1 - MOTOR HOUSING
BSD-1619P12521.A1
1619P12521
|
£14.91
|
£17.89
|
|
2 - DC MOTOR
BSD-160702264L.A5
160702264L
|
£40.80
|
£48.96
|
|
4 - ELECTRONICS MODULE
BSD-1619P10653.A7
1619P10653
|
£52.15
|
£62.58
|
|
9 - MANUFACTURER'S NAMEPLATE BTI
BSD-1619P12524.A0
1619P12524
|
£2.61
|
£3.13
|
|
13 - GROOVE BALL BEARING
BSD-1619P10733.A4
1619P10733
|
£2.80
|
£3.36
|
|
14 - GEAR
BSD-1619P10731.A4
1619P10731
|
£11.30
|
£13.56
|
|
22 - HANDLE
BSD-1619P12527.A1
1619P12527
|
£21.52
|
£25.83
|
|
23 - UPPER GUARD
BSD-1619P10719.A3
1619P10719
|
£19.45
|
£23.34
|
|
24 - LOWER GUARD
BSD-1619P10722.A3
1619P10722
|
£5.30
|
£6.36
|
|
25 - BASE PLATE
BSD-1600A00XR3.A4
1600A00XR3
|
£13.12
|
£15.75
|
|
26 - END CAP
BSD-1619P12356.A4
1619P12356
|
£2.61
|
£3.13
|
|
27 - HINGE BRACKET
BSD-1619P10725.A4
1619P10725
|
£2.16
|
£2.59
|
|
28 - SUPPORT BRACKET
BSD-1619P10726.A5
1619P10726
|
£2.61
|
£3.13
|
|
31 - BUMPER
BSD-1619P10728.A5
1619P10728
|
£1.75
|
£2.10
|
|
38 - GEAR SHAFT
BSD-1619P10735.A4
1619P10735
|
£12.04
|
£14.45
|
|
39 - GEAR
BSD-1619P10732.A5
1619P10732
|
£12.04
|
£14.45
|
|
41 - GROOVE BALL BEARING
BSD-1619P10734.A5
1619P10734
|
£3.72
|
£4.47
|
|
42 - BUSHING
BSD-1619P10729.A4
1619P10729
|
£1.75
|
£2.10
|
|
43 - SHAFT
BSD-1619P10730.A5
1619P10730
|
£6.52
|
£7.83
|
|
44 - GEAR
BSD-1619P10736.A5
1619P10736
|
£11.30
|
£13.56
|
|
45 - BALL BEARING
BSD-1619P06024.A7
1619P06024
|
£10.10
|
£12.12
|
|
48 - COMPRESSION SPRING
BSD-1619P10738.A5
1619P10738
|
£1.75
|
£2.10
|
|
49 - GUIDE BRACKET
BSD-1619P10727.A4
1619P10727
|
£5.30
|
£6.36
|
|
50 - LOCKING SLIDE
BSD-1619P12528.A0
1619P12528
|
£10.10
|
£12.12
|
|
51 - COMPRESSION SPRING
BSD-2610935251.A17
2610935251
|
£1.75
|
£2.10
|
|
53 - BEARING FLANGE
BSD-1619P10720.A6
1619P10720
|
£11.30
|
£13.56
|
|
55 - TRIGGER
BSD-1619P12529.A1
1619P12529
|
£10.10
|
£12.12
|
|
56 - EXTENSION SPRING
BSD-1619P10742.A9
1619P10742
|
£1.75
|
£2.10
|
|
57 - STICKER
BSD-1619P12520.A2
1619P12520
|
£2.61
|
£3.13
|
|
61 - HEXAGON SOCKET WRENCH
BSD-1619P11420.A5
1619P11420
|
£2.16
|
£2.59
|
|
64 - SLOTTED SPRING PIN
BSD-2917760151.A3
2917760151
|
£2.16
|
£2.59
|
|
65 - RIVET
BSD-1619P06968.A5
1619P06968
|
£1.75
|
£2.10
|
|
67 - PROTECTION COVER
BSD-1619P12371.A3
1619P12371
|
£12.04
|
£14.45
|
|
68 - RETAINING RING
BSD-1619P10737.A4
1619P10737
|
£1.75
|
£2.10
|
|
69 - NUT
BSD-1619P10828.A7
1619P10828
|
£2.16
|
£2.59
|
|
70 - CLIP
BSD-1619P08646.A7
1619P08646
|
£1.75
|
£2.10
|
|
71 - O-RING 14.0x1.3 MM
BSD-3600210014.A4
3600210014
|
£1.75
|
£2.10
|
|
72 - WING SCREW
BSD-1619P01618.A12
1619P01618
|
£2.29
|
£2.75
|
|
73 - HEX SOCKET HEAD CAP SCREW
BSD-1619P11432.A5
1619P11432
|
£1.75
|
£2.10
|
|
74 - TORX OVAL-HEAD SCREW 3x10
BSD-1619P00220.A128
1619P00220
|
£1.75
|
£2.10
|
|
75 - THREAD-FORMING TAP. SCREW
BSD-1619P11431.A3
1619P11431
|
£1.75
|
£2.10
|
|
76 - THREAD-FORMING TAP. SCREW
BSD-1619P07546.A7
1619P07546
|
£1.75
|
£2.10
|
|
77 - THREAD-FORMING TAP. SCREW
BSD-1613435023.A66
1613435023
|
£1.75
|
£2.10
|
|
78 - BEARING BOLT
BSD-2603201020.A68
2603201020
|
£1.75
|
£2.10
|
|
79 - PLAIN WASHER
BSD-1619P11626.A5
1619P11626
|
£1.75
|
£2.10
|
|
84 - WASHER
BSD-1619P13104.A0
1619P13104
|
£1.75
|
£2.10
|
|
85 - RETAINING WASHER
BSD-1619P10745.A0
1619P10745
|
£2.61
|
£3.13
|
|
651 - BATTERY PACK 10.8V 2.0 Ah. LI
BSD-2607336977.A1
2607336977
|
£61.98
|
£74.38
|
|
653 - FAST CHARGER BTI EU 230/10.8 V. 30 MIN.
BSD-2607225297.A1
2607225297
|
£58.76
|
£70.51
|
|
802 - MOTOR ASSEMBLY
BSD-1619P11483.A5
1619P11483
|
£37.27
|
£44.72
|
|
808 - NAMEPLATE
BSD-1619P12523.A0
1619P12523
|
£2.61
|
£3.13
|
|
825 - BASEPLATE COMPLETE
BSD-1619P11485.A4
1619P11485
|
£23.86
|
£28.63
|
|
844 - SPINDLE ASSEMBLY
BSD-1619P11484.A3
1619P11484
|
£31.64
|
£37.97
|
|
873 - PARALLEL-GUIDE
BSD-1619P12358.A2
1619P12358
|
£12.04
|
£14.45
|
|
873/1 - SUCTION NOZZLE
BSD-1619P11537.A7
1619P11537
|
£13.12
|
£15.75
|
|
