2 - SEAL RING
BSD-1600209011.A21
1600209011
|
£2.80
|
£3.36
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600502005.A363
1600502005
|
£2.61
|
£3.13
|
|
|
5 - ROTOR
BSD-3604080020.A24
3604080020
|
-
|
|
|
|
5/3 - FAN
BSD-1606610105.A20
1606610105
|
£14.91
|
£17.89
|
|
|
6 - GROOVE BALL BEARING 625-2Z DIN 625
BSD-1900905015.A301
1900905015
|
£30.42
|
£36.51
|
|
|
7 - O-RING 12.0x2.25 MM
BSD-3600210039.A153
3600210039
|
£7.36
|
£8.83
|
|
|
7/1 - RUBBER RING 6MM.dia12xdia16.4x3MM
BSD-3600206002.A64
3600206002
|
-
|
|
|
|
8 - GROOVE BALL BEARING 9x24x7
BSD-1900905017.A58
1900905017
|
£23.86
|
£28.63
|
|
|
9 - BEARING HOUSING
BSD-3605820046.A3
3605820046
|
-
|
|
|
|
11 - HANDLE
BSD-3605132044.A11
3605132044
|
-
|
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3604462049.A27
3604462049
|
-
|
|
|
|
13 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A1146
3600703011
|
£2.80
|
£3.36
|
|
|
14 - FASTENING CLAMP
BSD-1601302014.A788
1601302014
|
£2.61
|
£3.13
|
|
|
15 - CONNECTION HOUSING
BSD-3600099005.A19
3600099005
|
£16.41
|
£19.69
|
|
|
16 - REVERSING SWITCH
BSD-1607200043.A29
1607200043
|
-
|
|
|
|
17 - SWITCH
BSD-1607200038.A67
1607200038
|
£54.42
|
£65.30
|
|
|
18 - DISC SPRING
BSD-3600150013.A105
3600150013
|
£3.72
|
£4.47
|
|
|
19 - SEALING CAP
BSD-3605500071.A31
3605500071
|
£16.41
|
£19.69
|
|
|
20 - GEAR HOUSING
BSD-2605806227.A30
2605806227
|
-
|
|
|
|
21 - SPINDLE WITH GEAR Z=37
BSD-2606100052.A12
2606100052
|
-
|
|
|
|
22 - BALL DIN 5401-3 MM-III-ST
BSD-1903230004.A32
1903230004
|
£2.16
|
£2.59
|
|
|
23 - COUPLING HALF
BSD-2606445000.A60
2606445000
|
-
|
|
|
|
24 - COMPRESSION SPRING
BSD-1604616010.A43
1604616010
|
-
|
|
|
|
25 - COMPRESSION SPRING
BSD-1604619005.A71
1604619005
|
-
|
|
|
|
26 - SHIM
BSD-1600100607.A32
1600100607
|
-
|
|
|
|
27 - BUSHING
BSD-1600309004.A10
1600309004
|
-
|
|
|
|
28 - ROUND NUT
BSD-1603341000.A43
1603341000
|
-
|
|
|
|
29 - GUIDE SLEEVE
BSD-2600460001.A43
2600460001
|
-
|
|
|
|
30 - CARRIER 6 KT.. 6.3 MM
BSD-2606455002.A34
2606455002
|
-
|
|
|
|
31 - O-RING 8.0x1.5 MM
BSD-1900210103.A19
1900210103
|
£2.80
|
£3.36
|
|
|
32 - PRESSURE SPINDLE
BSD-1603120022.A70
1603120022
|
-
|
|
|
|
33 - COMPRESSION SPRING
BSD-1604626002.A37
1604626002
|
-
|
|
|
|
34 - TOOTHED SHAFT Z=11/34
BSD-2606100051.A11
2606100051
|
-
|
|
|
|
35 - SPINDLE WITH GEAR Z=18/35
BSD-2606100050.A2
2606100050
|
-
|
|
|
|
36 - SHIM 0.50 MM
BSD-2600100613.A258
2600100613
|
£1.75
|
£2.10
|
|
|
37 - SPRING LOCK WASHER
BSD-1600224011.A88
1600224011
|
-
|
|
|
|
38 - BALL DIN 5401-2.5MM-III-ST
BSD-1903230003.A505
1903230003
|
£2.61
|
£3.13
|
|
|
39 - NAMEPLATE
BSD-3601106053.A335
3601106053
|
£5.30
|
£6.36
|
|
|
40 - GROOVED NAIL
BSD-3603133000.A128
3603133000
|
£2.61
|
£3.13
|
|
|
41 - SPRING WASHER DIN 137-A5-ST
BSD-2916069006.A1
2916069006
|
-
|
|
|
|
42 - SPRING WASHER A 3 DIN 137-ST
BSD-2916060003.A238
2916060003
|
£1.32
|
£1.58
|
|
|
43 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A267
2916010409
|
-
|
|
|
|
44 - SPRING WASHER DIN 137-A4
BSD-1600150006.A83
1600150006
|
-
|
|
|
|
45 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A105
2910110116
|
£1.75
|
£2.10
|
|
|
46 - PAN HEAD SCREW DIN 85-AM3.5x15-4.8
BSD-2910091046.A144
2910091046
|
£1.75
|
£2.10
|
|
|
47 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A34
2910021116
|
£2.16
|
£2.59
|
|
|
48 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A21
2910141122
|
£2.16
|
£2.59
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A757
2910021122
|
£2.16
|
£2.59
|
|
|
50 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x22-8.8
BSD-2910141131.A21
2910141131
|
£2.16
|
£2.59
|
|
|
51 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x45-8.8
BSD-2910141140.A152
2910141140
|
£1.75
|
£2.10
|
|
|
52 - HEX SOCKET HEAD CAP SCREW
BSD-3603414001.A4
3603414001
|
-
|
|
|
|
53 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A120
2910011162
|
£1.75
|
£2.10
|
|
|
54 - SET SCREW
BSD-3603402000.A237
3603402000
|
£1.75
|
£2.10
|
|
|
69 - BUSHING
BSD-2600300058.A96
2600300058
|
-
|
|
|
|
71 - RETAINING WASHER
BSD-3600190012.A9
3600190012
|
-
|
|
|
|
72 - COUNTERSUNK-HEAD SCREW DIN 963-M3x8-8.8
BSD-2910780050.A96
2910780050
|
-
|
|
|
|
73 - O-RING 8.0x1.0 MM
BSD-1600210045.A159
1600210045
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1620
3601119236
|
£3.72
|
£4.47
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW 12
BSD-1907950506.A14
1907950506
|
£13.12
|
£15.75
|
|
|
652 - STRAIGHT PIN 4x60 MM
BSD-2603101035.A91
2603101035
|
£2.80
|
£3.36
|
|
|
800 - MOTOR HOUSING
BSD-3605102028.A32
3605102028
|
£156.22
|
£187.46
|
|
|
801 - CARRIER
BSD-3606455019.A10
3606455019
|
-
|
|
|
|
809 - BEARING HOUSING
BSD-1605820162.A46
1605820162
|
-
|
|
|
|
810 - STATOR 72V/200HZ.110V/300HZ
BSD-1604229202.A23
1604229202
|
£306.65
|
£367.98
|
|
