1 - KNOB BLADE PROTECTION
BDE-861842-01.A33
861842-01
|
£1.50
|
£1.80
|
|
|
1 - HEX KEY 8 MM MOTOR
BDE-860098-05.A58
860098-05
|
£3.30
|
£3.96
|
|
|
2 - NUT MOTOR
BDE-860126-01.A22
860126-01
|
-
|
|
|
|
2 - WASHER BLADE PROTECTION
BDE-860074-01.A102
860074-01
|
£1.50
|
£1.80
|
|
|
3 - SQUARE BLADE PROTECTION
BDE-863708-00.A45
863708-00
|
£10.85
|
£13.02
|
|
|
3 - BUSHING MOTOR
BDE-860447-00.A31
860447-00
|
£7.85
|
£9.42
|
|
|
4 - WASHER M8 MOTOR
BDE-860073-03.A365
860073-03
|
£1.50
|
£1.80
|
|
|
4 - TUBE EXTRACTION BLADE PROTECTION
BDE-864095-00.A63
864095-00
|
£7.85
|
£9.42
|
|
|
5 - NUT WING MOTOR
BDE-860143-00.A32
860143-00
|
-
|
|
|
|
5 - PROTECTOR BLADE PROTECTION
BDE-863706-01.A16
863706-01
|
£10.85
|
£13.02
|
|
|
6 - TIE ROD MOTOR
BDE-863015-00.A19
863015-00
|
£1.50
|
£1.80
|
|
|
7 - SCREW MOTOR
BDE-860085-19.A84
860085-19
|
£1.50
|
£1.80
|
|
|
7 - WASHER BLADE PROTECTION
BDE-860075-00.A123
860075-00
|
£1.50
|
£1.80
|
|
|
8 - GUARD BLADE PROTECTION
BDE-862235-04.A5
862235-04
|
-
|
|
|
|
8 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14613
000000-00
|
-
|
|
|
|
9 - BRACKET BLADE PROTECTION
BDE-863707-01.A26
863707-01
|
£9.41
|
£11.29
|
|
|
9 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14614
000000-00
|
-
|
|
|
|
10 - NO LONGER AVAILABLE BLADE PROTECTION
BDE-000000-00.A14615
000000-00
|
-
|
|
|
|
10 - BEARING MOTOR
BDE-868768-07.A78
868768-07
|
£7.85
|
£9.42
|
|
|
11 - SCREW BLADE PROTECTION
BDE-760273-00.A27
760273-00
|
£1.50
|
£1.80
|
|
|
12 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14616
000000-00
|
-
|
|
|
|
12 - KNOB BLADE PROTECTION
BDE-946469-00.A52
946469-00
|
£1.50
|
£1.80
|
|
|
13 - SCREW BLADE PROTECTION
BDE-760998-00.A118
760998-00
|
£1.50
|
£1.80
|
|
|
13 - END CAP MOTOR
BDE-860443-00.A31
860443-00
|
£4.69
|
£5.63
|
|
|
14 - FAN MOTOR
BDE-860444-00.A37
860444-00
|
£4.69
|
£5.63
|
|
|
14 - WASHER BLADE PROTECTION
BDE-864053-00.A68
864053-00
|
£3.80
|
£4.56
|
|
|
15 - COVER MOTOR
BDE-860445-00.A42
860445-00
|
£7.18
|
£8.62
|
|
|
15 - LEVER
BDE-862084-01.A10
862084-01
|
-
|
|
|
|
16 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14617
000000-00
|
-
|
|
|
|
16 - BRACKET BLADE PROTECTION
BDE-863775-01.A14
863775-01
|
-
|
|
|
|
17 - NO LONGER AVAILABLE BLADE PROTECTION
BDE-000000-00.A14618
000000-00
|
-
|
|
|
|
18 - BUSH BLADE PROTECTION
BDE-863705-00.A27
863705-00
|
£1.82
|
£2.19
|
|
|
18 - SCREW MOTOR
BDE-860084-10.A1
860084-10
|
-
|
|
|
|
19 - GUARD BLADE PROTECTION
BDE-862417-00.A14
862417-00
|
£10.85
|
£13.02
|
|
|
19 - NUT MOTOR
BDE-944590-00.A97
944590-00
|
£1.50
|
£1.80
|
|
|
20 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14619
000000-00
|
-
|
|
|
|
20 - SCREW BLADE PROTECTION
BDE-249412-20.A82
249412-20
|
£1.50
|
£1.80
|
|
|
21 - ROLLER BLADE PROTECTION
BDE-864054-00.A6
864054-00
|
£1.82
|
£2.19
|
|
|
22 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14620
000000-00
|
-
|
|
|
|
22 - SCREW BLADE PROTECTION
BDE-860301-00.A84
860301-00
|
£1.50
|
£1.80
|
|
|
23 - BRACKET BLADE PROTECTION
BDE-862083-00.A18
862083-00
|
-
|
|
|
|
23 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14621
000000-00
|
-
|
|
|
|
24 - SCREW MOTOR
BDE-930076-00.A79
930076-00
|
£1.50
|
£1.80
|
|
|
24 - NO LONGER AVAILABLE BLADE PROTECTION
BDE-000000-00.A14622
000000-00
|
-
|
|
|
|
25 - CAP MOTOR
BDE-863849-00.A11
863849-00
|
-
|
|
|
|
25 - SHIM BLADE PROTECTION
BDE-864086-00.A8
864086-00
|
£3.70
|
£4.44
|
|
|
26 - WASHER BLADE PROTECTION
BDE-860074-02.A109
860074-02
|
£1.50
|
£1.80
|
|
|
26 - PLATE MOTOR
BDE-863198-00.A7
863198-00
|
-
|
|
|
|
27 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14623
000000-00
|
-
|
|
|
|
27 - NUT BLADE PROTECTION
BDE-860083-03.A325
860083-03
|
£1.50
|
£1.80
|
|
|
28 - SUPPORT BLADE PROTECTION
BDE-863709-00.A22
863709-00
|
-
|
|
|
|
28 - CAPACITOR MOTOR
BDE-949772-23.A8
949772-23
|
£14.57
|
£17.48
|
|
|
30 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14624
000000-00
|
-
|
|
|
|
30 - BRACKET BLADE PROTECTION
BDE-945632-90.A7
945632-90
|
-
|
|
|
|
31 - NO LONGER AVAILABLE BLADE PROTECTION
BDE-000000-00.A14626
000000-00
|
-
|
|
|
|
32 - PROTECTOR BLADE PROTECTION
BDE-863703-00.A42
863703-00
|
-
|
|
|
|
33 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14625
000000-00
|
-
|
|
|
|
33 - SCREW BLADE PROTECTION
BDE-760219-00.A12
760219-00
|
£1.50
|
£1.80
|
|
|
34 - RING MOTOR
BDE-860806-00.A20
860806-00
|
£1.50
|
£1.80
|
|
|
35 - HOUSING MOTOR
BDE-860808-00.A21
860808-00
|
-
|
|
|
|
36 - INNER FLANGE MOTOR
BDE-863266-00.A2
863266-00
|
-
|
|
|
|
39 - OUTER FLANGE MOTOR
BDE-861241-00.A28
861241-00
|
-
|
|
|
|
40 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14627
000000-00
|
-
|
|
|
|
41 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14628
000000-00
|
-
|
|
|
|
42 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14629
000000-00
|
-
|
|
|
|
43 - NO LONGER AVAILABLE MOTOR
BDE-000000-00.A14630
000000-00
|
-
|
|
|
|
44 - KEY PARTS NOT DRAWN
BDE-860318-01.A35
860318-01
|
£1.50
|
£1.80
|
|
