1 - MOTOR HOUSING
BSD-3605102058.A37
3605102058
|
£120.11
|
£144.13
|
|
2 - SEAL RING
BSD-1600209011.A126
1600209011
|
£2.80
|
£3.36
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A275
1600502005
|
£2.61
|
£3.13
|
|
5 - ROTOR WITHOUT WINDING
BSD-3604080023.A1
3604080023
|
-
|
|
|
5/3 - FAN
BSD-1606610105.A53
1606610105
|
£14.91
|
£17.89
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A274
1900905015
|
£30.42
|
£36.51
|
|
7 - O-RING 12.0x2.25 MM
BSD-3600210039.A110
3600210039
|
£7.36
|
£8.83
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1610905011.A11
1610905011
|
£14.91
|
£17.89
|
|
9 - BEARING HOUSING
BSD-3605820039.A1
3605820039
|
-
|
|
|
11 - HANDLE
BSD-3605132044.A24
3605132044
|
-
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3604462049.A16
3604462049
|
-
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1278
3600703011
|
£2.80
|
£3.36
|
|
14 - FASTENING CLAMP
BSD-1601302014.A702
1601302014
|
£2.61
|
£3.13
|
|
15 - CONNECTION HOUSING
BSD-3600099005.A5
3600099005
|
£16.41
|
£19.69
|
|
16 - REVERSING SWITCH
BSD-1607200043.A48
1607200043
|
-
|
|
|
17 - SWITCH
BSD-1607200038.A139
1607200038
|
£54.42
|
£65.30
|
|
18 - PRESSURE SPINDLE
BSD-1603203024.A44
1603203024
|
-
|
|
|
19 - SEALING CAP
BSD-3605500071.A46
3605500071
|
£16.41
|
£19.69
|
|
20 - GEAR HOUSING
BSD-3605806106.A3
3605806106
|
-
|
|
|
21 - CYLINDRICAL GEAR Z=43
BSD-1606325021.A8
1606325021
|
-
|
|
|
22 - SPINDLE WITH GEAR Z=11
BSD-1606308017.A27
1606308017
|
-
|
|
|
23 - CARRIER
BSD-3606445022.A8
3606445022
|
-
|
|
|
24 - COUPLING HALF
BSD-1606455069.A8
1606455069
|
-
|
|
|
25 - TAPER RING
BSD-1600250000.A3
1600250000
|
-
|
|
|
26 - THREADED BUSHING
BSD-3600364010.A9
3600364010
|
-
|
|
|
27 - CYLINDRICAL GEAR Z=31
BSD-3606319014.A4
3606319014
|
-
|
|
|
28 - COMPRESSION SPRING
BSD-1604619015.A15
1604619015
|
£5.01
|
£6.01
|
|
29 - ROLLER
BSD-1603200019.A16
1603200019
|
-
|
|
|
30 - RETAINING SNAP RING
BSD-2600209018.A8
2600209018
|
-
|
|
|
31 - HOLDING SPRING
BSD-3604682003.A59
3604682003
|
-
|
|
|
32 - COMPRESSION SPRING
BSD-1604612005.A11
1604612005
|
-
|
|
|
34 - DISC SPRING
BSD-3600150013.A24
3600150013
|
£3.72
|
£4.47
|
|
36 - SHIM 0.50 MM
BSD-2600100613.A206
2600100613
|
£1.75
|
£2.10
|
|
39 - NAMEPLATE
BSD-3601106053.A12
3601106053
|
£5.30
|
£6.36
|
|
40 - GROOVED NAIL
BSD-3603133000.A174
3603133000
|
£2.61
|
£3.13
|
|
41 - SPRING WASHER DIN 137-A5-FST
BSD-2916060006.A107
2916060006
|
£1.32
|
£1.58
|
|
42 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A294
2916060003
|
£1.32
|
£1.58
|
|
43 - CLAMPING SADDLE
BSD-3601321001.A778
3601321001
|
£3.72
|
£4.47
|
|
44 - SPRING WASHER dia4.2 MM
BSD-3600150006.A401
3600150006
|
£2.61
|
£3.13
|
|
45 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A215
2910110118
|
£1.75
|
£2.10
|
|
46 - PAN HEAD SCREW DIN 85-AM3x5-4.8
BSD-2910091047.A7
2910091047
|
£1.75
|
£2.10
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A168
2910021116
|
£2.16
|
£2.59
|
|
48 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A797
2910021122
|
£2.16
|
£2.59
|
|
50 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A2
2910141131
|
£2.16
|
£2.59
|
|
51 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A91
2910141140
|
£1.75
|
£2.10
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A103
2910011162
|
£1.75
|
£2.10
|
|
54 - BALL DIN 5401-8 MM III-ST
BSD-1903230014.A130
1903230014
|
£1.75
|
£2.10
|
|
55 - BALL DIN 5401-6 G28
BSD-1903230011.A10
1903230011
|
£2.61
|
£3.13
|
|
56 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A443
1903230006
|
£2.16
|
£2.59
|
|
57 - END SPLICE
BSD-3604477008.A111
3604477008
|
£1.75
|
£2.10
|
|
60 - RETAINING RING 10 DIN 9045
BSD-2916600006.A66
2916600006
|
£1.75
|
£2.10
|
|
62 - CONTROL SHAFT
BSD-1603124099.A16
1603124099
|
-
|
|
|
63 - GUIDE BUSHING
BSD-1600521018.A28
1600521018
|
-
|
|
|
64 - COMPRESSION SPRING
BSD-1604616019.A9
1604616019
|
-
|
|
|
66 - SET SCREW
BSD-3603402000.A123
3603402000
|
£1.75
|
£2.10
|
|
67 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A442
1903230006
|
£2.16
|
£2.59
|
|
69 - BUSHING
BSD-2600300058.A133
2600300058
|
-
|
|
|
70 - CLAMP BUSHING
BSD-1600300081.A29
1600300081
|
-
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A49
3600190012
|
-
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A129
2910780050
|
-
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A203
1600210045
|
£1.75
|
£2.10
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1801
3601119236
|
£3.72
|
£4.47
|
|
650 - SLOTTED SCREWDRIVER
BSD-1607950037.A19
1607950037
|
£51.22
|
£61.47
|
|
800 - GEAR HOUSING
BSD-3605806013.A25
3605806013
|
-
|
|
|
801 - MOTOR HOUSING
BSD-3605102028.A4
3605102028
|
£156.22
|
£187.46
|
|
802 - CARRIER
BSD-3606445017.A2
3606445017
|
-
|
|
|
804 - SPINDLE WITH GEAR Z=31/11
BSD-3606328014.A0
3606328014
|
-
|
|
|
809 - BEARING HOUSING
BSD-3605820034.A5
3605820034
|
-
|
|
|
810 - STATOR 265V/200HZ. 200V/150HZ
BSD-1604229200.A40
1604229200
|
£458.51
|
£550.21
|
|
