|
35 - RUBBER RING
BSD-1610206021.A96
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390011.A0
1610390011
|
£3.72
|
£4.47
|
|
|
38 - SUPPORTING DISC
BSD-1610102022.A17
1610102022
|
£2.16
|
£2.59
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A132
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A112
1614690001
|
£1.75
|
£2.10
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A83
1610920003
|
£4.26
|
£5.11
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A30
1614633001
|
£2.52
|
£3.02
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A56
1614614001
|
£1.75
|
£2.10
|
|
|
48 - CONNECTING CABLE L=90 MM
BSD-1614431023.A20
1614431023
|
-
|
|
|
|
49 - CABLE L=130 MM
BSD-2604448005.A230
2604448005
|
£1.75
|
£2.10
|
|
|
50 - CABLE
BSD-2604448003.A136
2604448003
|
-
|
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A102
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A75
1610206023
|
£2.80
|
£3.36
|
|
|
56 - O-RING 14.0x3.0 MM
BSD-1610210070.A84
1610210070
|
£2.61
|
£3.13
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A27
1610210058
|
£2.61
|
£3.13
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A86
1610210069
|
£1.75
|
£2.10
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A60
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A36
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A177
1610202026
|
£5.30
|
£6.36
|
|
|
63 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A405
1610905048
|
£8.67
|
£10.41
|
|
|
64 - BALL BEARING 7x19x6
BSD-2600905032.A1744
2600905032
|
£5.30
|
£6.36
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A114
1900900228
|
£6.61
|
£7.93
|
|
|
66 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A37
1610910063
|
£5.58
|
£6.70
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A335
1610910064
|
£2.52
|
£3.02
|
|
|
68 - ROLLER-CAGE ASSEMBLY
BSD-1610920004.A52
1610920004
|
£3.80
|
£4.56
|
|
|
69 - SUPPORT DISC 1.0 MM
BSD-1610102618.A14
1610102618
|
-
|
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A366
1903230013
|
£2.16
|
£2.59
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A5
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A40
2916540018
|
£3.72
|
£4.47
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A167
1614601009
|
£1.95
|
£2.34
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A112
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A323
2910211021
|
£1.75
|
£2.10
|
|
|
78 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A80
1603435050
|
£2.33
|
£2.80
|
|
|
79 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A372
2910211005
|
£1.75
|
£2.10
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A333
2603435015
|
£2.16
|
£2.59
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2633
2603410001
|
£1.75
|
£2.10
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A60
1903230309
|
£1.75
|
£2.10
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A415
2916540012
|
-
|
|
|
|
90 - SWITCH
BSD-1617200042.A29
1617200042
|
£16.41
|
£19.69
|
|
|
94 - DETENT PIN
BSD-1613120017.A38
1613120017
|
£1.75
|
£2.10
|
|
|
102 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A8
2604465097
|
£5.58
|
£6.70
|
|
|
103 - CONNECTING CABLE L=55 MM
BSD-1614448017.A33
1614448017
|
£2.16
|
£2.59
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A433
1612025019
|
£6.52
|
£7.83
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040048.A59
1618040048
|
£8.67
|
£10.41
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A537
1613490002
|
£4.26
|
£5.11
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A343
1611316006
|
£2.61
|
£3.13
|
|
|
123/1 - CLAMPING BAND dia43 MM
BSD-1611316003.A35
1611316003
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A52
1613100012
|
£2.61
|
£3.13
|
|
|
125 - MANUFACTURER'S NAMEPLATE
BSD-1611110345.A9
1611110345
|
-
|
|
|
|
691 - CARRYING CASE
BSD-1615438366.A0
1615438366
|
-
|
|
|
|
700 - DRILL CHUCK SHANK
BSD-1617000132.A115
1617000132
|
£16.84
|
£20.21
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A174
2603421226
|
£1.75
|
£2.10
|
|
|
701 - KEY CHUCK R/L dia13 MM. 1/2-20 UNF
BSD-1608571062.A27
1608571062
|
£17.49
|
£20.99
|
|
|
701/7 - CHUCK WRENCH SG2. SW4
BSD-1607950044.A72
1607950044
|
£6.12
|
£7.34
|
|
|
711 - PARTS SET
BSD-1617000133.A84
1617000133
|
-
|
|
|
|
711/10/2 - RETAINING RING
BSD-2604601004.A104
2604601004
|
£1.75
|
£2.10
|
|
|
711/20 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A95
1608521004
|
-
|
|
|
|
711/30 - SCREWDRIVER BIT
BSD-2607000248.A29
2607000248
|
-
|
|
|
|
711/40 - SCREWDRIVER BLADE GR.1.0x6. 1/4
BSD-1608511020.A33
1608511020
|
-
|
|
|
|
720 - AUXILIARY HANDLE dia43 MM
BSD-2602025070.A73
2602025070
|
£14.91
|
£17.89
|
|
|
720/8 - PARTS SET
BSD-1617000925.A1
1617000925
|
£16.41
|
£19.69
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001010.A12
1613001010
|
£2.98
|
£3.57
|
|
|
801 - PARTS SET
BSD-1615108045.A21
1615108045
|
-
|
|
|
|
803 - ARMATURE WITH FAN 220-230V
BSD-1614010039.A4
1614010039
|
-
|
|
|
|
804 - SWITCH KIT
BSD-1617000915.A19
1617000915
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A596
1607000227
|
£23.86
|
£28.63
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A192
160111A3H5
|
£2.61
|
£3.13
|
|
|
811 - CARBON BRUSH
BSD-1617014114.A0
1617014114
|
£10.10
|
£12.12
|
|
|
814 - PARTS SET
BSD-1617000136.A23
1617000136
|
£18.96
|
£22.75
|
|
|
816 - GEAR HOUSING
BSD-1615806077.A55
1615806077
|
£45.67
|
£54.80
|
|
|
817 - HOUSING COVER
BSD-1615132031.A25
1615132031
|
-
|
|
|
|
821 - RATCHET SLEEVE
BSD-1617000931.A86
1617000931
|
£283.50
|
£340.20
|
|
|
827 - STRIKER
BSD-1617000338.A135
1617000338
|
£27.23
|
£32.68
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A8
1617000163
|
£7.36
|
£8.83
|
|
|
843 - BRUSH PLATE
BSD-2601015047.A119
2601015047
|
-
|
|
|
|
857 - O-RING 34.0x2.0 MM
BSD-1610210084.A30
1610210084
|
£1.75
|
£2.10
|
|
|
866 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A39
1610910063
|
£5.58
|
£6.70
|
|
|
890 - MODIFICATION SET 110-240V
BSD-1617000134.A14
1617000134
|
£80.61
|
£96.73
|
|
