2 - FIELD 240V
BSD-2604220411.A8
2604220411
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 220-230V
BSD-2604010648.A7
2604010648
|
-
|
|
|
|
3/60 - FAN
BSD-1606610116.A163
1606610116
|
£2.52
|
£3.02
|
|
|
4 - SWITCH
BSD-2607200367.A50
2607200367
|
£7.78
|
£9.33
|
|
|
5 - POWER SUPPLY CORD IT 2.75m 2x1.0mm H05VV-F
BSD-1604460145.A8
1604460145
|
-
|
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A205
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2798
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601118263.A3
2601118263
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A64
1607328028
|
£5.30
|
£6.36
|
|
|
13 - NEEDLE BEARING
BSD-2600910005.A20
2600910005
|
-
|
|
|
|
16 - BRUSH HOLDER
BSD-2604449026.A22
2604449026
|
£1.75
|
£2.10
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2079
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A2635
2603490022
|
£1.75
|
£2.10
|
|
|
25 - TOOTHED BELT
BSD-2604736001.A15
2604736001
|
£10.10
|
£12.12
|
|
|
26 - RATCHET CAP
BSD-2600590006.A535
2600590006
|
£1.75
|
£2.10
|
|
|
27 - SCREW AND WASHER ASSEMBLY
BSD-2603433000.A16
2603433000
|
£1.75
|
£2.10
|
|
|
28 - HANDLE
BSD-2602026053.A3
2602026053
|
£2.61
|
£3.13
|
|
|
29 - AIR-DEFLECTOR RING
BSD-2600290004.A4
2600290004
|
£2.16
|
£2.59
|
|
|
30 - COVERING HOOD
BSD-2605500163.A14
2605500163
|
£11.30
|
£13.56
|
|
|
32 - SHIM 0.2 MM
BSD-2600100621.A34
2600100621
|
£1.75
|
£2.10
|
|
|
33 - ADJUSTING SLIDE
BSD-2608000133.A8
2608000133
|
£8.67
|
£10.41
|
|
|
34 - BASE PLATE
BSD-1608000091.A19
1608000091
|
£4.75
|
£5.70
|
|
|
35 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A90
1610910057
|
£2.80
|
£3.36
|
|
|
36 - HEX SCREW DIN 933-M5x70-8.8
BSD-2911061180.A6
2911061180
|
-
|
|
|
|
37 - HANDLE
BSD-2602026052.A7
2602026052
|
-
|
|
|
|
39 - ROUND NUT M6
BSD-2603342006.A16
2603342006
|
£1.75
|
£2.10
|
|
|
40 - NUT M 8
BSD-2603342010.A10
2603342010
|
£2.61
|
£3.13
|
|
|
41 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A166
2915011007
|
-
|
|
|
|
42 - TOOTHED BELT WHEEL Z= 18
BSD-2606625001.A13
2606625001
|
£3.80
|
£4.56
|
|
|
43 - TOOTHED BELT WHEEL Z=28
BSD-2606625002.A4
2606625002
|
£6.52
|
£7.83
|
|
|
44 - CONNECTING CABLE L = 288 MM
BSD-2604448062.A58
2604448062
|
£1.32
|
£1.58
|
|
|
44/1 - CABLE L = 238 MM
BSD-2604448160.A35
2604448160
|
£2.52
|
£3.02
|
|
|
45 - HEX NUT DIN 985-M 5-8-A
BSD-2915061003.A5
2915061003
|
£2.16
|
£2.59
|
|
|
46 - PLAIN WASHER DIN 125-A5.3-A2
BSD-2918650007.A11
2918650007
|
£1.75
|
£2.10
|
|
|
47 - COMPRESSION SPRING
BSD-2604611010.A15
2604611010
|
£2.16
|
£2.59
|
|
|
51 - PRESSURE PLATE
BSD-2602316000.A24
2602316000
|
-
|
|
|
|
52 - CLAMPING JAW
BSD-2605510007.A11
2605510007
|
-
|
|
|
|
56 - HEX SOCKET HEAD CAP SCREW
BSD-2603414027.A15
2603414027
|
-
|
|
|
|
738 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A405
2607950004
|
£1.75
|
£2.10
|
|
|
755 - PLANING KNIFE
BSD-2607000096.A1
2607000096
|
£7.57
|
£9.08
|
|
|
801 - HOUSING SECTION
BSD-2605104866.A1
2605104866
|
£37.27
|
£44.72
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A194
2604321905
|
£11.30
|
£13.56
|
|
|
814 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A306
2600905052
|
£7.36
|
£8.83
|
|
|
850 - PLANER HEAD
BSD-2608584002.A7
2608584002
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3498
160111A3H3
|
£2.61
|
£3.13
|
|
