1 - MOTOR HOUSING
BSD-1609991106.A6
1609991106
|
-
|
|
|
|
2 - BRUSH HOLDER
BSD-1604336005.A26
1604336005
|
-
|
|
|
|
3 - SPIRAL SPRING
BSD-1604652001.A71
1604652001
|
-
|
|
|
|
4 - POLE SHOE 100-120V
BSD-1604220206.A27
1604220206
|
-
|
|
|
|
4/20 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A241
1901350003
|
£1.84
|
£2.21
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209002.A120
1600209002
|
£5.30
|
£6.36
|
|
|
7 - ARMATURE 110-115V
BSD-1609991110.A22
1609991110
|
-
|
|
|
|
11 - CARBON-BRUSH SET
BSD-1607014101.A78
1607014101
|
£11.87
|
£14.24
|
|
|
12 - SEALING CAP
BSD-3605500057.A197
3605500057
|
-
|
|
|
|
13 - HANDLE
BSD-3605133012.A167
3605133012
|
-
|
|
|
|
13/2 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A298
1602381001
|
-
|
|
|
|
13/3 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A749
2910211021
|
£1.75
|
£2.10
|
|
|
15 - SWITCH
BSD-1607200078.A2
1607200078
|
£42.84
|
£51.41
|
|
|
15 - SWITCH
BSD-1607200037.A85
1607200037
|
£47.95
|
£57.54
|
|
|
16 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A68
1607000227
|
£23.86
|
£28.63
|
|
|
17 - GROMMET dia7.9-dia12.0x120 MM
BSD-1600703022.A45
1600703022
|
£2.94
|
£3.53
|
|
|
18 - BEARING COVER
BSD-1600501019.A443
1600501019
|
£25.05
|
£30.06
|
|
|
19 - SUPPRESSION CAPACITOR
BSD-1607328012.A18
1607328012
|
-
|
|
|
|
19/20 - TERMINAL LUG
BSD-1601353003.A150
1601353003
|
-
|
|
|
|
20 - BALL BEARING 7x19x6
BSD-2600905032.A231
2600905032
|
£5.57
|
£6.68
|
|
|
22 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A179
1600900001
|
-
|
|
|
|
23 - INTERMEDIATE BEARING
BSD-3605820033.A15
3605820033
|
-
|
|
|
|
24 - NAMEPLATE
BSD-160111A3H3.A439
160111A3H3
|
£2.74
|
£3.29
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110004.A104
1601110004
|
-
|
|
|
|
26 - FELT DISC
BSD-1600108003.A23
1600108003
|
£1.38
|
£1.66
|
|
|
27 - O-RING 74.0x3.0 MM
BSD-1600210006.A1
1600210006
|
£1.84
|
£2.21
|
|
|
28 - FASTENING CLAMP
BSD-1601302014.A1021
1601302014
|
£2.74
|
£3.29
|
|
|
29 - RUBBER BUSHING
BSD-1600502020.A235
1600502020
|
£2.74
|
£3.29
|
|
|
30 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1728
2910211019
|
£1.84
|
£2.21
|
|
|
31 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A41
2910021154
|
£1.75
|
£2.10
|
|
|
33 - TAPPING SCREW B4.8x90 MM
BSD-1603435006.A48
1603435006
|
-
|
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A339
2910021125
|
£1.75
|
£2.10
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A340
2910021125
|
£1.75
|
£2.10
|
|
|
36 - SOCKET HEAD CAP SCREW DIN 84-BM5x55-8.8
BSD-2910021176.A141
2910021176
|
-
|
|
|
|
37 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1127
2910021118
|
£1.84
|
£2.21
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A412
2910021116
|
£2.27
|
£2.72
|
|
|
46 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A262
2916680006
|
-
|
|
|
|
60 - SPINDLE BEARING
BSD-1605806186.A4
1605806186
|
-
|
|
|
|
61 - GROOVE BALL BEARING 15x32x8
BSD-1900900201.A63
1900900201
|
-
|
|
|
|
62 - SPACER BUSHING
BSD-1600300026.A84
1600300026
|
-
|
|
|
|
63 - GROOVE BALL BEARING 15x35x11
BSD-1900900303.A45
1900900303
|
-
|
|
|
|
64 - SPACER BUSHING
BSD-1600300027.A23
1600300027
|
-
|
|
|
|
65 - DRILLING SPINDLE 5/8x16 UN
BSD-1603523093.A11
1603523093
|
-
|
|
|
|
66 - RETAINING SNAP RING
BSD-3607030355.A155
3607030355
|
£19.91
|
£23.89
|
|
|
67 - SHIM 0.5 MM
BSD-1600102003.A131
1600102003
|
£1.75
|
£2.10
|
|
|
68 - SEALING DISK
BSD-1600108000.A35
1600108000
|
-
|
|
|
|
69 - CYLINDRICAL GEAR Z=50
BSD-1606317045.A66
1606317045
|
-
|
|
|
|
70 - ADJUSTING BOLT
BSD-1603104005.A98
1603104005
|
-
|
|
|
|
71 - SHIM 0.2 MM
BSD-1420100620.A120
1420100620
|
£1.38
|
£1.66
|
|
|
72 - CONTROL LEVER
BSD-1602026026.A86
1602026026
|
-
|
|
|
|
73 - SOCKET HEAD CAP SCREW M3.5x5.5 MM
BSD-1603413005.A5
1603413005
|
£2.64
|
£3.17
|
|
|
74 - CONTROL LEVER
BSD-1602120006.A22
1602120006
|
-
|
|
|
|
75 - SPINDLE WITH GEAR Z=20/33/50
BSD-1606328048.A15
1606328048
|
-
|
|
|
|
76 - SPINDLE WITH GEAR Z=12
BSD-1606309036.A95
1606309036
|
-
|
|
|
|
77 - CYLINDRICAL GEAR Z=12/20/36
BSD-1606328058.A31
1606328058
|
-
|
|
|
|
78 - ROTARY SHAFT LIP SEAL
BSD-1600283003.A190
1600283003
|
£4.26
|
£5.11
|
|
|
79 - SHIM 0.5 MM
BSD-1600100631.A385
1600100631
|
£1.75
|
£2.10
|
|
|
80 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A586
2910021122
|
£2.27
|
£2.72
|
|
|
82 - SPRING LOCK WASHER DIN 127-B3.5
BSD-2916680004.A43
2916680004
|
-
|
|
|
|
83 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A356
2916660014
|
£1.75
|
£2.10
|
|
|
84 - CYLINDRICAL GEAR Z=35
BSD-1606317043.A1
1606317043
|
-
|
|
|
|
85 - CYLINDRICAL GEAR Z=33
BSD-1606320041.A4
1606320041
|
-
|
|
|
|
86 - STICKER
BSD-1601110134.A4
1601110134
|
-
|
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A297
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A422
1602025030
|
£19.91
|
£23.89
|
|
|
651 - KEYLESS CHUCK dia3-16 MM. 5/8
BSD-1608572014.A2
1608572014
|
-
|
|
|
|
651/2 - KEY CHUCK dia3-16 MM. 5/8
BSD-1608571056.A26
1608571056
|
£48.12
|
£57.74
|
|
|
811 - CARBON-BRUSH SET
BSD-1607014101.A81
1607014101
|
£11.87
|
£14.24
|
|
