1 - MOTOR HOUSING
BSD-1605108129.A4
1605108129
|
-
|
|
|
|
2 - FIELD 240V
BSD-1604220356.A14
1604220356
|
£27.23
|
£32.68
|
|
|
4 - ON-OFF SWITCH
BSD-2607200168.A2
2607200168
|
-
|
|
|
|
5 - POWER SUPPLY CORD
BSD-1607000389.A35
1607000389
|
-
|
|
|
|
6 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A242
1600703016
|
£1.75
|
£2.10
|
|
|
7 - CABLE CLIP
BSD-2601035001.A682
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-1601110046.A86
1601110046
|
£1.75
|
£2.10
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328028.A618
1607328028
|
£5.30
|
£6.36
|
|
|
13 - STICKER
BSD-1601110258.A2
1601110258
|
-
|
|
|
|
15 - PROTECTIVE COVER
BSD-1605510127.A11
1605510127
|
-
|
|
|
|
16 - CIRCULAR SAW BLADE
BSD-1608640055.A5
1608640055
|
-
|
|
|
|
17 - BEARING COVER
BSD-1605808059.A6
1605808059
|
-
|
|
|
|
18 - GEAR HOUSING
BSD-1605806412.A1
1605806412
|
-
|
|
|
|
19 - INTERMEDIATE RING
BSD-1600206026.A76
1600206026
|
£1.75
|
£2.10
|
|
|
20 - RETAINING RING DIN 9045 - dia 30MM
BSD-2916600016.A3
2916600016
|
£1.75
|
£2.10
|
|
|
21 - BALL BEARING 9x26x8
BSD-1900905025.A151
1900905025
|
£21.52
|
£25.83
|
|
|
22 - FILLING PIECE
BSD-1605500111.A0
1605500111
|
-
|
|
|
|
23 - AIR-DEFLECTOR RING
BSD-1600502014.A16
1600502014
|
-
|
|
|
|
24 - COMPRESSION SPRING
BSD-1604613006.A92
1604613006
|
£1.75
|
£2.10
|
|
|
25 - SEALING CAP
BSD-1605500109.A11
1605500109
|
-
|
|
|
|
26 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1449
2910021118
|
£1.75
|
£2.10
|
|
|
28 - INTERMEDIATE RING
BSD-1600502011.A117
1600502011
|
£2.61
|
£3.13
|
|
|
29 - BALL BEARING 7x19x6
BSD-2600905032.A36
2600905032
|
£5.30
|
£6.36
|
|
|
30 - HOUSING COVER
BSD-1605500112.A11
1605500112
|
-
|
|
|
|
31 - WIRE GUIDE
BSD-1601025001.A34
1601025001
|
£1.75
|
£2.10
|
|
|
32 - HANDLE
BSD-1605132092.A0
1605132092
|
-
|
|
|
|
33 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A2019
2910211019
|
£1.75
|
£2.10
|
|
|
34 - SUPPORTING DISC
BSD-1600102680.A23
1600102680
|
£1.75
|
£2.10
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A121
2910011157
|
-
|
|
|
|
36 - PROTECTIVE COVER dia 115 MM
BSD-1605510125.A4
1605510125
|
-
|
|
|
|
37 - PLAIN WASHER 0.3 MM
BSD-1600100633.A152
1600100633
|
-
|
|
|
|
38 - PAN HEAD SCREW DIN 923-M5x5-5.8
BSD-2910271147.A30
2910271147
|
-
|
|
|
|
39 - SPIRAL SPRING
BSD-1604652009.A3
1604652009
|
-
|
|
|
|
40 - ROUND-HEAD GROOVED PIN 2.6x3 DIN 1476-ST
BSD-2917721051.A120
2917721051
|
-
|
|
|
|
41 - CONICAL SPRING WASHER SW 46
BSD-1605703069.A99
1605703069
|
-
|
|
|
|
42 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A265
1603414007
|
£2.29
|
£2.75
|
|
|
43 - CONICAL SPRING WASHER
BSD-1605703071.A10
1605703071
|
-
|
|
|
|
44 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A80
2910021154
|
£1.75
|
£2.10
|
|
|
45 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A366
2916680006
|
-
|
|
|
|
46 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A520
1900905163
|
£11.30
|
£13.56
|
|
|
47 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A377
2916660014
|
£1.75
|
£2.10
|
|
|
48 - SPRING WASHER dia27.5xdia34.8x0.5 MM
BSD-1600150008.A25
1600150008
|
-
|
|
|
|
49 - CYLINDRICAL GEAR Z=41
BSD-1606320076.A19
1606320076
|
-
|
|
|
|
50 - DRIVE SHAFT
BSD-1603124105.A5
1603124105
|
-
|
|
|
|
51 - SHIM 0.5 MM
BSD-1600100631.A370
1600100631
|
£1.75
|
£2.10
|
|
|
52 - NEEDLE BEARING
BSD-1600910013.A74
1600910013
|
£5.58
|
£6.70
|
|
|
53 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A100
1603435006
|
-
|
|
|
|
54 - LENS HEAD SCREW
BSD-3603435025.A6
3603435025
|
£1.75
|
£2.10
|
|
|
56 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A230
2910211018
|
£1.75
|
£2.10
|
|
|
57 - BASE PLATE 110x298 MM
BSD-1608000075.A25
1608000075
|
-
|
|
|
|
58 - RUBBER BUFFER
BSD-1602386002.A146
1602386002
|
-
|
|
|
|
59 - PERFORATED PANEL M6-20x10x5 MM
BSD-1601030025.A1
1601030025
|
-
|
|
|
|
60 - PLAIN WASHER dia6.4xdia16x2 MM
BSD-1609201082.A215
1609201082
|
-
|
|
|
|
61 - HEX SOCKET HEAD CAP SCREW DIN 6912 M6x12-8.8
BSD-2910375193.A135
2910375193
|
-
|
|
|
|
62 - RIVING KNIFE
BSD-1600025012.A28
1600025012
|
-
|
|
|
|
63 - WING NUT M6
BSD-1603339006.A37
1603339006
|
£2.52
|
£3.02
|
|
|
64 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A141
2910281201
|
£1.75
|
£2.10
|
|
|
65 - SLIDE PLATE
BSD-1601030026.A65
1601030026
|
-
|
|
|
|
66 - DIAL
BSD-1608000076.A24
1608000076
|
-
|
|
|
|
67 - SPIRAL SPRING
BSD-1604652006.A142
1604652006
|
£1.75
|
£2.10
|
|
|
69 - BLADE TERMINAL
BSD-1604477001.A148
1604477001
|
£1.75
|
£2.10
|
|
|
70 - CLAMPING PIECE
BSD-1601030024.A84
1601030024
|
-
|
|
|
|
71 - COUNTERSUNK-HEAD SCREW M6x20 MM
BSD-1603490000.A31
1603490000
|
-
|
|
|
|
72 - SEAL
BSD-1601015016.A1
1601015016
|
-
|
|
|
|
73 - SEAL RING
BSD-1600206023.A27
1600206023
|
-
|
|
|
|
74 - TAPPING SCREW DIN 7971-B4.8x19
BSD-2910211234.A45
2910211234
|
£1.75
|
£2.10
|
|
|
76 - INTERMEDIATE RING
BSD-1600300089.A2
1600300089
|
£5.30
|
£6.36
|
|
|
77 - ROTARY SHAFT LIP SEAL
BSD-1600290012.A41
1600290012
|
-
|
|
|
|
78 - PLAIN WASHER DIN 433-6.4-ST 50
BSD-2916011013.A80
2916011013
|
£1.75
|
£2.10
|
|
|
81 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A281
1907950006
|
£4.26
|
£5.11
|
|
|
82 - LEAF SPRING
BSD-1601253007.A33
1601253007
|
-
|
|
|
|
84 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A682
2603410001
|
£1.75
|
£2.10
|
|
|
90 - TAB WASHER
BSD-1601030022.A139
1601030022
|
£1.75
|
£2.10
|
|
|
650 - END STOP
BSD-1601336004.A13
1601336004
|
-
|
|
|
|
700/1 - CONICAL SPRING WASHER
BSD-1600120071.A8
1600120071
|
-
|
|
|
|
700/2 - WOBBLING-DISC
BSD-1600132001.A7
1600132001
|
-
|
|
|
|
700/4 - SLOTTED SPRING PIN 3x8 DIN 1481
BSD-2917760075.A23
2917760075
|
-
|
|
|
|
700/5 - WOBBLING-DISC
BSD-1600132002.A8
1600132002
|
-
|
|
|
|
700/6 - DRIVE BUSHING
BSD-1600390009.A2
1600390009
|
-
|
|
|
|
700/7 - HEX SOCKET HEAD CAP SCREW M 6x16 DIN 6912-8.8
BSD-2910372197.A7
2910372197
|
-
|
|
|
|
705 - PARTS SET
BSD-1609200872.A19
1609200872
|
-
|
|
|
|
800 - CARBON BRUSH
BSD-1607014125.A13
1607014125
|
-
|
|
|
|
816 - BRUSH HOLDER
BSD-3604336012.A98
3604336012
|
£5.58
|
£6.70
|
|
|
830 - ARMATURE 240V
BSD-1604010268.A1
1604010268
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1525
160111A3H3
|
£2.61
|
£3.13
|
|
