5 - COMPRESSION SPRING
BSD-2604611037.A19
2604611037
|
-
|
|
|
|
6 - PRESSURE SPINDLE
BSD-2603126006.A14
2603126006
|
-
|
|
|
|
7 - NEEDLE BEARING
BSD-2600914013.A24
2600914013
|
£5.58
|
£6.70
|
|
|
8 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A785
2600910001
|
£4.26
|
£5.11
|
|
|
9 - GROOVED NAIL
BSD-3603133000.A366
3603133000
|
£2.61
|
£3.13
|
|
|
10 - DEPTH-GAUGE
BSD-2600460007.A9
2600460007
|
-
|
|
|
|
10 - DEPTH-GAUGE
BSD-2600460008.A22
2600460008
|
£16.96
|
£20.35
|
|
|
10 - DEPTH-GAUGE
BSD-2600460009.A3
2600460009
|
-
|
|
|
|
11 - STOP SPRING
BSD-2604601012.A46
2604601012
|
£2.52
|
£3.02
|
|
|
12 - BUSHING
BSD-2600499002.A10
2600499002
|
-
|
|
|
|
14 - SEAL RING
BSD-2600283012.A20
2600283012
|
£2.80
|
£3.36
|
|
|
16 - MANUFACTURER'S NAMEPLATE
BSD-2601110099.A23
2601110099
|
-
|
|
|
|
17 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A709
2600914010
|
£2.80
|
£3.36
|
|
|
19 - SHIM 0.3 MM
BSD-2600100607.A717
2600100607
|
£1.75
|
£2.10
|
|
|
20 - BALL BEARING 8x22x7
BSD-1900905029.A266
1900905029
|
£21.52
|
£25.83
|
|
|
21 - SEAL BUSHING
BSD-2600300049.A61
2600300049
|
-
|
|
|
|
22 - FELT DISC
BSD-2600108000.A192
2600108000
|
-
|
|
|
|
23 - CUPPED WASHER
BSD-2600500030.A87
2600500030
|
-
|
|
|
|
24 - SPRING RETAINING RING
BSD-2600119000.A60
2600119000
|
£1.75
|
£2.10
|
|
|
25 - REFERENCE PLATE
BSD-2601110170.A0
2601110170
|
-
|
|
|
|
26 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A766
2603490023
|
£1.75
|
£2.10
|
|
|
27 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A84
2916690003
|
£1.75
|
£2.10
|
|
|
28 - SCREW AND WASHER ASSEMBLY DIN 84-BM 4x35-Z4-8.8
BSD-2914501027.A46
2914501027
|
-
|
|
|
|
29 - COVER DISC
BSD-2601328041.A13
2601328041
|
-
|
|
|
|
32 - CHANGE-OVER SWITCH
BSD-2607200114.A37
2607200114
|
-
|
|
|
|
33 - ARMATURE 220V
BSD-2604010533.A7
2604010533
|
-
|
|
|
|
34 - FIELD 220V
BSD-2604222302.A10
2604222302
|
-
|
|
|
|
36 - HOUSING COVER
BSD-2605132017.A50
2605132017
|
-
|
|
|
|
37 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A722
2912401020
|
£2.16
|
£2.59
|
|
|
38 - BALL BEARING 7x22x7
BSD-1900905018.A911
1900905018
|
£18.96
|
£22.75
|
|
|
40 - ON-OFF SWITCH
BSD-2607200065.A39
2607200065
|
-
|
|
|
|
41 - SOCKET HEAD CAP SCREW M3x10 MM
BSD-2603410023.A422
2603410023
|
-
|
|
|
|
43 - SCREW 4x16
BSD-2603490022.A1525
2603490022
|
£1.75
|
£2.10
|
|
|
44 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1228
2600703012
|
£2.80
|
£3.36
|
|
|
45 - POWER SUPPLY CORD I / BR 4.15m 2 x 1.0mm H05VV-F
BSD-2604460278.A12
2604460278
|
£7.36
|
£8.83
|
|
|
46 - CABLE CLIP
BSD-2601035001.A396
2601035001
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW 2.2x6.5
BSD-2603435016.A62
2603435016
|
-
|
|
|
|
48 - SCREW AND WASHER ASSEMBLY DIN7985-M3x6-Z1-4.8
BSD-2914501011.A191
2914501011
|
£1.75
|
£2.10
|
|
|
49 - SPIRAL SPRING
BSD-2604652003.A14
2604652003
|
-
|
|
|
|
52 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A38
1608521004
|
-
|
|
|
|
53 - RETAINING RING
BSD-2604601004.A544
2604601004
|
£1.75
|
£2.10
|
|
|
57 - NEEDLE ROLLER DIN 5402-A3x11.8-G2
BSD-1903201042.A378
1903201042
|
£2.16
|
£2.59
|
|
|
58 - COMPRESSION SPRING
BSD-2604611026.A228
2604611026
|
-
|
|
|
|
61 - SHIM
BSD-2600150004.A177
2600150004
|
£2.16
|
£2.59
|
|
|
62 - SHIM 0.3 MM
BSD-2600101023.A147
2600101023
|
£1.75
|
£2.10
|
|
|
62 - SHIM 0.2 MM
BSD-2600101022.A472
2600101022
|
£1.75
|
£2.10
|
|
|
62 - SHIM 0.5 MM
BSD-2600101020.A177
2600101020
|
£1.75
|
£2.10
|
|
|
63 - CABLE
BSD-2604411524.A27
2604411524
|
-
|
|
|
|
65 - STICKER
BSD-2601110230.A103
2601110230
|
-
|
|
|
|
67 - CENTERING SLEEVE
BSD-2600409013.A60
2600409013
|
-
|
|
|
|
68 - FAN
BSD-2606610021.A15
2606610021
|
-
|
|
|
|
69 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A342
1900452012
|
£1.75
|
£2.10
|
|
|
800 - MOTOR HOUSING
BSD-2605104954.A47
2605104954
|
-
|
|
|
|
800 - MOTOR HOUSING
BSD-2605104954.A48
2605104954
|
-
|
|
|
|
801 - GEAR HOUSING
BSD-2605806957.A13
2605806957
|
-
|
|
|
|
802 - BEARING FLANGE
BSD-2605700925.A19
2605700925
|
-
|
|
|
|
803 - TOOTHED SHAFT Z=21/41
BSD-2606311900.A7
2606311900
|
-
|
|
|
|
804 - COUPLING HALF
BSD-2606490903.A7
2606490903
|
-
|
|
|
|
806 - COUPLING HALF
BSD-2606490907.A11
2606490907
|
-
|
|
|
|
806 - COUPLING HALF
BSD-2606490905.A12
2606490905
|
-
|
|
|
|
807 - CARBON-BRUSH SET
BSD-2604320902.A176
2604320902
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A783
160111A3H3
|
£2.61
|
£3.13
|
|
