2 - FIELD 220-230V
BSD-2604220429.A13
2604220429
|
£23.86
|
£28.63
|
|
|
6 - GROMMET dia8.8 MM
BSD-2600707061.A6
2600707061
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia6.9 MM
BSD-2600707059.A49
2600707059
|
£3.72
|
£4.47
|
|
|
7 - CABLE CLIP
BSD-1611035005.A232
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110418.A0
1611110418
|
-
|
|
|
|
10 - REFERENCE PLATE
BSD-1611110417.A30
1611110417
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-1617328021.A25
1617328021
|
-
|
|
|
|
15 - FAN
BSD-2606610049.A110
2606610049
|
£2.16
|
£2.59
|
|
|
17 - HOUSING COVER
BSD-1615132031.A12
1615132031
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A124
1610522008
|
£1.75
|
£2.10
|
|
|
20 - INTERMEDIATE FLANGE
BSD-1615700037.A160
1615700037
|
£40.80
|
£48.96
|
|
|
21 - RATCHET SLEEVE
BSD-1616490039.A5
1616490039
|
-
|
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A149
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320002.A150
1616320002
|
£24.45
|
£29.34
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A168
1613060010
|
£54.42
|
£65.30
|
|
|
25 - STRIKER PIN
BSD-1613124031.A0
1613124031
|
-
|
|
|
|
26 - HAMMER PISTON
BSD-1618700052.A164
1618700052
|
£13.12
|
£15.75
|
|
|
28 - STRIKER PIN
BSD-1613124026.A168
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A492
1613105012
|
£3.72
|
£4.47
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A168
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A168
1610100003
|
£1.75
|
£2.10
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A176
1612026023
|
£2.61
|
£3.13
|
|
|
34 - PROTECTIVE CAP
BSD-1610508015.A11
1610508015
|
-
|
|
|
|
35 - RUBBER RING
BSD-1610206021.A286
1610206021
|
£1.75
|
£2.10
|
|
|
37 - DAMPING BUSHING
BSD-1610390011.A160
1610390011
|
£3.72
|
£4.47
|
|
|
38 - SUPPORTING DISC
BSD-1610102022.A160
1610102022
|
£2.16
|
£2.59
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A4
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A172
1614690001
|
£1.75
|
£2.10
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A23
1610920003
|
£4.26
|
£5.11
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A172
1614633001
|
£2.52
|
£3.02
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A172
1614614001
|
£1.75
|
£2.10
|
|
|
48 - CONNECTING CABLE L=90 MM
BSD-1614431023.A48
1614431023
|
-
|
|
|
|
49 - CABLE L=130 MM
BSD-2604448005.A5
2604448005
|
£1.75
|
£2.10
|
|
|
50 - CABLE
BSD-2604448003.A87
2604448003
|
-
|
|
|
|
51 - STICKER
BSD-2601110230.A127
2601110230
|
-
|
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A330
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A23
1610206023
|
£2.80
|
£3.36
|
|
|
56 - O-RING 14.0x3.0 MM
BSD-1610210070.A138
1610210070
|
£2.61
|
£3.13
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A184
1610210058
|
£2.61
|
£3.13
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A24
1610210069
|
£1.75
|
£2.10
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A168
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A205
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A215
1610202026
|
£5.30
|
£6.36
|
|
|
63 - GROOVE BALL BEARING
BSD-1610905013.A12
1610905013
|
-
|
|
|
|
64 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A293
1610905025
|
£6.52
|
£7.83
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A21
1900900228
|
£6.61
|
£7.93
|
|
|
66 - BUSHING dia30xdia37x15.7 MM
BSD-1610301000.A113
1610301000
|
£3.34
|
£4.01
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A36
1610910064
|
£2.52
|
£3.02
|
|
|
68 - ROLLER-CAGE ASSEMBLY
BSD-1610920004.A53
1610920004
|
£3.80
|
£4.56
|
|
|
69 - SUPPORT DISC 1.0 MM
BSD-1610102618.A12
1610102618
|
-
|
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A367
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A169
2916540018
|
£3.72
|
£4.47
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A31
1614601009
|
£1.95
|
£2.34
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A195
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A166
2910211021
|
£1.75
|
£2.10
|
|
|
78 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A19
1603435050
|
£2.33
|
£2.80
|
|
|
79 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A288
2910211005
|
£1.75
|
£2.10
|
|
|
79 - TAPPING SCREW DIN 7971-B 2.9x13
BSD-2910211206.A94
2910211206
|
£1.32
|
£1.58
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A212
2603435015
|
£2.16
|
£2.59
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2240
2603410001
|
£1.75
|
£2.10
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A0
1903230309
|
£1.75
|
£2.10
|
|
|
90 - SWITCH
BSD-1617200042.A58
1617200042
|
£16.41
|
£19.69
|
|
|
91 - CYLINDRICAL ROLLER
BSD-1613100014.A5
1613100014
|
£1.95
|
£2.34
|
|
|
92 - CHUCK
BSD-1607031148.A0
1607031148
|
-
|
|
|
|
92/8 - CHUCK WRENCH SG2
BSD-2607950007.A855
2607950007
|
£6.52
|
£7.83
|
|
|
94 - DETENT PIN
BSD-1613120017.A149
1613120017
|
£1.75
|
£2.10
|
|
|
102 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A85
2604465097
|
£5.58
|
£6.70
|
|
|
103 - CONNECTING CABLE L=55 MM
BSD-1614448017.A0
1614448017
|
£2.16
|
£2.59
|
|
|
120 - AUXILIARY HANDLE dia43 MM
BSD-1619P10682.A98
1619P10682
|
£12.49
|
£14.99
|
|
|
120/20 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A291
2915011007
|
-
|
|
|
|
120/30 - WING SCREW M6x(15)55
BSD-1613480007.A65
1613480007
|
£1.75
|
£2.10
|
|
|
125 - STICKER
BSD-1601110265.A293
1601110265
|
-
|
|
|
|
127 - STICKER
BSD-1611110296.A5
1611110296
|
-
|
|
|
|
651 - DEPTH-GAUGE
BSD-2603001003.A2
2603001003
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-1615108040.A17
1615108040
|
-
|
|
|
|
803 - ARMATURE WITH FAN 220-230V
BSD-1614010039.A40
1614010039
|
-
|
|
|
|
804 - SWITCH KIT
BSD-1617000915.A9
1617000915
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A602
1607000386
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A3564
160111A3H3
|
£2.61
|
£3.13
|
|
|
811 - CARBON BRUSH
BSD-1617014114.A73
1617014114
|
£10.10
|
£12.12
|
|
|
814 - PARTS SET
BSD-1617000136.A11
1617000136
|
£18.96
|
£22.75
|
|
|
816 - GEAR HOUSING
BSD-1615806077.A7
1615806077
|
£45.67
|
£54.80
|
|
|
827 - STRIKER
BSD-1617000338.A160
1617000338
|
£27.23
|
£32.68
|
|
|
843 - BRUSH PLATE
BSD-2601015047.A36
2601015047
|
-
|
|
|
|
857 - O-RING 34.0x2.0 MM
BSD-1610210084.A40
1610210084
|
£1.75
|
£2.10
|
|
|
866 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A136
1610910063
|
£5.58
|
£6.70
|
|
|
890 - MODIFICATION SET 110-240V
BSD-1617000134.A30
1617000134
|
£80.61
|
£96.73
|
|
