1 - HOUSING SECTION
BSD-2605104416.A2
2605104416
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-2604220518.A3
2604220518
|
-
|
|
|
|
3/60 - FAN
BSD-2606610083.A11
2606610083
|
£5.30
|
£6.36
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A152
2600703017
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2208
2601035001
|
£1.75
|
£2.10
|
|
|
8 - NAMEPLATE
BSD-2601118946.A0
2601118946
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118953.A3
2601118953
|
-
|
|
|
|
11 - CONNECTING CABLE L = 37 MM
BSD-2604448178.A9
2604448178
|
-
|
|
|
|
12 - CONNECTING CABLE L=52MM
BSD-2604448016.A62
2604448016
|
£1.75
|
£2.10
|
|
|
13 - NEEDLE BEARING
BSD-2600917002.A88
2600917002
|
£3.72
|
£4.47
|
|
|
16 - CONNECTION PLATE 230V
BSD-1607233095.A2
1607233095
|
-
|
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1833
2603490022
|
£1.75
|
£2.10
|
|
|
27 - GROOVE BALL BEARING 8x24x7
BSD-2600905060.A4
2600905060
|
-
|
|
|
|
33 - FLEXIBLE CONNECTION
BSD-2600712003.A8
2600712003
|
-
|
|
|
|
34 - CONTACT SPRING
BSD-2601329037.A87
2601329037
|
£1.75
|
£2.10
|
|
|
36 - COMPRESSION SPRING
BSD-2604610034.A8
2604610034
|
-
|
|
|
|
37 - SWITCH SLIDE
BSD-2602319008.A7
2602319008
|
-
|
|
|
|
38 - DAMPING RUBBER
BSD-2603100056.A16
2603100056
|
£1.75
|
£2.10
|
|
|
44 - CONNECTING CABLE L=88 MM
BSD-2604448034.A73
2604448034
|
£1.75
|
£2.10
|
|
|
45 - THRUST MEMBER
BSD-2600590010.A7
2600590010
|
-
|
|
|
|
46 - CLAMPING RING
BSD-2600290025.A4
2600290025
|
-
|
|
|
|
803 - ARMATURE 230-240V
BSD-2604010931.A9
2604010931
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 2.65m 2 x 1.0mm H05 RN-F
BSD-1607000388.A133
1607000388
|
£12.04
|
£14.45
|
|
|
810 - CARBON-BRUSH SET
BSD-2607014010.A11
2607014010
|
-
|
|
|
|
826 - NEEDLE-ROLLER BEARING
BSD-2600917007.A7
2600917007
|
-
|
|
|
|
830 - LOCATING WASHER
BSD-2608000144.A0
2608000144
|
-
|
|
|
|
831 - BASE PLATE
BSD-2601098901.A6
2601098901
|
-
|
|
|
|
832 - SANDER PLATE
BSD-2608000149.A13
2608000149
|
£11.12
|
£13.35
|
|
|
840 - FLEXIBLE SHAFT
BSD-2603010002.A4
2603010002
|
-
|
|
|
|
847 - BACKUP RING
BSD-2608005068.A11
2608005068
|
£1.32
|
£1.58
|
|
