1 - MOTOR HOUSING
BSD-3605102058.A56
3605102058
|
£120.11
|
£144.13
|
|
|
2 - SEAL RING
BSD-1600209011.A293
1600209011
|
£2.80
|
£3.36
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A153
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR
BSD-3604080020.A123
3604080020
|
-
|
|
|
|
5/3 - FAN
BSD-1606610105.A141
1606610105
|
£14.91
|
£17.89
|
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A152
1900905015
|
£30.42
|
£36.51
|
|
|
7/1 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A162
3600206002
|
-
|
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A178
1900905017
|
£23.86
|
£28.63
|
|
|
9 - BEARING HOUSING
BSD-3605820046.A56
3605820046
|
-
|
|
|
|
10 - GROOVE BALL BEARING 9x24x7
BSD-1610905011.A60
1610905011
|
£14.91
|
£17.89
|
|
|
11 - HANDLE
BSD-3605132044.A39
3605132044
|
-
|
|
|
|
12 - POWER SUPPLY CORD
BSD-1604422018.A2
1604422018
|
-
|
|
|
|
13/2 - GROMMET
BSD-1602388012.A0
1602388012
|
-
|
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A149
1601302014
|
£2.61
|
£3.13
|
|
|
15 - CONNECTION HOUSING
BSD-3600099005.A45
3600099005
|
£16.41
|
£19.69
|
|
|
16/1 - STRIP TERMINAL
BSD-1901091014.A1
1901091014
|
-
|
|
|
|
17/1 - COVER PLATE
BSD-1602386001.A2
1602386001
|
-
|
|
|
|
19 - SEALING CAP
BSD-3605500071.A14
3605500071
|
£16.41
|
£19.69
|
|
|
20 - INTERMEDIATE BEARING
BSD-3605820061.A11
3605820061
|
-
|
|
|
|
21 - SEALING DISK
BSD-1600108033.A6
1600108033
|
£2.16
|
£2.59
|
|
|
22 - COUPLING HALF
BSD-1606455050.A14
1606455050
|
-
|
|
|
|
23 - SPACER RING
BSD-1600201010.A12
1600201010
|
-
|
|
|
|
24 - CYLINDRICAL GEAR Z=23
BSD-1606317066.A9
1606317066
|
-
|
|
|
|
25 - SPINDLE WITH GEAR Z=13/34
BSD-1606328090.A2
1606328090
|
-
|
|
|
|
27 - SHIM 0.50 MM
BSD-2600100613.A148
2600100613
|
£1.75
|
£2.10
|
|
|
28 - SPINDLE HOUSING
BSD-1605806282.A2
1605806282
|
-
|
|
|
|
29 - O-RING 22x2 MM
BSD-1900210321.A10
1900210321
|
£5.30
|
£6.36
|
|
|
31 - DRIVE SHAFT
BSD-1603123024.A8
1603123024
|
-
|
|
|
|
33 - BUSHING
BSD-1600521005.A20
1600521005
|
-
|
|
|
|
34 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A180
1903230004
|
£2.16
|
£2.59
|
|
|
35 - COMPRESSION SPRING
BSD-1604619011.A23
1604619011
|
-
|
|
|
|
36 - STRIKER
BSD-1608710025.A10
1608710025
|
-
|
|
|
|
37 - BALL DIN 5401-5 G28
BSD-1903230009.A428
1903230009
|
£1.75
|
£2.10
|
|
|
38 - COMPRESSION SPRING
BSD-1604611018.A0
1604611018
|
-
|
|
|
|
39 - SPACER RING
BSD-1600202030.A0
1600202030
|
-
|
|
|
|
44 - NAMEPLATE
BSD-3601106053.A904
3601106053
|
£5.30
|
£6.36
|
|
|
45 - GROOVED NAIL
BSD-3603133000.A669
3603133000
|
£2.61
|
£3.13
|
|
|
46/1 - HEX NUT DIN 934 -M4-m-8
BSD-2915011005.A141
2915011005
|
£1.75
|
£2.10
|
|
|
47 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A105
2916060003
|
£1.32
|
£1.58
|
|
|
48 - CLAMPING SADDLE
BSD-3601321001.A196
3601321001
|
£3.72
|
£4.47
|
|
|
49 - SPRING WASHER dia4.2 MM
BSD-3600150006.A383
3600150006
|
£2.61
|
£3.13
|
|
|
50 - PAN HEAD SCREW DIN 85-AM4x8-MS
BSD-2910110118.A85
2910110118
|
£1.75
|
£2.10
|
|
|
51 - PAN HEAD SCREW DIN 85-AM3.5x15-4.8
BSD-2910091046.A57
2910091046
|
£1.75
|
£2.10
|
|
|
52 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A702
2910021116
|
£2.16
|
£2.59
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A300
2910021122
|
£2.16
|
£2.59
|
|
|
54 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A215
2910141122
|
£2.16
|
£2.59
|
|
|
55 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A63
2910141131
|
£2.16
|
£2.59
|
|
|
56 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A58
2910141140
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW
BSD-1603410005.A1
1603410005
|
-
|
|
|
|
58/1 - TAPPING SCREW DIN 7971-BZ3.9x25
BSD-2910211022.A106
2910211022
|
£1.75
|
£2.10
|
|
|
59 - COUPLING HALF
BSD-1606455051.A0
1606455051
|
-
|
|
|
|
60 - GUIDE SLEEVE
BSD-1600506009.A3
1600506009
|
£7.36
|
£8.83
|
|
|
61 - DETENT PIN
BSD-1603124085.A12
1603124085
|
£3.72
|
£4.47
|
|
|
62 - COMPRESSION SPRING
BSD-1604611019.A12
1604611019
|
£2.80
|
£3.36
|
|
|
63 - SET SCREW
BSD-3603402000.A320
3603402000
|
£1.75
|
£2.10
|
|
|
64 - END SPLICE
BSD-3604477008.A364
3604477008
|
£1.75
|
£2.10
|
|
|
69 - BUSHING
BSD-2600300058.A38
2600300058
|
-
|
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A114
3600190012
|
-
|
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A66
2910780050
|
-
|
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A100
1600210045
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A803
3601119236
|
£3.72
|
£4.47
|
|
|
700 - COMPRESSION SPRING
BSD-1604619011.A22
1604619011
|
-
|
|
|
|
702 - SUSPENSION LOOP
BSD-3604682000.A25
3604682000
|
£14.72
|
£17.67
|
|
|
703 - HEX SOCKET HEAD CAP SCREW
BSD-2910131193.A28
2910131193
|
£1.75
|
£2.10
|
|
|
800 - COUPLING HALF
BSD-1606455052.A12
1606455052
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-3605102028.A106
3605102028
|
£156.22
|
£187.46
|
|
|
809 - BEARING HOUSING
BSD-1605820162.A29
1605820162
|
-
|
|
|
|
810 - STATOR 265V/200HZ. 200V/150HZ
BSD-1604229200.A43
1604229200
|
£458.51
|
£550.21
|
|
