1 - SOCKET HEAD CAP SCREW
BSD-1609390251.A7
1609390251
|
-
|
|
|
|
2 - HOUSING COVER
BSD-1609390252.A3
1609390252
|
-
|
|
|
|
3 - HANDLE
BSD-1609390253.A2
1609390253
|
-
|
|
|
|
4 - SOCKET HEAD CAP SCREW
BSD-1609390254.A8
1609390254
|
-
|
|
|
|
5 - HOUSING HALF
BSD-1609390255.A2
1609390255
|
-
|
|
|
|
6 - RUBBER BUFFER
BSD-1609390256.A8
1609390256
|
-
|
|
|
|
7 - SOCKET HEAD CAP SCREW
BSD-1609390257.A2
1609390257
|
-
|
|
|
|
8 - SOCKET HEAD CAP SCREW
BSD-1609390258.A8
1609390258
|
-
|
|
|
|
9 - BALL BEARING 7x22x7
BSD-1900905018.A20
1900905018
|
£18.96
|
£22.75
|
|
|
10 - SPINDLE WITH GEAR
BSD-1609390259.A2
1609390259
|
-
|
|
|
|
11 - BUSHING
BSD-1609390260.A8
1609390260
|
-
|
|
|
|
12 - GEAR HOUSING
BSD-1609390261.A2
1609390261
|
-
|
|
|
|
13 - SOCKET HEAD CAP SCREW BM 5x30
BSD-1609390289.A8
1609390289
|
-
|
|
|
|
14 - SOCKET HEAD CAP SCREW dia 4x25 MM
BSD-1609390262.A8
1609390262
|
-
|
|
|
|
15 - SAW CHAIN
BSD-1609390241.A0
1609390241
|
-
|
|
|
|
16 - GUIDE RAIL
BSD-1609390239.A10
1609390239
|
-
|
|
|
|
17 - SEALING CAP
BSD-1609390265.A8
1609390265
|
-
|
|
|
|
18 - OIL RESERVOIR
BSD-1609390266.A2
1609390266
|
-
|
|
|
|
19 - .
BSD-1609390267.A8
1609390267
|
-
|
|
|
|
20 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A93
2916011016
|
£1.75
|
£2.10
|
|
|
21 - HEX NUT M8
BSD-1609390268.A1
1609390268
|
-
|
|
|
|
24 - PROTECTIVE COVER
BSD-1609390286.A0
1609390286
|
-
|
|
|
|
25 - SPRING LOCK WASHER B 8 DIN 127
BSD-2916680009.A47
2916680009
|
-
|
|
|
|
26 - HEX NUT DIN 934-M8-8-A
BSD-2915011009.A162
2915011009
|
£2.61
|
£3.13
|
|
|
27 - HOUSING HALF
BSD-1609390272.A3
1609390272
|
-
|
|
|
|
28 - OVAL-HEAD SCREW DIN 7985-M3x6-4.8
BSD-2910641048.A0
2910641048
|
-
|
|
|
|
29 - CARBON-BRUSH SET
BSD-1609390288.A1
1609390288
|
-
|
|
|
|
30 - BRUSH HOLDER
BSD-1609390264.A1
1609390264
|
-
|
|
|
|
31 - POWER SUPPLY CORD CH 230V 0.55m 2 x 1.0mm H07 RN-F
BSD-1604460442.A11
1604460442
|
£12.04
|
£14.45
|
|
|
32 - GROMMET
BSD-1609390270.A9
1609390270
|
-
|
|
|
|
33 - FASTENING CLAMP
BSD-1609390273.A1
1609390273
|
-
|
|
|
|
35 - SUPPRESSION CAPACITOR
BSD-1609390274.A9
1609390274
|
-
|
|
|
|
36 - ON-OFF SWITCH
BSD-1609390275.A1
1609390275
|
-
|
|
|
|
37 - POLE SHOE 220V
BSD-1609390276.A6
1609390276
|
-
|
|
|
|
38 - RETAINING BRACKET
BSD-1609390277.A1
1609390277
|
-
|
|
|
|
39 - SOCKET HEAD CAP SCREW dia 4x16 MM
BSD-1609390278.A9
1609390278
|
-
|
|
|
|
40 - AIR-DEFLECTOR RING
BSD-1609390279.A1
1609390279
|
-
|
|
|
|
41 - ARMATURE 220-230V
BSD-1609390280.A2
1609390280
|
-
|
|
|
|
42 - GROOVE BALL BEARING 10x26x8
BSD-1900905120.A205
1900905120
|
-
|
|
|
|
43 - COUNTERSUNK-HEAD SCREW M 3x10 DIN 963-5.8
BSD-2910771052.A33
2910771052
|
-
|
|
|
|
45 - PROTECTIVE SHIELD
BSD-1609390282.A1
1609390282
|
-
|
|
|
|
48 - SOCKET HEAD CAP SCREW dia 4x50 MM
BSD-1609390283.A9
1609390283
|
-
|
|
|
|
49 - RETAINING PIN
BSD-1609390284.A1
1609390284
|
-
|
|
|
|
52 - SPRING LOCK WASHER B 3 DIN 127
BSD-2916680003.A0
2916680003
|
-
|
|
|
|
60 - NAMEPLATE
BSD-1601110165.A0
1601110165
|
-
|
|
|
|
60 - NAMEPLATE
BSD-1601110167.A1
1601110167
|
-
|
|
|
|
60 - NAMEPLATE
BSD-1601110169.A0
1601110169
|
-
|
|
|
|
61 - NAMEPLATE
BSD-1601110174.A1
1601110174
|
-
|
|
|
|
62 - REFERENCE PLATE
BSD-1601110170.A1
1601110170
|
-
|
|
|
|
62 - REFERENCE PLATE
BSD-1601110171.A5
1601110171
|
-
|
|
|
|
650 - PROTECTIVE COVER
BSD-1609390449.A10
1609390449
|
-
|
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW13
BSD-1907950507.A5
1907950507
|
-
|
|
|
|
652 - SCREWDRIVER GR. 2 DIN 52 628
BSD-1907959050.A10
1907959050
|
-
|
|
|
