1 - MOTOR HOUSING
BSD-3605105001.A3
3605105001
|
-
|
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-3604080001.A1
3604080001
|
-
|
|
|
|
3/3 - FAN
BSD-3606610001.A1
3606610001
|
-
|
|
|
|
3/5 - MAGNETO BALL BEARING E 10 DIN 615
BSD-1900900008.A15
1900900008
|
-
|
|
|
|
3/6 - OIL RETURN RING
BSD-1600313008.A0
1600313008
|
-
|
|
|
|
3/7 - MAGNETO BALL BEARING E 7 DIN 615
BSD-1900900005.A2
1900900005
|
£36.63
|
£43.96
|
|
|
4 - SWITCH
BSD-1607200038.A132
1607200038
|
£54.42
|
£65.30
|
|
|
5 - ELEC. CABLE W/CONNECTION
BSD-3604462033.A0
3604462033
|
-
|
|
|
|
6 - GROMMET dia13.2-dia17.0x120 MM
BSD-1600703002.A3
1600703002
|
£5.01
|
£6.01
|
|
|
7 - CLAMP
BSD-1601315011.A14
1601315011
|
-
|
|
|
|
8 - NAMEPLATE
BSD-3601106053.A3
3601106053
|
£5.30
|
£6.36
|
|
|
10 - SWITCH
BSD-3607200000.A54
3607200000
|
£21.52
|
£25.83
|
|
|
11 - SWITCH HOUSING
BSD-3605130030.A0
3605130030
|
-
|
|
|
|
12 - SWITCH COVER
BSD-3605500070.A3
3605500070
|
-
|
|
|
|
13 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A463
1602381001
|
-
|
|
|
|
14 - SEALING CAP
BSD-3605500075.A14
3605500075
|
-
|
|
|
|
15 - SET SCREW
BSD-1603402004.A100
1603402004
|
£2.61
|
£3.13
|
|
|
16 - AIR-DEFLECTOR RING
BSD-1600117000.A3
1600117000
|
-
|
|
|
|
18 - BEARING HOUSING
BSD-3605820049.A16
3605820049
|
-
|
|
|
|
19 - SHIM 0.05 MM
BSD-1600102654.A3
1600102654
|
£1.95
|
£2.34
|
|
|
20 - SHIM 0.5 MM
BSD-1600101633.A14
1600101633
|
£1.75
|
£2.10
|
|
|
21 - SEALING DISK
BSD-1600108006.A0
1600108006
|
-
|
|
|
|
22 - SHIM 0.2 MM
BSD-1600100609.A37
1600100609
|
-
|
|
|
|
23 - TOOTHED SHAFT Z=11/25
BSD-3606300027.A1
3606300027
|
-
|
|
|
|
24 - BUSHING
BSD-3600311005.A3
3600311005
|
-
|
|
|
|
25 - O-RING 54.0x3.0 MM
BSD-1600210004.A46
1600210004
|
£2.80
|
£3.36
|
|
|
26 - INTERMEDIATE BEARING
BSD-3605820000.A3
3605820000
|
-
|
|
|
|
27 - STOP BUSHING
BSD-3600320003.A0
3600320003
|
£13.41
|
£16.09
|
|
|
28 - CONTROL SHAFT
BSD-3603123002.A3
3603123002
|
-
|
|
|
|
29 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A102
1903230007
|
£1.75
|
£2.10
|
|
|
30 - RETAINING RING 12 DIN 9045
BSD-2916600007.A80
2916600007
|
£2.80
|
£3.36
|
|
|
31 - CYLINDRICAL GEAR Z=40
BSD-3606325000.A2
3606325000
|
-
|
|
|
|
32 - BALL DIN5401-6.5MM-III-ST
BSD-1903230012.A2
1903230012
|
£1.75
|
£2.10
|
|
|
33 - COMPRESSION SPRING
BSD-3604612002.A3
3604612002
|
-
|
|
|
|
34 - BALL DIN 5401-9 MM III-ST
BSD-1903230015.A1
1903230015
|
£2.61
|
£3.13
|
|
|
35 - CLUTCH ELEMENT
BSD-3606445019.A2
3606445019
|
-
|
|
|
|
36 - CYLINDRICAL ROLLER dia 5x12 MM
BSD-3603200001.A3
3603200001
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-3604619013.A3
3604619013
|
-
|
|
|
|
38 - BACKUP RING
BSD-3600250000.A0
3600250000
|
-
|
|
|
|
40 - THREADED SLEEVE
BSD-3600364009.A0
3600364009
|
-
|
|
|
|
41 - SPRING RETAINING RING DIN 472-34x1.5MM
BSD-2916660037.A3
2916660037
|
£2.33
|
£2.80
|
|
|
43 - SPINDLE BEARING
BSD-3605806014.A3
3605806014
|
-
|
|
|
|
43/2 - BUSHING
BSD-3600320004.A3
3600320004
|
-
|
|
|
|
44 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A101
1903230007
|
£1.75
|
£2.10
|
|
|
45 - HOLDING SPRING
BSD-3604682003.A51
3604682003
|
-
|
|
|
|
46 - PRESSURE SPINDLE
BSD-1603203024.A58
1603203024
|
-
|
|
|
|
47 - CABLE
BSD-1604440000.A2
1604440000
|
-
|
|
|
|
48 - PVC-INSULATED CABLE
BSD-1604441000.A15
1604441000
|
-
|
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM3x20-8.8
BSD-2910021062.A18
2910021062
|
£1.75
|
£2.10
|
|
|
50 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-5.8
BSD-2910011120.A143
2910011120
|
£1.75
|
£2.10
|
|
|
51 - HEX SOCKET HEAD CAP SCREW
BSD-3603414002.A3
3603414002
|
-
|
|
|
|
52 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A793
2910021122
|
£2.16
|
£2.59
|
|
|
53 - RETAINING SNAP RING
BSD-1600209007.A8
1600209007
|
-
|
|
|
|
54 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A140
2910110120
|
£1.75
|
£2.10
|
|
|
55 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A553
3603133001
|
£2.61
|
£3.13
|
|
|
56 - COMPRESSION SPRING
BSD-3604611010.A0
3604611010
|
-
|
|
|
|
57 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A448
2916690003
|
£1.75
|
£2.10
|
|
|
58 - SPRING WASHER dia4.2 MM
BSD-3600150006.A392
3600150006
|
£2.61
|
£3.13
|
|
|
59 - CLAMPING SADDLE
BSD-3601321001.A765
3601321001
|
£3.72
|
£4.47
|
|
|
61 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x35-8.8
BSD-2910141136.A106
2910141136
|
£2.80
|
£3.36
|
|
|
62 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A411
1903230006
|
£2.16
|
£2.59
|
|
|
63 - END SPLICE
BSD-3604477008.A116
3604477008
|
£1.75
|
£2.10
|
|
|
64 - SET SCREW
BSD-3603402000.A110
3603402000
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1790
3601119236
|
£3.72
|
£4.47
|
|
|
650 - SLOTTED SCREWDRIVER
BSD-1607950037.A9
1607950037
|
£51.22
|
£61.47
|
|
|
702 - AUXILIARY HANDLE dia48 MM
BSD-3602025007.A3
3602025007
|
£27.23
|
£32.68
|
|
|
703 - COMPRESSION SPRING
BSD-3604614000.A3
3604614000
|
-
|
|
|
|
801 - SPINDLE BEARING
BSD-3605806017.A3
3605806017
|
-
|
|
|
|
802 - CARRIER F 6.3 (1/4)
BSD-3606445016.A3
3606445016
|
-
|
|
|
