1 - MOTOR HOUSING
BSD-3605102058.A76
3605102058
|
£120.11
|
£144.13
|
|
2 - SEAL RING
BSD-1600209011.A240
1600209011
|
£2.80
|
£3.36
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A133
1600502005
|
£2.61
|
£3.13
|
|
5 - ROTOR
BSD-3604080020.A99
3604080020
|
-
|
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A117
1900905015
|
£30.42
|
£36.51
|
|
7 - O-RING 12.0x2.25 MM
BSD-3600210039.A34
3600210039
|
£7.36
|
£8.83
|
|
7/1 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A187
3600206002
|
-
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A210
1900905017
|
£23.86
|
£28.63
|
|
9 - BEARING HOUSING
BSD-3605820046.A41
3605820046
|
-
|
|
|
11 - CONNECTION HOUSING
BSD-3600099004.A14
3600099004
|
£21.68
|
£26.01
|
|
12 - POWER SUPPLY CORD
BSD-1604462053.A5
1604462053
|
-
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A373
3600703011
|
£2.80
|
£3.36
|
|
15 - HANDLE
BSD-3607031145.A2
3607031145
|
-
|
|
|
17 - HANDLE
BSD-3607031145.A3
3607031145
|
-
|
|
|
18 - FASTENING CLAMP
BSD-1601302014.A116
1601302014
|
£2.61
|
£3.13
|
|
20 - GEAR HOUSING
BSD-2605806227.A60
2605806227
|
-
|
|
|
21 - SPINDLE WITH GEAR Z=37
BSD-2606100052.A58
2606100052
|
-
|
|
|
22 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A240
1903230004
|
£2.16
|
£2.59
|
|
23 - COUPLING HALF
BSD-2606445000.A10
2606445000
|
-
|
|
|
24 - COMPRESSION SPRING
BSD-1604616010.A25
1604616010
|
-
|
|
|
25 - COMPRESSION SPRING
BSD-1604619005.A18
1604619005
|
-
|
|
|
26 - SHIM
BSD-1600100607.A54
1600100607
|
-
|
|
|
27 - BUSHING
BSD-1600309004.A49
1600309004
|
-
|
|
|
28 - ROUND NUT
BSD-1603341000.A6
1603341000
|
-
|
|
|
29 - GUIDE SLEEVE
BSD-2600460001.A25
2600460001
|
-
|
|
|
30 - CARRIER 6 KT.. 6.3 MM
BSD-2606455002.A20
2606455002
|
-
|
|
|
31 - O-RING 8.0x1.5 MM
BSD-1900210103.A84
1900210103
|
£2.80
|
£3.36
|
|
32 - PRESSURE SPINDLE
BSD-1603120022.A12
1603120022
|
-
|
|
|
33 - COMPRESSION SPRING
BSD-1604626002.A4
1604626002
|
-
|
|
|
34 - SPINDLE WITH GEAR Z=14/34
BSD-1606328086.A9
1606328086
|
-
|
|
|
35 - DISC SPRING
BSD-3600150013.A167
3600150013
|
£3.72
|
£4.47
|
|
36 - SHIM 0.50 MM
BSD-2600100613.A97
2600100613
|
£1.75
|
£2.10
|
|
37 - SPRING LOCK WASHER
BSD-1600224011.A16
1600224011
|
-
|
|
|
38 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A276
1903230003
|
£2.61
|
£3.13
|
|
39 - NAMEPLATE
BSD-3601106053.A740
3601106053
|
£5.30
|
£6.36
|
|
40 - GROOVED NAIL
BSD-3603133000.A708
3603133000
|
£2.61
|
£3.13
|
|
43 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A39
2916010409
|
-
|
|
|
44 - SPRING WASHER DIN 137-A4
BSD-1600150006.A776
1600150006
|
-
|
|
|
45 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A211
2910110116
|
£1.75
|
£2.10
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A617
2910021116
|
£2.16
|
£2.59
|
|
48 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A195
2910141122
|
£2.16
|
£2.59
|
|
51 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A47
2910141140
|
£1.75
|
£2.10
|
|
52 - HEX SOCKET HEAD CAP SCREW
BSD-3603414001.A57
3603414001
|
-
|
|
|
54 - SET SCREW
BSD-3603402000.A428
3603402000
|
£1.75
|
£2.10
|
|
56 - END SPLICE
BSD-3604477008.A378
3604477008
|
£1.75
|
£2.10
|
|
69 - BUSHING
BSD-2600300058.A54
2600300058
|
-
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A84
3600190012
|
-
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A27
2910780050
|
-
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A120
1600210045
|
£1.75
|
£2.10
|
|
99 - REFERENCE PLATE
BSD-3601119236.A581
3601119236
|
£3.72
|
£4.47
|
|
652 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A23
2603101035
|
£2.80
|
£3.36
|
|
800 - MOTOR HOUSING
BSD-3605102028.A111
3605102028
|
£156.22
|
£187.46
|
|
809 - BEARING HOUSING
BSD-1605820162.A15
1605820162
|
-
|
|
|
810 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229201.A30
1604229201
|
£410.78
|
£492.94
|
|
