1 - MOTOR HOUSING
BSD-3605102081.A27
3605102081
|
£156.22
|
£187.46
|
|
|
2 - STATOR 265V/200HZ.230V/180HZ
BSD-1604229098.A6
1604229098
|
£357.27
|
£428.72
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-1604080032.A11
1604080032
|
£195.26
|
£234.31
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A273
1600209002
|
£5.30
|
£6.36
|
|
|
5 - SPINDLE BEARING
BSD-3605806140.A14
3605806140
|
£352.76
|
£423.31
|
|
|
6 - GRINDING SPINDLE
BSD-3603050013.A6
3603050013
|
£195.26
|
£234.31
|
|
|
7 - INTERMEDIATE RING
BSD-1600200009.A29
1600200009
|
£6.52
|
£7.83
|
|
|
9 - O-RING 54.0x3.0 MM
BSD-1600210004.A114
1600210004
|
£2.80
|
£3.36
|
|
|
10 - HANDLE
BSD-3605132024.A35
3605132024
|
£27.23
|
£32.68
|
|
|
11 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A228
1600703009
|
£5.58
|
£6.70
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A149
3607030236
|
£61.98
|
£74.38
|
|
|
13 - SEALING PLATE
BSD-1600113003.A308
1600113003
|
£2.80
|
£3.36
|
|
|
14 - SWITCH
BSD-1607200020.A34
1607200020
|
-
|
|
|
|
15 - FASTENING CLAMP
BSD-1601303003.A85
1601303003
|
£2.16
|
£2.59
|
|
|
16 - SPRING RETAINING RING DIN 471 17x1 MM
BSD-2916650008.A250
2916650008
|
£1.75
|
£2.10
|
|
|
17 - CONTROL LEVER
BSD-1602026030.A407
1602026030
|
£10.10
|
£12.12
|
|
|
17/8 - FELT WASHER
BSD-1600205008.A380
1600205008
|
£1.75
|
£2.10
|
|
|
24 - GROOVE BALL BEARING
BSD-3600905058.A41
3600905058
|
£21.52
|
£25.83
|
|
|
26 - NAMEPLATE
BSD-3601106053.A1064
3601106053
|
£5.30
|
£6.36
|
|
|
27 - GROOVE BALL BEARING
BSD-3600905060.A93
3600905060
|
£21.52
|
£25.83
|
|
|
28 - O-RING 35.0x2.0 MM
BSD-2600210026.A8
2600210026
|
£2.16
|
£2.59
|
|
|
29 - CYLINDRICAL GEAR Z=28
BSD-1606319007.A11
1606319007
|
£93.88
|
£112.65
|
|
|
30 - SHIM WASHER 0.4 MM
BSD-1600101600.A17
1600101600
|
£1.75
|
£2.10
|
|
|
31 - COVER DISC
BSD-1600101016.A45
1600101016
|
£5.30
|
£6.36
|
|
|
32 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A412
2910211006
|
£1.75
|
£2.10
|
|
|
33 - CLAMPING SADDLE
BSD-3601321001.A109
3601321001
|
£3.72
|
£4.47
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A546
2910021118
|
£1.75
|
£2.10
|
|
|
35 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A210
2910091118
|
£1.75
|
£2.10
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A20
2910141166
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW
BSD-3603450008.A146
3603450008
|
£2.16
|
£2.59
|
|
|
39 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A463
2910110120
|
£1.75
|
£2.10
|
|
|
40 - SHIM 0.2 MM
BSD-1600100632.A255
1600100632
|
£1.75
|
£2.10
|
|
|
41 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A187
3603133001
|
£2.61
|
£3.13
|
|
|
42 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A254
2916011005
|
£1.75
|
£2.10
|
|
|
43 - FELT DISC
BSD-1600108018.A329
1600108018
|
£2.61
|
£3.13
|
|
|
44 - SPRING WASHER dia4.2 MM
BSD-3600150006.A103
3600150006
|
£2.61
|
£3.13
|
|
|
45 - SHIM
BSD-1600101625.A8
1600101625
|
£3.72
|
£4.47
|
|
|
46 - SHIM 0.10 MM
BSD-1420100023.A301
1420100023
|
-
|
|
|
|
47 - COVER DISC
BSD-1600501024.A327
1600501024
|
£16.41
|
£19.69
|
|
|
48 - BEARING COVER
BSD-1600501019.A76
1600501019
|
£23.86
|
£28.63
|
|
|
54 - BEARING FLANGE
BSD-3605820002.A12
3605820002
|
£68.42
|
£82.10
|
|
|
55 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A230
1900905234
|
£31.64
|
£37.97
|
|
|
56 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A98
3603435051
|
£1.75
|
£2.10
|
|
|
57 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A31
3600905147
|
£13.12
|
£15.75
|
|
|
58 - O-RING 22x2 MM
BSD-1900210321.A50
1900210321
|
£5.30
|
£6.36
|
|
|
60 - SEALING CORD
BSD-1601014000.A334
1601014000
|
£2.80
|
£3.36
|
|
|
67 - SEALING PLATE
BSD-1602388006.A114
1602388006
|
£5.58
|
£6.70
|
|
|
68 - GROMMET
BSD-1600306001.A22
1600306001
|
£2.61
|
£3.13
|
|
|
69 - CYLINDRICAL GEAR Z=21
BSD-1606302001.A5
1606302001
|
£179.37
|
£215.24
|
|
|
70 - PROTECTIVE RING
BSD-3600222004.A6
3600222004
|
£27.23
|
£32.68
|
|
|
71 - SPACER RING
BSD-3600200057.A29
3600200057
|
£27.23
|
£32.68
|
|
|
72 - SHIM
BSD-3600150019.A6
3600150019
|
£2.16
|
£2.59
|
|
|
73 - SPRING RETAINING RING DIN472-35x1.5
BSD-2916669114.A6
2916669114
|
£2.16
|
£2.59
|
|
|
74 - SPACER RING
BSD-3600202015.A6
3600202015
|
£21.68
|
£26.01
|
|
|
75 - O-RING 32.0x1.5 MM
BSD-3600210057.A52
3600210057
|
£2.61
|
£3.13
|
|
|
76 - RETAINING RING 24x2 DIN9045-24
BSD-2916609112.A50
2916609112
|
£2.61
|
£3.13
|
|
|
88 - SPRING WASHER dia4.2 MM
BSD-3600150006.A102
3600150006
|
£2.61
|
£3.13
|
|
|
89 - END SPLICE
BSD-3604477008.A283
3604477008
|
£1.75
|
£2.10
|
|
|
91 - SEAL RING
BSD-1600209004.A113
1600209004
|
£2.80
|
£3.36
|
|
|
93 - PLAIN WASHER
BSD-1600101002.A54
1600101002
|
£13.12
|
£15.75
|
|
|
94 - SET SCREW
BSD-1603402002.A236
1603402002
|
£1.75
|
£2.10
|
|
|
95 - SET SCREW
BSD-1603402004.A216
1603402004
|
£2.61
|
£3.13
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A113
3601110047
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A243
3601119236
|
£3.72
|
£4.47
|
|
|
101 - SHIM 0.05 MM
BSD-1600100601.A9
1600100601
|
-
|
|
|
|
650 - PIN-TYPE FACE-WRENCH
BSD-2607950022.A58
2607950022
|
£31.64
|
£37.97
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW32
BSD-2607950021.A11
2607950021
|
£27.23
|
£32.68
|
|
|
700/10 - CLAMPING-FLANGE
BSD-3605703089.A82
3605703089
|
£63.50
|
£76.20
|
|
|
700/20 - CLAMPING RING
BSD-3605703074.A11
3605703074
|
£21.68
|
£26.01
|
|
|
700/40 - PROTECTIVE COVER dia100 MM
BSD-3605510032.A16
3605510032
|
£179.37
|
£215.24
|
|
|
701/701 - CLAMPING-FLANGE
BSD-3605703070.A5
3605703070
|
£93.88
|
£112.65
|
|
|
701/702 - CLAMPING RING
BSD-3605703066.A5
3605703066
|
-
|
|
|
|
703 - ACCESSORY SET
BSD-3607000036.A11
3607000036
|
£54.42
|
£65.30
|
|
|
800 - SWITCH KIT
BSD-1607000036.A44
1607000036
|
-
|
|
|
|
801 - SEALING PLATE
BSD-1602388007.A75
1602388007
|
£12.04
|
£14.45
|
|
|
802 - MOTOR HOUSING
BSD-3605102079.A25
3605102079
|
£179.37
|
£215.24
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031221.A7
3607031221
|
£522.92
|
£627.51
|
|
|
805 - HANDLE
BSD-3605132048.A331
3605132048
|
£63.50
|
£76.20
|
|
