2 - DC MOTOR 7.2V
BSD-1609340003.A18
1609340003
|
-
|
|
|
|
2/10 - PINION Z=11
BSD-2606316112.A85
2606316112
|
£4.26
|
£5.11
|
|
|
3 - BATTERY PACK 7.2V
BSD-1609340000.A10
1609340000
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200294.A7
2607200294
|
£14.91
|
£17.89
|
|
|
6 - TOOTHED SHAFT Z=10/19/81
BSD-1609340005.A91
1609340005
|
£16.74
|
£20.09
|
|
|
7 - SINTERED-METAL BUSHING
BSD-2600302002.A276
2600302002
|
£1.75
|
£2.10
|
|
|
8 - SET OF GEARS Z=58/67
BSD-1609340007.A202
1609340007
|
£14.91
|
£17.89
|
|
|
9 - SINTERED-METAL BUSHING
BSD-2600301011.A387
2600301011
|
£1.75
|
£2.10
|
|
|
10 - DRILLING SPINDLE 3/8
BSD-2606135018.A22
2606135018
|
-
|
|
|
|
11 - GROOVE BALL BEARING 10x26x8
BSD-1900905120.A157
1900905120
|
-
|
|
|
|
11 - GROOVE BALL BEARING 6000 DIN 625
BSD-1900900270.A50
1900900270
|
-
|
|
|
|
12 - KEY CHUCK dia1-10 MM. 3/8
BSD-1608571058.A25
1608571058
|
£13.99
|
£16.79
|
|
|
12 - KEY CHUCK dia1-10 MM. 3/8
BSD-1608571066.A0
1608571066
|
-
|
|
|
|
12/800 - CHUCK WRENCH SG 1. dia4x60 MM
BSD-1607950042.A15
1607950042
|
£3.49
|
£4.19
|
|
|
13 - ADJUSTING SLIDE
BSD-2601099027.A47
2601099027
|
-
|
|
|
|
14 - RATCHET SPRING
BSD-1609340011.A19
1609340011
|
-
|
|
|
|
15 - HOLDING SPRING
BSD-2601250002.A151
2601250002
|
£1.32
|
£1.58
|
|
|
16 - SCREWDRIVER BLADE 6 MM
BSD-1609200147.A47
1609200147
|
£3.72
|
£4.47
|
|
|
17 - CLAMP SPRING
BSD-2601250003.A4
2601250003
|
-
|
|
|
|
19 - LOCKING LEVER 32.7 MM
BSD-1609340014.A25
1609340014
|
-
|
|
|
|
19 - LOCKING LEVER 36.5 MM
BSD-2601099026.A49
2601099026
|
-
|
|
|
|
20 - CONTACT SPRING
BSD-2601324012.A47
2601324012
|
£1.75
|
£2.10
|
|
|
21 - HOLDING SPRING dia8.7 MM
BSD-2601251002.A43
2601251002
|
-
|
|
|
|
21 - SPRING CLIP dia 6.2 MM
BSD-1609340016.A1
1609340016
|
-
|
|
|
|
22 - SPACER SLEEVE dia 6 MM
BSD-1609340017.A22
1609340017
|
-
|
|
|
|
23 - COUNTERSUNK-HEAD SCREW M5x20
BSD-2609110721.A219
2609110721
|
£2.16
|
£2.59
|
|
|
24 - SCREW 4x16
BSD-2603490022.A53
2603490022
|
£1.75
|
£2.10
|
|
|
25 - SOCKET HEAD CAP SCREW DIN 84-AM4x20-8.8
BSD-2910021130.A180
2910021130
|
£1.75
|
£2.10
|
|
|
26 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A404
2915011005
|
£1.75
|
£2.10
|
|
|
27 - SPRING RETAINING RING DIN 471-10x1MM-FSt
BSD-2916650001.A503
2916650001
|
£2.61
|
£3.13
|
|
|
27 - LOCKING WASHER
BSD-1609340020.A19
1609340020
|
-
|
|
|
|
30 - MANUFACTURER'S NAMEPLATE
BSD-1601110217.A1
1601110217
|
-
|
|
|
|
52 - DUST PROTECTION
BSD-2601010038.A172
2601010038
|
-
|
|
|
|
650 - FAST CHARGER EU 230/7.2-24V. 1h
BSD-2607224425.A379
2607224425
|
£88.07
|
£105.68
|
|
|
650 - FAST CHARGER EU 230/7.2-14.4V. 30 MIN.
BSD-2607224701.A7
2607224701
|
£88.07
|
£105.68
|
|
|
800 - BATT-OPER DRILL
BSD-0601920023.A3
0601920023
|
-
|
|
|
|
800 - BATT-OPER DRILL
BSD-0601920061.A1
0601920061
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104873.A7
2605104873
|
-
|
|
|
