1 - MOTOR HOUSING
BSD-2605104295.A10
2605104295
|
-
|
|
|
|
2 - FIELD 220-240V
BSD-1604220254.A35
1604220254
|
£22.76
|
£27.31
|
|
|
3 - ARMATURE 230-240V
BSD-2604010739.A45
2604010739
|
-
|
|
|
|
3/60 - FAN
BSD-2606610029.A185
2606610029
|
£2.74
|
£3.29
|
|
|
4 - SWITCH
BSD-2607200190.A3
2607200190
|
£54.42
|
£65.30
|
|
|
4 - ON-OFF SWITCH
BSD-2607200224.A18
2607200224
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 230V 2.65m 2 x 1.0mm H05 VV-F
BSD-2604460147.A73
2604460147
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1053
2600703012
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-2601035001.A605
2601035001
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601119415.A5
2601119415
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A210
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A661
1900905018
|
£19.91
|
£23.89
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A263
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A562
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1436
2603490022
|
£1.84
|
£2.21
|
|
|
20 - REFERENCE PLATE
BSD-2601119413.A13
2601119413
|
-
|
|
|
|
24 - DRILLING SPINDLE 1/2
BSD-2606135013.A9
2606135013
|
£21.42
|
£25.71
|
|
|
26 - COMPRESSION SPRING
BSD-2604616002.A83
2604616002
|
£1.84
|
£2.21
|
|
|
27 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A562
1900905163
|
£11.30
|
£13.56
|
|
|
28 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A421
2916660014
|
£1.75
|
£2.10
|
|
|
29 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A402
2916650008
|
£1.84
|
£2.21
|
|
|
30 - FLAT KEY
BSD-2602300028.A6
2602300028
|
-
|
|
|
|
31 - RETAINING WASHER
BSD-2600101671.A258
2600101671
|
£1.84
|
£2.21
|
|
|
32 - SHIM 1.0 MM
BSD-2600101515.A86
2600101515
|
£2.05
|
£2.46
|
|
|
33 - CYLINDRICAL GEAR Z=48
BSD-2606317063.A2
2606317063
|
-
|
|
|
|
34 - CYLINDRICAL GEAR Z=36
BSD-2606317062.A6
2606317062
|
-
|
|
|
|
35 - SHIM 0.5 MM
BSD-2600101616.A391
2600101616
|
-
|
|
|
|
35 - SHIM 0.3 MM
BSD-2600101617.A24
2600101617
|
£1.84
|
£2.21
|
|
|
36 - CATCH DISK
BSD-2600190070.A7
2600190070
|
£5.58
|
£6.70
|
|
|
37 - CATCH DISK
BSD-2600190063.A5
2600190063
|
£5.87
|
£7.04
|
|
|
38 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A657
2600917003
|
£2.94
|
£3.53
|
|
|
39 - SHIM WASHER 0.2 MM
BSD-2600000012.A14
2600000012
|
£1.75
|
£2.10
|
|
|
39 - SHIM WASHER 0.5 MM
BSD-2600000014.A102
2600000014
|
£1.84
|
£2.21
|
|
|
39 - SHIM WASHER 1.35 MM
BSD-2600000030.A136
2600000030
|
£1.75
|
£2.10
|
|
|
40 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A522
1903230010
|
£1.84
|
£2.21
|
|
|
41 - ROTARY KNOB
BSD-2602026017.A80
2602026017
|
£7.72
|
£9.27
|
|
|
42 - SLOTTED SPRING PIN 4x30 MM DIN 7346
BSD-2917780105.A124
2917780105
|
£1.75
|
£2.10
|
|
|
44 - COVER DISC
BSD-2601328033.A6
2601328033
|
-
|
|
|
|
45 - TAPPING SCREW
BSD-2603435086.A237
2603435086
|
£1.84
|
£2.21
|
|
|
46 - HOUSING COVER
BSD-2605132048.A12
2605132048
|
-
|
|
|
|
47 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A184
2604465097
|
£5.58
|
£6.70
|
|
|
48 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1107
2603490017
|
£2.27
|
£2.72
|
|
|
49 - SHIM
BSD-2600150004.A227
2600150004
|
£2.27
|
£2.72
|
|
|
50 - SHIM WASHER 0.2 MM
BSD-2600101665.A71
2600101665
|
£1.84
|
£2.21
|
|
|
50 - SHIM WASHER 0.5 MM
BSD-2600101667.A164
2600101667
|
£1.84
|
£2.21
|
|
|
50 - SHIM WASHER 0.3 MM
BSD-2600101027.A65
2600101027
|
£1.84
|
£2.21
|
|
|
51 - CABLE L=130 MM
BSD-2604448005.A323
2604448005
|
£1.84
|
£2.21
|
|
|
52 - EARTH CONDUCTOR
BSD-2604448097.A118
2604448097
|
£1.84
|
£2.21
|
|
|
53 - CHANGE-OVER SWITCH
BSD-2607200231.A187
2607200231
|
£17.22
|
£20.67
|
|
|
54 - SPRING RETAINING RING DIN 472-24x1.2 MM
BSD-2916660008.A667
2916660008
|
£2.16
|
£2.59
|
|
|
55 - CUPPED WASHER
BSD-2600500002.A398
2600500002
|
£1.75
|
£2.10
|
|
|
56 - FELT WASHER
BSD-2600108077.A305
2600108077
|
£1.84
|
£2.21
|
|
|
57 - RECEPTACLE
BSD-2600400008.A166
2600400008
|
£1.75
|
£2.10
|
|
|
61 - SHIM 0.3 MM
BSD-2600100607.A762
2600100607
|
£1.75
|
£2.10
|
|
|
62 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A746
2600914010
|
£2.94
|
£3.53
|
|
|
63 - HEADLESS SCREW
BSD-2603435070.A41
2603435070
|
£2.16
|
£2.59
|
|
|
64 - HEADLESS SCREW 65 MM
BSD-2603435071.A60
2603435071
|
-
|
|
|
|
66 - ADJUSTING SLIDE
BSD-2602033006.A32
2602033006
|
£2.94
|
£3.53
|
|
|
68 - SHIM WASHER
BSD-2600100618.A281
2600100618
|
£1.84
|
£2.21
|
|
|
69 - ROTARY KNOB
BSD-2602026038.A66
2602026038
|
-
|
|
|
|
71 - RATCHET CAP
BSD-2600590006.A858
2600590006
|
£1.84
|
£2.21
|
|
|
72 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A80
2604465086
|
£5.58
|
£6.70
|
|
|
73 - CONNECTING CABLE L=110 MM
BSD-2604448146.A61
2604448146
|
£1.84
|
£2.21
|
|
|
75 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A396
2603490024
|
£1.84
|
£2.21
|
|
|
77 - CONNECTING CABLE L=68 MM
BSD-2604448100.A7
2604448100
|
£1.75
|
£2.10
|
|
|
78 - CONNECTING CABLE L=98 MM
BSD-2604448074.A39
2604448074
|
£2.16
|
£2.59
|
|
|
79 - RETAINING RING
BSD-2604601004.A603
2604601004
|
£1.75
|
£2.10
|
|
|
81 - STICKER
BSD-2601110117.A16
2601110117
|
-
|
|
|
|
82 - GASKET
BSD-2601073012.A53
2601073012
|
£1.75
|
£2.10
|
|
|
753 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A475
1619P10682
|
£12.49
|
£14.99
|
|
|
753/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1377
2915011007
|
-
|
|
|
|
753/30 - WING SCREW M6x(15)55
BSD-1613480007.A252
1613480007
|
£1.75
|
£2.10
|
|
|
753/50 - CLAMPING PLATE M6
BSD-2608040014.A246
2608040014
|
-
|
|
|
|
753/60 - WING SCREW M6x20 MM
BSD-1613480008.A170
1613480008
|
£1.84
|
£2.21
|
|
|
754 - DEPTH-GAUGE
BSD-2603001019.A162
2603001019
|
£2.63
|
£3.16
|
|
|
756 - DRILL HOLDER
BSD-2607000122.A182
2607000122
|
-
|
|
|
|
780/1 - KEYLESS CHUCK
BSD-2608572123.A6
2608572123
|
£51.22
|
£61.47
|
|
|
780/30/1 - COUNTERSUNK-HEAD SCREW M 6x34 MM
BSD-2603421213.A49
2603421213
|
£2.74
|
£3.29
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A1496
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A653
2604321905
|
£11.87
|
£14.24
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A64
2600905039
|
£12.64
|
£15.17
|
|
|
825 - GEAR HOUSING
BSD-2605806987.A16
2605806987
|
-
|
|
|
|
843 - INTERMEDIATE FLANGE
BSD-2605700936.A13
2605700936
|
£46.82
|
£56.18
|
|
|
859 - TOOTHED SHAFT Z= 10/22/29
BSD-2606100903.A3
2606100903
|
-
|
|
|
|
865 - STICKER
BSD-2601110076.A104
2601110076
|
-
|
|
|
|
867 - LOCKING WASHER DIN 6799-4-FSt
BSD-2916080007.A198
2916080007
|
£2.74
|
£3.29
|
|
|
870 - PARTS SET
BSD-2607010226.A90
2607010226
|
£2.33
|
£2.80
|
|
