3 - FIELD 240V
BSD-2604220398.A6
2604220398
|
-
|
|
|
|
4 - ARMATURE 220V
BSD-2604010529.A20
2604010529
|
-
|
|
|
|
5 - SWITCH
BSD-2607200084.A55
2607200084
|
£10.10
|
£12.12
|
|
|
5 - SWITCH
BSD-2607200260.A414
2607200260
|
£11.30
|
£13.56
|
|
|
7 - GROMMET dia11.6-dia12.5x84 MM
BSD-2600707060.A168
2600707060
|
£2.61
|
£3.13
|
|
|
7 - GROMMET dia6.9 MM
BSD-2600707059.A266
2600707059
|
£3.72
|
£4.47
|
|
|
7 - GROMMET dia8.8 MM
BSD-2600707061.A131
2600707061
|
£2.80
|
£3.36
|
|
|
8 - CABLE CLIP
BSD-2601035001.A1639
2601035001
|
£1.75
|
£2.10
|
|
|
11 - STICKER
BSD-2601110079.A23
2601110079
|
-
|
|
|
|
13 - SUPPRESSION CAPACITOR
BSD-2607329095.A17
2607329095
|
-
|
|
|
|
14 - SUPPRESSOR BOX
BSD-2604465099.A51
2604465099
|
-
|
|
|
|
14 - BRUSH HOLDER
BSD-1604449002.A46
1604449002
|
£1.75
|
£2.10
|
|
|
18 - CHUCK dia 1-10 MM. 3/8
BSD-1608571033.A18
1608571033
|
-
|
|
|
|
18 - CHUCK WRENCH SG2
BSD-2607950007.A49
2607950007
|
£6.52
|
£7.83
|
|
|
23 - STICKER
BSD-2601110080.A1
2601110080
|
-
|
|
|
|
25 - O-RING 54.0x3.0 MM
BSD-1600210004.A166
1600210004
|
£2.80
|
£3.36
|
|
|
27 - FELT WASHER
BSD-2600205002.A23
2600205002
|
-
|
|
|
|
31 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A133
2916650001
|
£2.61
|
£3.13
|
|
|
32 - GROOVE BALL BEARING 6200-2Z DIN 625
BSD-1900905232.A90
1900905232
|
£21.68
|
£26.01
|
|
|
33 - TORX OVAL-HEAD SCREW 3x18
BSD-2603490018.A593
2603490018
|
£1.75
|
£2.10
|
|
|
37 - NEEDLE-ROLLER BEARING dia8x8 MM
BSD-2600917003.A247
2600917003
|
£2.80
|
£3.36
|
|
|
38 - BALL DIN 5401-5 G28
BSD-1903230009.A803
1903230009
|
£1.75
|
£2.10
|
|
|
43 - CARB BRUSH HOLD W-SUPR
BSD-2604465081.A57
2604465081
|
-
|
|
|
|
45 - SINTERED-METAL BUSHING
BSD-1900301004.A65
1900301004
|
£13.41
|
£16.09
|
|
|
46 - INTERMEDIATE PLATE 0.3 MM
BSD-2601000018.A14
2601000018
|
-
|
|
|
|
47 - PRESSURE PLATE 1.5 MM
BSD-1601000013.A85
1601000013
|
-
|
|
|
|
48 - LUBRICATING FELT
BSD-2601020005.A65
2601020005
|
-
|
|
|
|
51 - O-RING 8.0x2.5 MM
BSD-1610210014.A264
1610210014
|
-
|
|
|
|
54 - DAMPING PLATE
BSD-2601022000.A184
2601022000
|
£1.75
|
£2.10
|
|
|
64 - SCREW 4x16
BSD-2603490022.A2064
2603490022
|
£1.75
|
£2.10
|
|
|
66 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A84
2603490025
|
£1.75
|
£2.10
|
|
|
68 - CONNECTING CABLE L=154 MM
BSD-2604448000.A187
2604448000
|
-
|
|
|
|
69 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1929
2603410001
|
£1.75
|
£2.10
|
|
|
70 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A701
2910211019
|
£1.75
|
£2.10
|
|
|
71 - CABLE
BSD-2604448003.A12
2604448003
|
-
|
|
|
|
75 - FAN
BSD-2606610047.A93
2606610047
|
-
|
|
|
|
85 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A593
2915011007
|
-
|
|
|
|
86 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A248
1900452012
|
£1.75
|
£2.10
|
|
|
801 - HOUSING SECTION
BSD-2605104949.A40
2605104949
|
-
|
|
|
|
802 - DRILLING SPINDLE Z=46
BSD-2606135901.A29
2606135901
|
-
|
|
|
|
803 - BEARING BRACKET
BSD-2605807904.A29
2605807904
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321904.A187
2604321904
|
£10.10
|
£12.12
|
|
|
825 - RUBBER PLUG
BSD-2603239010.A14
2603239010
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A738
1607000227
|
£23.86
|
£28.63
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A5069
160111A3H3
|
£2.61
|
£3.13
|
|
