1 - MOTOR HOUSING
BSD-3605102048.A0
3605102048
|
£103.14
|
£123.77
|
|
|
3 - LUBRICATING FELT
BSD-1603212000.A61
1603212000
|
-
|
|
|
|
4 - HANDLE
BSD-3605132046.A65
3605132046
|
-
|
|
|
|
5 - FELT WASHER
BSD-1600205026.A119
1600205026
|
£2.61
|
£3.13
|
|
|
6 - STATOR 265V/200HZ
BSD-1604229181.A14
1604229181
|
£306.65
|
£367.98
|
|
|
7 - AIR-DEFLECTOR RING
BSD-1600117001.A6
1600117001
|
£2.16
|
£2.59
|
|
|
8 - ROTOR WITHOUT WINDING
BSD-1604080053.A0
1604080053
|
£134.16
|
£160.99
|
|
|
9 - GROMMET dia5.5-dia8.3x75 MM
BSD-1600703012.A96
1600703012
|
£2.52
|
£3.02
|
|
|
10 - ELEC. CABLE W/CONNECTION
BSD-3604462048.A28
3604462048
|
-
|
|
|
|
11 - FASTENING CLAMP
BSD-1601302001.A114
1601302001
|
£1.75
|
£2.10
|
|
|
12 - SOCKET-TERMINAL STRIP 1x1.5 MM/2
BSD-1901091012.A119
1901091012
|
£5.30
|
£6.36
|
|
|
14 - SWITCH
BSD-1607200067.A66
1607200067
|
-
|
|
|
|
15 - HOUSING COVER
BSD-3605500066.A2
3605500066
|
-
|
|
|
|
16 - NAMEPLATE
BSD-1601106002.A19
1601106002
|
£1.75
|
£2.10
|
|
|
18 - NAMEPLATE
BSD-3601106053.A976
3601106053
|
£5.30
|
£6.36
|
|
|
19 - DRILLING SPINDLE
BSD-1603124084.A0
1603124084
|
-
|
|
|
|
20 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A897
1600905011
|
£5.58
|
£6.70
|
|
|
21 - SEALING DISK
BSD-1600108023.A6
1600108023
|
-
|
|
|
|
22 - SPINDLE HOUSING
BSD-1605806279.A5
1605806279
|
-
|
|
|
|
23 - RETAINING SNAP RING
BSD-1600501056.A1
1600501056
|
-
|
|
|
|
27 - GEAR HOUSING
BSD-1605820168.A1
1605820168
|
-
|
|
|
|
28 - CYLINDRICAL GEAR Z=19
BSD-1606319015.A5
1606319015
|
-
|
|
|
|
29 - SEALING DISK dia18xdia10x4 MM
BSD-1600108024.A68
1600108024
|
£1.75
|
£2.10
|
|
|
30 - CONICAL SPRING WASHER
BSD-1600501030.A95
1600501030
|
-
|
|
|
|
31 - FELT WASHER
BSD-1600205025.A67
1600205025
|
-
|
|
|
|
32 - INTERMEDIATE RING
BSD-1600300044.A49
1600300044
|
-
|
|
|
|
34 - SHIM
BSD-1410101601.A0
1410101601
|
-
|
|
|
|
36 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A197
2916010409
|
-
|
|
|
|
37 - SPRING RETAINING RING DIN 471-8x0.8 FSt
BSD-2916640005.A121
2916640005
|
£1.75
|
£2.10
|
|
|
38 - SPRING WASHER DIN 137-A4
BSD-1600150006.A447
1600150006
|
-
|
|
|
|
41 - GROOVE BALL BEARING 6x19x6
BSD-1900900428.A37
1900900428
|
£16.74
|
£20.09
|
|
|
42 - SINTERED-METAL BUSHING J4G7x8R6x6DIN1850
BSD-1900301003.A53
1900301003
|
-
|
|
|
|
43 - TAPPING SCREW DIN 7971-BZ4.2x13
BSD-2910211025.A88
2910211025
|
£1.75
|
£2.10
|
|
|
45 - SOCKET HEAD CAP SCREW DIN 84-AM3x6-5.8
BSD-2910011048.A82
2910011048
|
£1.75
|
£2.10
|
|
|
46 - TAPPING SCREW DIN 7971-BZ3.5x19
BSD-2910211013.A60
2910211013
|
-
|
|
|
|
47 - HEX SOCKET HEAD CAP SCREW M 3x40 MM
BSD-3603414008.A6
3603414008
|
-
|
|
|
|
48 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A26
2910110118
|
£1.75
|
£2.10
|
|
|
49 - O-RING 35.0x1.5 MM
BSD-1600210010.A98
1600210010
|
£2.80
|
£3.36
|
|
|
50 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A164
2910001052
|
£2.16
|
£2.59
|
|
