1 - GEARCASE SA INCL.495051
BDE-613138-00SV.A8
613138-00SV
|
£47.08
|
£56.49
|
|
|
2 - ARMATURE SA
BDE-617376-00SV.A3
617376-00SV
|
£78.12
|
£93.74
|
|
|
3 - SCREW
BDE-142940-00.A7
142940-00
|
£1.50
|
£1.80
|
|
|
4 - BAFFLE FAN
BDE-613137-00.A0
613137-00
|
£3.22
|
£3.86
|
|
|
5 - SCREW
BDE-613619-00.A18
613619-00
|
£1.50
|
£1.80
|
|
|
6 - MAGNET
BDE-611202-00SV.A32
611202-00SV
|
-
|
|
|
|
7 - SUPPORT BEARING
BDE-N171820.A31
N171820
|
-
|
|
|
|
8 - SCREW
BDE-330019-25.A7
330019-25
|
£1.50
|
£1.80
|
|
|
9 - BRUSHBOX SA
BDE-610126-00.A21
610126-00
|
£7.85
|
£9.42
|
|
|
10 - GEAR & SPINDLE
BDE-615940-00SV.A4
615940-00SV
|
£41.24
|
£49.49
|
|
|
11 - WASHER SPECIAL
BDE-619618-00.A3
619618-00
|
£1.50
|
£1.80
|
|
|
12 - SCREW
BDE-622484-00.A7
622484-00
|
£1.50
|
£1.80
|
|
|
13 - SUPPORT PLATE
BDE-621173-00.A5
621173-00
|
£1.50
|
£1.80
|
|
|
14 - GEARCASE COVER
BDE-N027851SV.A2
N027851SV
|
£34.00
|
£40.80
|
|
|
15 - STRIP
BDE-621979-00.A11
621979-00
|
£1.50
|
£1.80
|
|
|
16 - SEAL
BDE-618733-00.A12
618733-00
|
£1.50
|
£1.80
|
|
|
17 - FELT SEAL
BDE-618477-00.A0
618477-00
|
£1.50
|
£1.80
|
|
|
18 - COVERPLATE
BDE-N020720.A0
N020720
|
£1.50
|
£1.80
|
|
|
19 - SCREW
BDE-330045-43.A27
330045-43
|
£1.50
|
£1.80
|
|
|
20 - SHAFT SA
BDE-N026647.A6
N026647
|
£38.80
|
£46.56
|
|
|
21 - BALL
BDE-000903-00.A118
000903-00
|
£12.17
|
£14.60
|
|
|
22 - SLIDER TO 201609
BDE-622647-00.A12
622647-00
|
£4.69
|
£5.63
|
|
|
22 - SLIDER FROM 201609
BDE-N252639.A8
N252639
|
£7.85
|
£9.42
|
|
|
23 - SPRING TORSION TO 201609
BDE-622659-00.A4
622659-00
|
£1.50
|
£1.80
|
|
|
23 - SPRING FROM 201609
BDE-N426742.A9
N426742
|
£1.50
|
£1.80
|
|
|
24 - SHAFT SA
BDE-N026647.A5
N026647
|
£38.80
|
£46.56
|
|
|
25 - SADDLE
BDE-617000-00.A1
617000-00
|
£3.30
|
£3.96
|
|
|
26 - SCREW
BDE-622486-00.A4
622486-00
|
£1.50
|
£1.80
|
|
|
27 - GASKET
BDE-N063272.A9
N063272
|
£1.50
|
£1.80
|
|
|
28 - BEARING
BDE-N021857.A9
N021857
|
£9.41
|
£11.29
|
|
|
29 - LOCK NUT
BDE-622485-00.A6
622485-00
|
£1.50
|
£1.80
|
|
|
30 - COVER
BDE-621927-00.A1
621927-00
|
£1.50
|
£1.80
|
|
|
31 - INSERT
BDE-N030977.A0
N030977
|
£2.78
|
£3.34
|
|
|
32 - HOUSING MOTOR
BDE-613143-01.A0
613143-01
|
-
|
|
|
|
33 - SCREW
BDE-330019-45.A13
330019-45
|
£1.50
|
£1.80
|
|
|
34 - BOOT
BDE-N084697.A2
N084697
|
£10.85
|
£13.02
|
|
|
35 - LEVER
BDE-N102371
N102371
|
£9.17
|
£11.00
|
|
|
36 - RING
BDE-050049-00.A50
050049-00
|
£1.50
|
£1.80
|
|
|
37 - BRACKET
BDE-617008-00.A2
617008-00
|
£1.50
|
£1.80
|
|
|
38 - SHOE SA
BDE-623511-00SV.A5
623511-00SV
|
£38.80
|
£46.56
|
|
|
39 - HANDLE SA
BDE-N093946
N093946
|
£19.40
|
£23.28
|
|
|
40 - SCREW
BDE-90611830.A165
90611830
|
£1.50
|
£1.80
|
|
|
41 - SCREW
BDE-682211-00.A212
682211-00
|
£1.50
|
£1.80
|
|
|
42 - SWITCH VARIABLE PRE EMI GB
BDE-N102245
N102245
|
£116.32
|
£139.59
|
|
|
43 - SPRING
BDE-N102647.A0
N102647
|
£1.50
|
£1.80
|
|
|
44 - BLOCK
BDE-N122099.A20
N122099
|
£1.50
|
£1.80
|
|
|
45 - BUTTON LOCK-OFF
BDE-N060864.A0
N060864
|
£1.50
|
£1.80
|
|
|
46 - BRAND LABEL
BDE-N102491
N102491
|
£2.71
|
£3.25
|
|
|
47 - RATING PLATE GB
BDE-N098564
N098564
|
£3.22
|
£3.86
|
|
|
48 - SCREW
BDE-330045-45.A62
330045-45
|
£1.50
|
£1.80
|
|
|
49 - LOCK PIN
BDE-615983-00.A8
615983-00
|
£1.50
|
£1.80
|
|
|
50 - CAP
BDE-617733-00.A6
617733-00
|
£1.50
|
£1.80
|
|
|
51 - SPRING
BDE-618427-00.A10
618427-00
|
£1.50
|
£1.80
|
|
|
52 - BEARING & SEAL
BDE-391032-00.A23
391032-00
|
£3.80
|
£4.56
|
|
|
53 - BEARING
BDE-330003-64.A96
330003-64
|
£4.69
|
£5.63
|
|
|
54 - RETAINER
BDE-696060-00.A33
696060-00
|
£1.50
|
£1.80
|
|
|
73 - WARNING LABEL
BDE-N105032.A2
N105032
|
£1.42
|
£1.70
|
|
|
800 - GREASE
BDE-286436-00.A279
286436-00
|
£126.63
|
£151.96
|
|
|
861 - KITBOX
BDE-N152704.A5
N152704
|
£44.14
|
£52.97
|
|
|
866 - BATTERY 14.4V - 4.0AH DCS320L2 GB
BDE-N195932.A20
N195932
|
£144.10
|
£172.92
|
|
|
866 - BATTERY 14.4V - 4.0AH DCS320M2 GB
BDE-N195932.A21
N195932
|
£144.10
|
£172.92
|
|
|
871 - CHARGER 10.8V - 18V GB
BDE-N450537.A64
N450537
|
£157.18
|
£188.61
|
|
