An exploded drawing and listing for the Bosch ROTAK 43 / 3600H81D71 / --- 230 Volt
Ex VAT Inc VAT
1/17 - DRIVE SHAFT BSD-F016L65108.A6 F016L65108 £13.12 £15.75
1/21 - DRIVE BELT BSD-F016L65109.A95 F016L65109 £16.41 £19.69
32 - SELF-CUTTING SCREW BSD-F016L37433.A42 F016L37433 £1.75 £2.10
40 - MOWER DECK BSD-F016L66159.A32 F016L66159 £37.27 £44.72
41/01/02 - BEARING 6003 BSD-F016L64387.A1 F016L64387 £5.30 £6.36
42 - COVER PANEL BSD-F016L66041.A8 F016L66041 -
43 - MOTOR HOOD BSD-F016L65159.A11 F016L65159 £30.28 £36.33
52/01 - AXLE BSD-F016L66467.A0 F016L66467 £5.01 £6.01
52/02 - LEVER BSD-F016L90582.A110 F016L90582 -
52/03 - SPACER BSD-F016L90583.A82 F016L90583 £2.33 £2.80
55 - CUTTER BLADE BSD-F016L65924.A6 F016L65924 £33.74 £40.49
59 - SCREW AND WASHER ASSEMBLY BSD-F016104350.A0 F016104350 £1.95 £2.34
61/01 - AXLE BSD-F016L66466.A29 F016L66466 £5.87 £7.04
61/02 - LEVER BSD-F016L90581.A82 F016L90581 £7.78 £9.33
61/03 - SPACER BSD-F016L90585.A110 F016L90585 £1.75 £2.10
64 - RATCHET CAP 9 MM BSD-F016F05700.A1 F016F05700 £1.95 £2.34
75/01 - HANDLE BSD-F016L66133.A7 F016L66133 £23.86 £28.63
75/4 - SWITCH HOUSING BSD-F016L65739.A19 F016L65739 -
75/5 - SWITCH HOUSING BSD-F016L66235.A67 F016L66235 £3.34 £4.01
75/6 - CABLE CLEAT BSD-F016T49630.A38 F016T49630 -
75/9 - SPRING LEVER BSD-F016T49845.A49 F016T49845 -
75/10 - PUSH-BUTTON BSD-F016F05705.A54 F016F05705 £3.75 £4.50
75/11 - COMPRESSION SPRING BSD-F016T49226.A67 F016T49226 -
75/14 - SELF-CUTTING SCREW 4x19 MM BSD-F016T49429.A351 F016T49429 £1.75 £2.10
75/27 - CABLE CLIP BSD-F016L90575.A24 F016L90575 £1.75 £2.10
80 - COLLECTOR BOX BOTTOM L/H BSD-F016L64304.A13 F016L64304 £21.68 £26.01
81 - COLLECTOR BOX BOTTOM R/H BSD-F016L64338.A24 F016L64338 £16.41 £19.69
82 - GUARD FLAP BSD-F016L66137.A124 F016L66137 £13.32 £15.99
83/84 - HANDLE BSD-F016L66441.A51 F016L66441 £4.75 £5.70
85 - SPRING BSD-F016L66165.A168 F016L66165 £2.82 £3.39
99 - SPRING BSD-F016L59327.A61 F016L59327 £2.80 £3.36
100 - SPRING BSD-F016L65790.A46 F016L65790 £1.95 £2.34
101 - LINK PIECE BSD-F016L65971.A2 F016L65971 -
106 - WIRE GUIDE BSD-F016L90579.A26 F016L90579 £33.45 £40.14
107 - FILTER HOUSING BSD-F016L65539.A35 F016L65539 £11.30 £13.56
108 - BEARING COVER BSD-F016L67627.A48 F016L67627 £2.71 £3.25
110 - FILTER HOUSING BSD-F016L65709.A19 F016L65709 £5.87 £7.04
150 - ROLLER DRUM BSD-F016L66175.A37 F016L66175 -
151 - BRACKET BSD-F016L64900.A9 F016L64900 -
152 - BRACKET BSD-F016L64901.A73 F016L64901 -
153 - SPINDLE BSD-F016L65870.A36 F016L65870 £6.61 £7.93
452 - COMPANY LOGO ROTAK 43 BSD-F016L66273.A5 F016L66273 £2.61 £3.13
501 - PLAIN WASHER dia8.15 BSD-F016T48185.A45 F016T48185 £3.72 £4.47
504 - SELF-CUTTING SCREW 4x19 MM BSD-F016T49429.A352 F016T49429 £1.75 £2.10
505 - SCREW M5x8 Csk Hd. BSD-F016L36542.A22 F016L36542 £2.61 £3.13
506/1 - BOLT M6x50 BSD-F016L59277.A64 F016L59277 £3.80 £4.56
506/2 - WING NUT BSD-F016L66136.A2 F016L66136 £4.26 £5.11
801 - MOTOR BSD-F016103596.A31 F016103596 £134.16 £160.99
801/1/20 - BEARING BSD-F016L64594.A31 F016L64594 £3.75 £4.50
841 - HOUSING BSD-F016103600.A12 F016103600 -
841/1 - COVER BSD-F016104318.A19 F016104318 £5.87 £7.04
850 - WHEEL BSD-F016103992.A0 F016103992 -
860 - WHEEL BSD-F016103908.A11 F016103908 £7.78 £9.33
875/02 - POWER SUPPLY CORD GB 22m 2 x 0.75mm without plug BSD-F016104085.A4 F016104085 £31.64 £37.97
875/03 - CONNECTING CABLE BSD-F016103602.A36 F016103602 £14.72 £17.67
875/7 - ON-OFF SWITCH BSD-F016F05717.A0 F016F05717 £14.91 £17.89
875/18 - CONTROL BAR BSD-F016103601.A1 F016103601 -
878 - BOTTOM HANDLE BSD-F016L65166.A21 F016L65166 -
883 - COVER BSD-F016103608.A117 F016103608 £27.23 £32.68
893 - THERMAL PROTECTOR BSD-F016103605.A31 F016103605 £12.04 £14.45
