2 - STATOR
BSD-3604229132.A0
3604229132
|
£410.78
|
£492.94
|
|
|
2/20 - RECEPTACLE
BSD-3604478004.A2
3604478004
|
£5.30
|
£6.36
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-1604080032.A31
1604080032
|
£195.26
|
£234.31
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A255
1600209002
|
£5.30
|
£6.36
|
|
|
5 - SPINDLE BEARING
BSD-3605806112.A5
3605806112
|
£283.50
|
£340.20
|
|
|
6 - GRINDING SPINDLE M8. SW22
BSD-1603124035.A32
1603124035
|
£120.11
|
£144.13
|
|
|
8 - THREADED BUSHING M 32x1
BSD-1600362018.A34
1600362018
|
£68.42
|
£82.10
|
|
|
9 - O-RING 45x3MM
BSD-1900210146.A226
1900210146
|
£4.26
|
£5.11
|
|
|
10 - HANDLE
BSD-3605132079.A13
3605132079
|
£45.67
|
£54.80
|
|
|
11 - GROMMET dia12.8xdia13.5x100 MM
BSD-3600703003.A84
3600703003
|
£5.30
|
£6.36
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3604462018.A18
3604462018
|
£72.18
|
£86.62
|
|
|
14 - SWITCH
BSD-3607200055.A8
3607200055
|
£93.88
|
£112.65
|
|
|
15 - FASTENING CLAMP
BSD-3601303004.A168
3601303004
|
£5.58
|
£6.70
|
|
|
20 - PLAIN WASHER
BSD-1600102013.A4
1600102013
|
£3.72
|
£4.47
|
|
|
21 - COLLET dia 8. M 8. SW 14
BSD-2608570009.A4
2608570009
|
£40.80
|
£48.96
|
|
|
22 - CARRIER
BSD-1606442000.A47
1606442000
|
£5.58
|
£6.70
|
|
|
23 - CARRIER
BSD-1600320026.A54
1600320026
|
£48.38
|
£58.06
|
|
|
23/2 - STRAIGHT PIN 4 H 8x12 DIN 7
BSD-2917500095.A126
2917500095
|
£1.75
|
£2.10
|
|
|
24 - CYL. ROLLER BEARING I-82 006 M DIN 5412
BSD-3600905110.A47
3600905110
|
£45.67
|
£54.80
|
|
|
25 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A145
1900905121
|
£18.96
|
£22.75
|
|
|
26 - NAMEPLATE
BSD-3601106053.A1084
3601106053
|
£5.30
|
£6.36
|
|
|
27 - THREADED RING M30x1
BSD-1603344024.A29
1603344024
|
£23.86
|
£28.63
|
|
|
33 - CLAMPING SADDLE
BSD-3601321001.A116
3601321001
|
£3.72
|
£4.47
|
|
|
34 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A1140
2910211019
|
£1.75
|
£2.10
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x18-8.8
BSD-2910141160.A9
2910141160
|
£2.16
|
£2.59
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A162
2910141164
|
£2.16
|
£2.59
|
|
|
39 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A452
2910110120
|
£1.75
|
£2.10
|
|
|
41 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A204
3603133001
|
£2.61
|
£3.13
|
|
|
44 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A532
2910021118
|
£1.75
|
£2.10
|
|
|
48 - BEARING COVER
BSD-1600501019.A54
1600501019
|
£23.86
|
£28.63
|
|
|
52 - SCREW 4x16
BSD-2603490022.A1644
2603490022
|
£1.75
|
£2.10
|
|
|
54 - BEARING FLANGE
BSD-3605820064.A118
3605820064
|
£68.42
|
£82.10
|
|
|
55 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A237
1900905234
|
£31.64
|
£37.97
|
|
|
56 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A642
2910021125
|
£1.75
|
£2.10
|
|
|
57 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A19
3600905147
|
£13.12
|
£15.75
|
|
|
58 - O-RING 22x2 MM
BSD-1900210321.A40
1900210321
|
£5.30
|
£6.36
|
|
|
68 - SEALING PLATE
BSD-3600054006.A3
3600054006
|
£3.72
|
£4.47
|
|
|
88 - SPRING WASHER dia4.2 MM
BSD-3600150006.A66
3600150006
|
£2.61
|
£3.13
|
|
|
90 - STRIP TERMINAL
BSD-1901091110.A89
1901091110
|
£1.75
|
£2.10
|
|
|
91 - SEAL RING
BSD-1600209004.A133
1600209004
|
£2.80
|
£3.36
|
|
|
94 - SET SCREW
BSD-1603402002.A258
1603402002
|
£1.75
|
£2.10
|
|
|
95 - SET SCREW
BSD-1603402004.A203
1603402004
|
£2.61
|
£3.13
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A100
3601110047
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A264
3601119236
|
£3.72
|
£4.47
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A8
1907950508
|
£14.91
|
£17.89
|
|
|
652 - SINGLE-HEAD ENG. WRENCH SW22
BSD-1607950505.A5
1607950505
|
£16.41
|
£19.69
|
|
|
700 - COLLET dia 10. M8. SW 14
BSD-2608570017.A14
2608570017
|
£41.62
|
£49.95
|
|
|
701 - COLLET dia 1/4. M 8. SW 14
BSD-2608570014.A21
2608570014
|
£37.27
|
£44.72
|
|
|
702 - COLLET dia 6. M8. SW14
BSD-2608570018.A3
2608570018
|
£48.38
|
£58.06
|
|
|
802 - MOTOR HOUSING
BSD-3605102079.A7
3605102079
|
£179.37
|
£215.24
|
|
|
824 - CYL. ROLLER BEARING
BSD-3600905111.A1
3600905111
|
£68.42
|
£82.10
|
|
|
835 - HANDLE
BSD-3607031870.A10
3607031870
|
-
|
|
|
