1 - MOTOR HOUSING
BSD-3605102081.A49
3605102081
|
£156.22
|
£187.46
|
|
|
2 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229099.A49
1604229099
|
£410.78
|
£492.94
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-1604080038.A2
1604080038
|
£500.46
|
£600.55
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A235
1600209002
|
£5.30
|
£6.36
|
|
|
5/1 - SPINDLE BEARING
BSD-3605806141.A1
3605806141
|
£306.65
|
£367.98
|
|
|
5/2 - SPINDLE BEARING
BSD-3605806140.A6
3605806140
|
£352.76
|
£423.31
|
|
|
6 - GRINDING SPINDLE
BSD-3603050013.A20
3603050013
|
£195.26
|
£234.31
|
|
|
6/1 - ARMATURE SHAFT
BSD-1603050012.A24
1603050012
|
-
|
|
|
|
7 - INTERMEDIATE RING
BSD-1600200009.A43
1600200009
|
£6.52
|
£7.83
|
|
|
8 - THREADED RING
BSD-1603344002.A23
1603344002
|
-
|
|
|
|
9 - O-RING 54.0x3.0 MM
BSD-1600210004.A98
1600210004
|
£2.80
|
£3.36
|
|
|
10 - HANDLE
BSD-3605132024.A24
3605132024
|
£27.23
|
£32.68
|
|
|
11 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A215
1600703009
|
£5.58
|
£6.70
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A162
3607030236
|
£61.98
|
£74.38
|
|
|
13 - SEALING PLATE
BSD-1600113003.A294
1600113003
|
£2.80
|
£3.36
|
|
|
14 - SWITCH
BSD-1607200020.A26
1607200020
|
-
|
|
|
|
15 - FASTENING CLAMP
BSD-1601303003.A94
1601303003
|
£2.16
|
£2.59
|
|
|
16 - SPRING RETAINING RING DIN 471 20x1.2
BSD-2916650011.A50
2916650011
|
£2.16
|
£2.59
|
|
|
17 - CONTROL LEVER
BSD-1602026030.A403
1602026030
|
£10.10
|
£12.12
|
|
|
17/8 - FELT WASHER
BSD-1600205008.A374
1600205008
|
£1.75
|
£2.10
|
|
|
20 - CLAMPING-FLANGE dia 125 MM
BSD-1605703021.A1
1605703021
|
-
|
|
|
|
21 - ROUND NUT dia 125 MM
BSD-1603345018.A2
1603345018
|
-
|
|
|
|
24 - GROOVE BALL BEARING 15x42x13
BSD-1900900351.A21
1900900351
|
£24.45
|
£29.34
|
|
|
24/1 - GROOVE BALL BEARING
BSD-3600905058.A26
3600905058
|
£21.52
|
£25.83
|
|
|
26 - NAMEPLATE
BSD-3601106053.A1061
3601106053
|
£5.30
|
£6.36
|
|
|
27 - GROOVE BALL BEARING 15x32x9
BSD-1900905162.A76
1900905162
|
£18.96
|
£22.75
|
|
|
27/1 - GROOVE BALL BEARING
BSD-3600905060.A107
3600905060
|
£21.52
|
£25.83
|
|
|
28/1 - O-RING 35.0x2.0 MM
BSD-2600210026.A20
2600210026
|
£2.16
|
£2.59
|
|
|
29 - CYLINDRICAL GEAR Z=29
BSD-1606320028.A22
1606320028
|
£72.18
|
£86.62
|
|
|
30 - SHIM WASHER 0.4 MM
BSD-1600101600.A6
1600101600
|
£1.75
|
£2.10
|
|
|
31 - COVER DISC
BSD-1600101016.A56
1600101016
|
£5.30
|
£6.36
|
|
|
32 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A422
2910211006
|
£1.75
|
£2.10
|
|
|
33 - PLAIN WASHER DIN 46 255-DPG 9
BSD-2916010409.A175
2916010409
|
-
|
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A568
2910021118
|
£1.75
|
£2.10
|
|
|
35 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A217
2910091118
|
£1.75
|
£2.10
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A42
2910141166
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW
BSD-3603450008.A166
3603450008
|
£2.16
|
£2.59
|
|
|
39 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A475
2910110120
|
£1.75
|
£2.10
|
|
|
40 - SHIM 0.2 MM
BSD-1600100632.A260
1600100632
|
£1.75
|
£2.10
|
|
|
41 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A156
3603133001
|
£2.61
|
£3.13
|
|
|
42 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A237
2916011005
|
£1.75
|
£2.10
|
|
|
43 - FELT DISC
BSD-1600108018.A323
1600108018
|
£2.61
|
£3.13
|
|
|
44 - SPRING WASHER dia4.2 MM
BSD-3600150006.A57
3600150006
|
£2.61
|
£3.13
|
|
|
46 - SHIM 0.10 MM
BSD-1420100023.A306
1420100023
|
-
|
|
|
|
47 - COVER DISC
BSD-1600501024.A343
1600501024
|
£16.41
|
£19.69
|
|
|
48 - BEARING COVER
BSD-1600501019.A40
1600501019
|
£23.86
|
£28.63
|
|
|
49 - THREADED RING
BSD-1603344031.A0
1603344031
|
£59.53
|
£71.44
|
|
|
54 - BEARING FLANGE
BSD-1605820100.A2
1605820100
|
-
|
|
|
|
55 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A219
1900905234
|
£31.64
|
£37.97
|
|
|
56 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A89
3603435051
|
£1.75
|
£2.10
|
|
|
57 - BALL BEARING 7x22x7
BSD-1900905018.A73
1900905018
|
£18.96
|
£22.75
|
|
|
60 - SEALING CORD
BSD-1601014000.A346
1601014000
|
£2.80
|
£3.36
|
|
|
67 - SEALING PLATE
BSD-1602388006.A132
1602388006
|
£5.58
|
£6.70
|
|
|
68 - GROMMET
BSD-1600306001.A6
1600306001
|
£2.61
|
£3.13
|
|
|
70 - PROTECTIVE RING
BSD-3600222005.A3
3600222005
|
£31.64
|
£37.97
|
|
|
71 - SPACER RING
BSD-3600200021.A0
3600200021
|
£33.74
|
£40.49
|
|
|
72 - SHIM
BSD-3600150008.A2
3600150008
|
£2.61
|
£3.13
|
|
|
73 - SPRING RETAINING RING DIN 472-47x1.75
BSD-2916669021.A3
2916669021
|
-
|
|
|
|
74 - SPACER RING
BSD-3600202014.A3
3600202014
|
£21.68
|
£26.01
|
|
|
75 - O-RING 43.0x2.0 MM
BSD-3600210058.A26
3600210058
|
£1.75
|
£2.10
|
|
|
89 - END SPLICE
BSD-3604477008.A302
3604477008
|
£1.75
|
£2.10
|
|
|
91 - SEAL RING
BSD-1600209004.A152
1600209004
|
£2.80
|
£3.36
|
|
|
92 - RETAINING RING 35 DIN 9045
BSD-2916600018.A84
2916600018
|
£1.75
|
£2.10
|
|
|
93 - PLAIN WASHER
BSD-1600101002.A43
1600101002
|
£13.12
|
£15.75
|
|
|
94 - SET SCREW
BSD-1603402002.A221
1603402002
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A242
3601119236
|
£3.72
|
£4.47
|
|
|
101 - SHIM 0.05 MM
BSD-1600100601.A4
1600100601
|
-
|
|
|
|
651 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A628
1607950061
|
£5.42
|
£6.50
|
|
|
652 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A181
1907950007
|
£5.30
|
£6.36
|
|
|
702/1 - PROTECTIVE COVER dia 125 MM
BSD-3605510030.A0
3605510030
|
£27.23
|
£32.68
|
|
|
702/10 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A2
2910141244
|
£1.75
|
£2.10
|
|
|
702/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A188
2910141242
|
£1.75
|
£2.10
|
|
|
800 - SWITCH KIT
BSD-1607000036.A29
1607000036
|
-
|
|
|
|
801 - SEALING PLATE
BSD-1602388007.A57
1602388007
|
£12.04
|
£14.45
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031222.A2
3607031222
|
£1006.71
|
£1208.05
|
|
|
805 - HANDLE
BSD-3605132048.A325
3605132048
|
£63.50
|
£76.20
|
|
