1 - ARMATURE AE-VE 115V
BDE-868404-01.A0
868404-01
|
-
|
|
|
|
1 - ARMATURE GB 115
BDE-868404-01.A1
868404-01
|
-
|
|
|
|
1 - ARMATURE GB 240V
BDE-868404-00.A6
868404-00
|
£238.94
|
£286.73
|
|
|
2 - NO LONGER AVAILABLE AE-VE 115V
BDE-000000-00.A39803
000000-00
|
-
|
|
|
|
2 - NO LONGER AVAILABLE GB 115
BDE-000000-00.A39804
000000-00
|
-
|
|
|
|
2 - FIELD 240V GB 240V
BDE-868503-04.A6
868503-04
|
£226.53
|
£271.84
|
|
|
2 - NO LONGER AVAILABLE IT 48VOLT
BDE-000000-00.A39801
000000-00
|
-
|
|
|
|
3 - SWITCH GB 115
BDE-932401-00.A9
932401-00
|
£36.42
|
£43.70
|
|
|
3 - SWITCH GB 240V
BDE-932401-00.A10
932401-00
|
£36.42
|
£43.70
|
|
|
3 - SWITCH AE-VE 115V
BDE-932401-00.A11
932401-00
|
£36.42
|
£43.70
|
|
|
3 - NO LONGER AVAILABLE IT 48VOLT
BDE-000000-00.A39802
000000-00
|
-
|
|
|
|
4 - BRUSH GB 115
BDE-932497-00.A7
932497-00
|
£4.69
|
£5.63
|
|
|
4 - BRUSH AE-VE 115V
BDE-932497-00.A8
932497-00
|
£4.69
|
£5.63
|
|
|
4 - BRUSH GB 240V
BDE-932497-00.A9
932497-00
|
£4.69
|
£5.63
|
|
|
5 - CABLE & PLUG GB 240V
BDE-949770-15.A1
949770-15
|
£33.13
|
£39.76
|
|
|
5 - CABLE & PLUG GB 115
BDE-949770-29.A6
949770-29
|
-
|
|
|
|
5 - NO LONGER AVAILABLE AE-VE 115V
BDE-000000-00.A39805
000000-00
|
-
|
|
|
|
6 - HOLDER
BDE-932300-00.A0
932300-00
|
£101.69
|
£122.03
|
|
|
7 - GEARCASE SA
BDE-932418-00.A3
932418-00
|
£238.94
|
£286.73
|
|
|
8 - NO LONGER AVAILABLE
BDE-000000-00.A39806
000000-00
|
-
|
|
|
|
9 - SCREW
BDE-860084-09.A26
860084-09
|
£1.50
|
£1.80
|
|
|
10 - NO LONGER AVAILABLE
BDE-000000-00.A39807
000000-00
|
-
|
|
|
|
11 - LEVER
BDE-932315-00.A2
932315-00
|
£3.22
|
£3.86
|
|
|
12 - SPRING
BDE-932313-00.A2
932313-00
|
£5.72
|
£6.87
|
|
|
13 - COVER
BDE-932317-00.A6
932317-00
|
£3.70
|
£4.44
|
|
|
14 - PIN
BDE-932314-00.A6
932314-00
|
£1.42
|
£1.70
|
|
|
15 - SPRING
BDE-931013-00.A10
931013-00
|
£1.42
|
£1.70
|
|
|
16 - SCREW
BDE-860093-11.A3
860093-11
|
£1.50
|
£1.80
|
|
|
18 - SPACER
BDE-930614.A5
930614
|
£1.42
|
£1.70
|
|
|
19 - BEARING
BDE-930025-00.A9
930025-00
|
£9.17
|
£11.00
|
|
|
20 - GEAR
BDE-932428-00.A0
932428-00
|
£29.32
|
£35.18
|
|
|
21 - WASHER
BDE-932297-00.A0
932297-00
|
£1.42
|
£1.70
|
|
|
22 - RING
BDE-932299-00.A3
932299-00
|
£7.01
|
£8.41
|
|
|
23 - WASHER
BDE-932287-00.A3
932287-00
|
£1.42
|
£1.70
|
|
|
24 - SPINDLE & GEAR SA
BDE-869219-00.A1
869219-00
|
£135.36
|
£162.43
|
|
|
25 - WASHER
BDE-932286-00.A6
932286-00
|
£2.71
|
£3.25
|
|
|
26 - SPINDLE & GEAR SA
BDE-869219-02.A8
869219-02
|
£101.69
|
£122.03
|
|
|
27 - WASHER
BDE-932285-00.A3
932285-00
|
£3.30
|
£3.96
|
|
|
28 - PLATE
BDE-932288-00.A6
932288-00
|
£1.50
|
£1.80
|
|
|
29 - SEAL
BDE-930039.A21
930039
|
£1.42
|
£1.70
|
|
|
30 - WASHER
BDE-932289-00.A3
932289-00
|
£1.42
|
£1.70
|
|
|
31 - LEVER SA
BDE-932265-00.A8
932265-00
|
£29.32
|
£35.18
|
|
|
32 - SPRING
BDE-932290-00.A8
932290-00
|
£1.78
|
£2.13
|
|
|
33 - SPRING
BDE-932291-00.A3
932291-00
|
£4.58
|
£5.49
|
|
|
34 - SCREW
BDE-932408-00.A1
932408-00
|
£1.42
|
£1.70
|
|
|
35 - WASHER
BDE-931429-00.A8
931429-00
|
£3.30
|
£3.96
|
|
|
36 - EJECTOR
BDE-932304-00.A4
932304-00
|
-
|
|
|
|
37 - NO LONGER AVAILABLE
BDE-000000-00.A39808
000000-00
|
-
|
|
|
|
38 - CAP
BDE-932308-01.A3
932308-01
|
-
|
|
|
|
39 - GASKET
BDE-932312-00.A7
932312-00
|
£1.42
|
£1.70
|
|
|
40 - PIN
BDE-932301-00.A4
932301-00
|
-
|
|
|
|
41 - GEARCASE COVER SA
BDE-943963-00.A1
943963-00
|
£59.41
|
£71.29
|
|
|
42 - SEAL
BDE-932311-00.A2
932311-00
|
£2.21
|
£2.65
|
|
|
43 - RING
BDE-931052-00.A12
931052-00
|
£1.42
|
£1.70
|
|
|
44 - RING
BDE-930940-00.A4
930940-00
|
£3.22
|
£3.86
|
|
|
45 - BEARING
BDE-330003-11.A18
330003-11
|
£10.85
|
£13.02
|
|
|
46 - CIRCLIP
BDE-949729-02.A2
949729-02
|
£1.50
|
£1.80
|
|
|
47 - WASHER
BDE-932309-00.A9
932309-00
|
£1.50
|
£1.80
|
|
|
48 - SPACER
BDE-930073-00.A7
930073-00
|
£1.42
|
£1.70
|
|
|
49 - BEARING
BDE-577745-00.A130
577745-00
|
£7.85
|
£9.42
|
|
|
50 - SLEEVE
BDE-934409-00.A4
934409-00
|
-
|
|
|
|
51 - BAFFLE
BDE-930072-00.A8
930072-00
|
£2.21
|
£2.65
|
|
|
52 - SCREW
BDE-930246-00.A3
930246-00
|
£1.42
|
£1.70
|
|
|
53 - WASHER
BDE-761035-00.A23
761035-00
|
£1.42
|
£1.70
|
|
|
54 - WASHER
BDE-949876-08.A12
949876-08
|
£1.50
|
£1.80
|
|
|
55 - FIELDCASE
BDE-932261-01.A1
932261-01
|
-
|
|
|
|
57 - SCREW
BDE-930251-00.A6
930251-00
|
£1.42
|
£1.70
|
|
|
58 - NO LONGER AVAILABLE
BDE-000000-00.A39809
000000-00
|
-
|
|
|
|
59 - SCREW
BDE-930242-00.A1
930242-00
|
£1.42
|
£1.70
|
|
|
60 - BASEPLATE SA
BDE-930269-00.A3
930269-00
|
£3.22
|
£3.86
|
|
|
61 - SPRING
BDE-930099-00.A13
930099-00
|
-
|
|
|
|
62 - BLOCK
BDE-932307-00.A10
932307-00
|
£1.42
|
£1.70
|
|
|
63 - PLATE
BDE-932320-00.A5
932320-00
|
£7.64
|
£9.17
|
|
|
64 - SCREW
BDE-932319-00.A3
932319-00
|
£1.42
|
£1.70
|
|
|
65 - CAPACITOR GB 240V
BDE-932476-00.A7
932476-00
|
£3.22
|
£3.86
|
|
|
65 - NO LONGER AVAILABLE IT 48VOLT
BDE-000000-00.A39810
000000-00
|
-
|
|
|
|
65 - CAPACITOR GB 115
BDE-932476-00.A6
932476-00
|
£3.22
|
£3.86
|
|
|
66 - PIN
BDE-932406-00.A6
932406-00
|
£1.42
|
£1.70
|
|
|
67 - RING
BDE-932268-00.A1
932268-00
|
£3.22
|
£3.86
|
|
|
68 - ROLLER
BDE-932405-00.A2
932405-00
|
£1.42
|
£1.70
|
|
|
69 - SCREW
BDE-860084-09.A25
860084-09
|
£1.50
|
£1.80
|
|
|
70 - SWITCH REVERSE
BDE-932403-00.A7
932403-00
|
£23.75
|
£28.50
|
|
|
71 - NO LONGER AVAILABLE
BDE-000000-00.A39811
000000-00
|
-
|
|
|
|
72 - NO LONGER AVAILABLE
BDE-000000-00.A39812
000000-00
|
-
|
|
|
|
78 - SCREW GB 240V
BDE-930076-00.A56
930076-00
|
£1.50
|
£1.80
|
|
|
78 - SCREW GB 115
BDE-930076-00.A57
930076-00
|
£1.50
|
£1.80
|
|
|
79 - CORD CLAMP GB 240V
BDE-930103-00.A147
930103-00
|
£1.50
|
£1.80
|
|
|
79 - CORD CLAMP IT 48VOLT
BDE-930103-00.A148
930103-00
|
£1.50
|
£1.80
|
|
|
79 - CORD CLAMP GB 115
BDE-930103-00.A149
930103-00
|
£1.50
|
£1.80
|
|
|
80 - CORD PROTECTOR GB 240V
BDE-931113-00.A15
931113-00
|
£1.42
|
£1.70
|
|
|
80 - CORD PROTECTOR GB 115
BDE-931113-00.A16
931113-00
|
£1.42
|
£1.70
|
|
|
80 - CORD PROTECTOR IT 48VOLT
BDE-930981-00.A25
930981-00
|
£1.42
|
£1.70
|
|
