1 - MOTOR HOUSING
BSD-1605108218.A3
1605108218
|
-
|
|
|
|
2 - FIELD 230V
BSD-1604220346.A2
1604220346
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-1607200198.A11
1607200198
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A764
2600703017
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118B10.A1
1601118B10
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A674
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A105
2600905032
|
£5.30
|
£6.36
|
|
|
15 - FAN
BSD-1606610145.A26
1606610145
|
£2.80
|
£3.36
|
|
|
16 - BRUSH PLATE
BSD-1604336043.A5
1604336043
|
£7.78
|
£9.33
|
|
|
21 - PROTECTIVE COVER
BSD-1605510300.A3
1605510300
|
£36.63
|
£43.96
|
|
|
22 - BASE PLATE
BSD-1608000119.A4
1608000119
|
£14.91
|
£17.89
|
|
|
23 - HANDLE
BSD-1605500218.A0
1605500218
|
-
|
|
|
|
24 - PIVOTING BLADE GUARD
BSD-1605510271.A3
1605510271
|
£14.91
|
£17.89
|
|
|
25 - CONTACT SPRING
BSD-1601290010.A15
1601290010
|
£1.75
|
£2.10
|
|
|
26 - CONNECTING CABLE
BSD-1604449023.A2
1604449023
|
£6.61
|
£7.93
|
|
|
27 - CONNECTING PIPING
BSD-1604449017.A0
1604449017
|
£2.16
|
£2.59
|
|
|
28 - CONNECTING CABLE
BSD-1604449013.A8
1604449013
|
£1.75
|
£2.10
|
|
|
29 - SAFETY CATCH
BSD-1601900005.A5
1601900005
|
£1.95
|
£2.34
|
|
|
30 - FELT SEAL
BSD-1601015033.A2
1601015033
|
£1.75
|
£2.10
|
|
|
31 - COMPRESSION SPRING
BSD-1604610018.A2
1604610018
|
£1.75
|
£2.10
|
|
|
32 - PUSH-BUTTON
BSD-1603231019.A50
1603231019
|
-
|
|
|
|
36 - DRIVE SHAFT
BSD-1603124133.A5
1603124133
|
£10.10
|
£12.12
|
|
|
37 - CYLINDRICAL GEAR
BSD-1606320600.A13
1606320600
|
£5.87
|
£7.04
|
|
|
38 - GROOVE BALL BEARING 12x28x8
BSD-1600905031.A64
1600905031
|
£6.52
|
£7.83
|
|
|
39 - SPEED GOVERNOR 230-240V
BSD-1607233131.A0
1607233131
|
-
|
|
|
|
40 - MITER SQUARE
BSD-1608190024.A2
1608190024
|
£2.33
|
£2.80
|
|
|
41 - BOW
BSD-1601329034.A1
1601329034
|
£7.78
|
£9.33
|
|
|
42 - GUIDE BRACKET
BSD-1601329035.A4
1601329035
|
£6.61
|
£7.93
|
|
|
43 - SPACER TUBE
BSD-1600360003.A3
1600360003
|
£5.58
|
£6.70
|
|
|
44 - TENSIONING LEVER
BSD-1602002006.A55
1602002006
|
£1.75
|
£2.10
|
|
|
45 - RUBBER BUFFER
BSD-1600305001.A29
1600305001
|
£1.75
|
£2.10
|
|
|
46 - CLAMP RING
BSD-1600102025.A3
1600102025
|
£1.32
|
£1.58
|
|
|
47 - EXTENSION SPRING
BSD-1604650015.A1
1604650015
|
-
|
|
|
|
48 - CLAMPING-FLANGE
BSD-1605703126.A1
1605703126
|
-
|
|
|
|
49 - CIRCULAR SAW BLADE
BSD-1608640086.A3
1608640086
|
-
|
|
|
|
50 - CONICAL SPRING WASHER
BSD-1605703107.A27
1605703107
|
£3.72
|
£4.47
|
|
|
51 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A307
1603414007
|
£2.29
|
£2.75
|
|
|
52 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A258
1907950006
|
£4.26
|
£5.11
|
|
|
53 - RIVING KNIFE
BSD-1600025021.A3
1600025021
|
-
|
|
|
|
54 - WING NUT M6
BSD-1603339006.A118
1603339006
|
£2.52
|
£3.02
|
|
|
55 - WING SCREW M6
BSD-1603480018.A62
1603480018
|
£2.16
|
£2.59
|
|
|
57 - SCREW 4x16
BSD-2603490022.A1325
2603490022
|
£1.75
|
£2.10
|
|
|
58 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A360
1613435034
|
£1.75
|
£2.10
|
|
|
60 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A150
2910281201
|
£1.75
|
£2.10
|
|
|
62 - PLAIN WASHER
BSD-2916011894.A45
2916011894
|
£1.75
|
£2.10
|
|
|
63 - CARRYING PLATE
BSD-1600098006.A1
1600098006
|
£8.49
|
£10.19
|
|
|
64 - THREAD-FORMING TAP. SCREW DIN 7500-M 4x12
BSD-2914491409.A58
2914491409
|
£1.66
|
£1.99
|
|
|
65 - COVER
BSD-1605510301.A1
1605510301
|
£21.42
|
£25.71
|
|
|
66 - ROUND-HEAD BOLT M6x2-P1x20
BSD-1603434009.A0
1603434009
|
£1.32
|
£1.58
|
|
|
650 - PARALLEL-GUIDE
BSD-2608005036.A55
2608005036
|
£8.67
|
£10.41
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1604010773.A0
1604010773
|
£80.61
|
£96.73
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A165
1607000386
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1289
160111A3H3
|
£2.61
|
£3.13
|
|
|
816 - CARBON-BRUSH SET
BSD-1607014176.A297
1607014176
|
£13.12
|
£15.75
|
|
|
818 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A360
2603410001
|
£1.75
|
£2.10
|
|
|
834 - BEARING BRACKET
BSD-1605808070.A4
1605808070
|
£12.04
|
£14.45
|
|
|
899 - GREASE TUBE 225 ML
BSD-1605430003.A198
1605430003
|
£33.74
|
£40.49
|
|
