2 - FIELD 220-240V
BSD-1604220357.A3
1604220357
|
£40.80
|
£48.96
|
|
|
3/50 - FAN
BSD-3606610002.A24
3606610002
|
£2.33
|
£2.80
|
|
|
6 - GROMMET dia8.8-dia9.0x70 MM
BSD-1600703024.A44
1600703024
|
-
|
|
|
|
7 - CABLE CLIP
BSD-1611035005.A293
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A91
1601110483
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A631
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A20
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-1610905009.A51
1610905009
|
£14.72
|
£17.67
|
|
|
16 - BRUSH HOLDER
BSD-1604336024.A20
1604336024
|
£14.75
|
£17.70
|
|
|
21 - MANUFACTURER'S NAMEPLATE
BSD-1601110638.A2
1601110638
|
-
|
|
|
|
22 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A62
2912401019
|
£1.75
|
£2.10
|
|
|
24 - PROTECTIVE COVER
BSD-1605510157.A13
1605510157
|
£14.72
|
£17.67
|
|
|
25 - CIRCULAR SAW BLADE
BSD-1608640086.A14
1608640086
|
-
|
|
|
|
26 - BEARING FLANGE
BSD-1605808065.A18
1605808065
|
£11.78
|
£14.13
|
|
|
27 - INTERMEDIATE RING
BSD-1600221003.A17
1600221003
|
£2.61
|
£3.13
|
|
|
28 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A659
2603410001
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-3600591001.A3
3600591001
|
-
|
|
|
|
31 - SEALING CAP
BSD-1605500156.A12
1605500156
|
-
|
|
|
|
32 - INTERMEDIATE RING
BSD-1600502011.A125
1600502011
|
£2.61
|
£3.13
|
|
|
33 - SLOTTED SPRING PIN 6x22 DIN7346
BSD-2917780150.A25
2917780150
|
£1.75
|
£2.10
|
|
|
34 - SPEED GOVERNOR 220-240V
BSD-1607233030.A4
1607233030
|
-
|
|
|
|
35 - HANDLE COVER
BSD-1605500153.A4
1605500153
|
-
|
|
|
|
36 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A157
2603435042
|
£1.75
|
£2.10
|
|
|
39 - CONICAL SPRING WASHER
BSD-1605703107.A35
1605703107
|
£3.72
|
£4.47
|
|
|
40 - CLAMPING-FLANGE dia 12x30 MM
BSD-1605703091.A6
1605703091
|
-
|
|
|
|
41 - THREAD-FORMING TAP. SCREW DIN 7500-M 4x12
BSD-2914491409.A73
2914491409
|
£1.66
|
£1.99
|
|
|
43 - SPRING RETAINING RING DIN 471-40x1.75-FST
BSD-2916650020.A37
2916650020
|
-
|
|
|
|
44 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A284
1603414007
|
£2.29
|
£2.75
|
|
|
45 - CYLINDRICAL GEAR Z=41
BSD-1606320081.A8
1606320081
|
-
|
|
|
|
47 - EXTENSION SPRING
BSD-1604649001.A28
1604649001
|
-
|
|
|
|
48 - NOZZLE SOCKET
BSD-1600910019.A13
1600910019
|
£3.34
|
£4.01
|
|
|
50 - GUIDE BUSHING
BSD-1600309011.A24
1600309011
|
-
|
|
|
|
51 - BASE PLATE 170x382 MM
BSD-1608000105.A9
1608000105
|
-
|
|
|
|
52 - RUBBER BUFFER
BSD-1600305001.A33
1600305001
|
£1.75
|
£2.10
|
|
|
53 - SPACER BUSHING
BSD-1600309012.A8
1600309012
|
£1.75
|
£2.10
|
|
|
54 - RIVING KNIFE
BSD-1600025013.A7
1600025013
|
£3.34
|
£4.01
|
|
|
55 - WING NUT M6
BSD-1603339006.A370
1603339006
|
£2.52
|
£3.02
|
|
|
56 - SPACER BUSHING dia33xdia6.2xdia14.7 MM
BSD-1600309013.A26
1600309013
|
-
|
|
|
|
57 - PAN HEAD SCREW M6x170 MM
BSD-1603434005.A19
1603434005
|
-
|
|
|
|
58 - ADJUSTING PLATE
BSD-1601329015.A16
1601329015
|
£1.95
|
£2.34
|
|
|
62 - THRUST MEMBER
BSD-1608040112.A25
1608040112
|
-
|
|
|
|
63 - WING SCREW
BSD-1603480022.A27
1603480022
|
-
|
|
|
|
64 - ROUND-HEAD BOLT M6x35 MM
BSD-1603434006.A19
1603434006
|
-
|
|
|
|
66 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A271
1907950006
|
£4.26
|
£5.11
|
|
|
67 - SUPPRESSOR BOX
BSD-1604503014.A42
1604503014
|
-
|
|
|
|
68 - INTERMEDIATE RING
BSD-1600300092.A13
1600300092
|
£1.32
|
£1.58
|
|
|
69 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A449
1600290016
|
£2.61
|
£3.13
|
|
|
70 - BLADE TERMINAL
BSD-1604477005.A75
1604477005
|
£2.61
|
£3.13
|
|
|
73 - MITER SQUARE
BSD-1608190009.A14
1608190009
|
-
|
|
|
|
74 - THREAD-FORMING TAP. SCREW TT M5x30 MM
BSD-1603435022.A11
1603435022
|
£1.75
|
£2.10
|
|
|
77 - PAN HEAD SCREW DIN 923-M4x10-5.8
BSD-2910271120.A7
2910271120
|
£1.32
|
£1.58
|
|
|
80 - O-RING 46.0x1.1 MM
BSD-1600210035.A45
1600210035
|
£1.75
|
£2.10
|
|
|
650 - PARALLEL-GUIDE
BSD-2608005036.A68
2608005036
|
£8.67
|
£10.41
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A83
1607014129
|
£16.41
|
£19.69
|
|
|
801 - SPIRAL SPRING
BSD-2604652008.A27
2604652008
|
-
|
|
|
|
804 - ON-OFF SWITCH
BSD-1607000231.A73
1607000231
|
£18.96
|
£22.75
|
|
|
810 - PARTS SET
BSD-1607000923.A6
1607000923
|
-
|
|
|
|
810 - HANDLE COVER
BSD-1607000925.A4
1607000925
|
-
|
|
|
|
830 - ARMATURE 220-240V
BSD-1604010339.A5
1604010339
|
-
|
|
|
|
835 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H05VV-F
BSD-2604460102.A16
2604460102
|
-
|
|
|
|
837 - PIVOTING BLADE GUARD
BSD-1605510172.A21
1605510172
|
-
|
|
|
|
840 - CLAMPING-FLANGE
BSD-1605703093.A17
1605703093
|
-
|
|
|
|
846 - PARTS SET dia 12 MM. M6
BSD-1607000225.A17
1607000225
|
-
|
|
|
|
859 - PARTS SET
BSD-1607000197.A49
1607000197
|
-
|
|
|
|
872 - PARTS SET
BSD-1607000222.A11
1607000222
|
-
|
|
|
|
878 - PARTS SET
BSD-1607000205.A44
1607000205
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1509
160111A3H3
|
£2.61
|
£3.13
|
|
|
899 - GREASE TUBE 225 ML
BSD-1605430003.A188
1605430003
|
£33.74
|
£40.49
|
|
