1 - MOTOR HOUSING
BSD-2610930648.A3
2610930648
|
£23.86
|
£28.63
|
|
2 - POLE HOUSING 14;4-24V
BSD-2610942109.A67
2610942109
|
£21.68
|
£26.01
|
|
3 - ARMATURE
BSD-2610943270.A0
2610943270
|
£72.18
|
£86.62
|
|
4 - ELECTRONICS MODULE
BSD-1607233258.A0
1607233258
|
£156.22
|
£187.46
|
|
9 - MANUFACTURER'S NAMEPLATE GKS 36 V-LI
BSD-2610946104.A0
2610946104
|
£2.33
|
£2.80
|
|
13 - BALL BEARING
BSD-2610351861.A7
2610351861
|
-
|
|
|
16 - BRUSH HOLDER
BSD-2610934990.A3
2610934990
|
£2.80
|
£3.36
|
|
21 - SPIRAL SPRING
BSD-1619P14306.A7
1619P14306
|
£3.72
|
£4.47
|
|
22 - SET OF HANDLES
BSD-2610942926.A0
2610942926
|
-
|
|
|
24 - LOWER GUARD
BSD-2610930652.A0
2610930652
|
£21.68
|
£26.01
|
|
26 - END CAP
BSD-2610930667.A0
2610930667
|
£2.80
|
£3.36
|
|
29 - ADJUSTING LEVER
BSD-2610943266.A0
2610943266
|
£2.16
|
£2.59
|
|
30 - ADJUSTMENT ROD
BSD-2610942927.A0
2610942927
|
£3.72
|
£4.47
|
|
31 - END STOP
BSD-1619P01532.A4
1619P01532
|
£1.75
|
£2.10
|
|
41 - GROOVE BALL BEARING 6000-2RS DIN 625
BSD-1900905173.A21
1900905173
|
£5.30
|
£6.36
|
|
43 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A807
1600910018
|
£5.30
|
£6.36
|
|
44 - GUIDE BUSHING
BSD-1619P11416.A3
1619P11416
|
£8.67
|
£10.41
|
|
45 - SPECIAL WASHER
BSD-2610959533.A3
2610959533
|
£6.52
|
£7.83
|
|
46 - FLANGE BOLT
BSD-2610935247.A3
2610935247
|
£1.75
|
£2.10
|
|
47 - PUSH-BUTTON
BSD-2610935245.A3
2610935245
|
£1.75
|
£2.10
|
|
48 - COMPRESSION SPRING
BSD-2610936576.A0
2610936576
|
£1.75
|
£2.10
|
|
49 - LOCKING PIN
BSD-2610935246.A0
2610935246
|
£2.80
|
£3.36
|
|
50 - SWITCH BUTTON
BSD-2610942928.A0
2610942928
|
£1.75
|
£2.10
|
|
51 - COMPRESSION SPRING
BSD-2610935251.A3
2610935251
|
£1.75
|
£2.10
|
|
53 - PUSH-BUTTON
BSD-2610942929.A0
2610942929
|
£2.61
|
£3.13
|
|
55 - TRIGGER
BSD-2610942930.A0
2610942930
|
£2.41
|
£2.89
|
|
56 - EXTENSION SPRING
BSD-2610947075.A0
2610947075
|
£2.61
|
£3.13
|
|
57 - LOCATING RING
BSD-2610942931.A3
2610942931
|
£2.16
|
£2.59
|
|
59 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A127
2910281203
|
£2.61
|
£3.13
|
|
60 - KNOB
BSD-2610936575.A3
2610936575
|
£1.75
|
£2.10
|
|
61 - HEXAGON SOCKET WRENCH
BSD-2610937464.A3
2610937464
|
£1.75
|
£2.10
|
|
63 - ADJUSTING SCREW
BSD-2610001398.A3
2610001398
|
£1.75
|
£2.10
|
|
64 - SLOTTED SPRING PIN ISO 8752-6x36-A-ST
BSD-2917761253.A0
2917761253
|
£1.75
|
£2.10
|
|
66 - SET RING
BSD-2610937452.A0
2610937452
|
£1.75
|
£2.10
|
|
72 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A293
2603490018
|
£1.75
|
£2.10
|
|
73 - SCREW 4x16
BSD-2603490022.A529
2603490022
|
£1.75
|
£2.10
|
|
74 - SHOULDER SCREW
BSD-2610937508.A0
2610937508
|
£1.75
|
£2.10
|
|
75 - OVAL-HEAD SCREW A 4x12-10.9-D
BSD-2914201503.A4
2914201503
|
£2.16
|
£2.59
|
|
76 - HEX SOCKET HEAD CAP SCREW
BSD-2610937450.A0
2610937450
|
£2.16
|
£2.59
|
|
78 - RAISED CTSK TAPPING SCREW
BSD-2610937451.A0
2610937451
|
£1.75
|
£2.10
|
|
79 - WASHER
BSD-2610386556.A12
2610386556
|
£1.75
|
£2.10
|
|
80 - PLAIN WASHER
BSD-2916011111.A0
2916011111
|
£2.61
|
£3.13
|
|
81 - SHIM RING DIN 988-6x12x0.5
BSD-2916190012.A0
2916190012
|
£1.75
|
£2.10
|
|
82 - WASHER
BSD-2610945804.A3
2610945804
|
£1.75
|
£2.10
|
|
83 - SCREW ST3.9x19
BSD-2610315386.A44
2610315386
|
£1.75
|
£2.10
|
|
87 - ADJUSTMENT KNOB
BSD-2610990806.A22
2610990806
|
£2.41
|
£2.89
|
|
650 - DUST EXTRACTION
BSD-1619P12492.A0
1619P12492
|
£5.30
|
£6.36
|
|
651 - SLIDE-IN ACCU PACKAGE 36V 2.0 Ah Li
BSD-2607336913.A0
2607336913
|
£195.26
|
£234.31
|
|
651 - BATTERY PACK 36V. 2.0Ah. LI
BSD-2607336003.A3
2607336003
|
-
|
|
|
653 - FAST CHARGER EU 230/18-36V. 1h
BSD-2607225099.A5
2607225099
|
£134.16
|
£160.99
|
|
653 - FAST CHARGER GB 230/18-36V. 1h
BSD-2607225902.A26
2607225902
|
£52.49
|
£62.99
|
|
654 - EDGE GUIDE
BSD-2610955166.A3
2610955166
|
£6.52
|
£7.83
|
|
804 - CONTACT RETAINER
BSD-1609280425.A1
1609280425
|
£16.41
|
£19.69
|
|
808 - NAMEPLATE
BSD-2610946106.A0
2610946106
|
£2.33
|
£2.80
|
|
810 - CARBON-BRUSH SET
BSD-2610945334.A0
2610945334
|
£10.10
|
£12.12
|
|
823 - PROTECTIVE COVER
BSD-2610941037.A0
2610941037
|
£31.64
|
£37.97
|
|
825 - BASE PLATE
BSD-2610948882.A0
2610948882
|
£54.42
|
£65.30
|
|
832 - HOOK MOUNTING
BSD-2610945305.A0
2610945305
|
£16.41
|
£19.69
|
|
838 - SPINDLE ASSEMBLY
BSD-2610000765.A0
2610000765
|
£23.86
|
£28.63
|
|
842 - PIVOT PLATE
BSD-2610997509.A3
2610997509
|
£11.30
|
£13.56
|
|
