1 - MOTOR HOUSING
BSD-3605102081.A53
3605102081
|
£156.22
|
£187.46
|
|
|
2 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229099.A47
1604229099
|
£410.78
|
£492.94
|
|
|
3 - ROTOR WITHOUT WINDING
BSD-1604080038.A6
1604080038
|
£500.46
|
£600.55
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A242
1600209002
|
£5.30
|
£6.36
|
|
|
5 - SPINDLE BEARING
BSD-3605806141.A5
3605806141
|
£306.65
|
£367.98
|
|
|
6 - GRINDING SPINDLE
BSD-3603050014.A0
3603050014
|
£135.25
|
£162.30
|
|
|
7 - INTERMEDIATE RING
BSD-1600200009.A35
1600200009
|
£6.52
|
£7.83
|
|
|
9 - O-RING 54.0x3.0 MM
BSD-1600210004.A97
1600210004
|
£2.80
|
£3.36
|
|
|
10 - HANDLE
BSD-3605132024.A22
3605132024
|
£27.23
|
£32.68
|
|
|
11 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A214
1600703009
|
£5.58
|
£6.70
|
|
|
12 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A164
3607030236
|
£61.98
|
£74.38
|
|
|
13 - SEALING PLATE
BSD-1600113003.A290
1600113003
|
£2.80
|
£3.36
|
|
|
14 - SWITCH
BSD-1607200020.A25
1607200020
|
-
|
|
|
|
15 - FASTENING CLAMP
BSD-1601303003.A92
1601303003
|
£2.16
|
£2.59
|
|
|
16 - SPRING RETAINING RING DIN 471 20x1.2
BSD-2916650011.A54
2916650011
|
£2.16
|
£2.59
|
|
|
17 - CONTROL LEVER
BSD-1602026030.A404
1602026030
|
£10.10
|
£12.12
|
|
|
17/8 - FELT WASHER
BSD-1600205008.A377
1600205008
|
£1.75
|
£2.10
|
|
|
24 - GROOVE BALL BEARING
BSD-3600905057.A48
3600905057
|
£21.68
|
£26.01
|
|
|
26 - NAMEPLATE
BSD-3601106053.A1054
3601106053
|
£5.30
|
£6.36
|
|
|
27 - GROOVE BALL BEARING
BSD-3600905060.A117
3600905060
|
£21.52
|
£25.83
|
|
|
28 - O-RING 35.0x2.0 MM
BSD-2600210026.A27
2600210026
|
£2.16
|
£2.59
|
|
|
29 - CYLINDRICAL GEAR Z=29
BSD-1606320028.A25
1606320028
|
£72.18
|
£86.62
|
|
|
30 - SHIM WASHER 0.4 MM
BSD-1600101600.A2
1600101600
|
£1.75
|
£2.10
|
|
|
31 - COVER DISC
BSD-1600101016.A60
1600101016
|
£5.30
|
£6.36
|
|
|
32 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A421
2910211006
|
£1.75
|
£2.10
|
|
|
33 - CLAMPING SADDLE
BSD-3601321001.A90
3601321001
|
£3.72
|
£4.47
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A560
2910021118
|
£1.75
|
£2.10
|
|
|
35 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A214
2910091118
|
£1.75
|
£2.10
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A46
2910141166
|
£1.75
|
£2.10
|
|
|
37 - SOCKET HEAD CAP SCREW
BSD-3603450008.A168
3603450008
|
£2.16
|
£2.59
|
|
|
39 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A482
2910110120
|
£1.75
|
£2.10
|
|
|
40 - SHIM 0.2 MM
BSD-1600100632.A262
1600100632
|
£1.75
|
£2.10
|
|
|
41 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A146
3603133001
|
£2.61
|
£3.13
|
|
|
42 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A242
2916011005
|
£1.75
|
£2.10
|
|
|
43 - FELT DISC
BSD-1600108018.A316
1600108018
|
£2.61
|
£3.13
|
|
|
44 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A241
2916011005
|
£1.75
|
£2.10
|
|
|
46 - SHIM 0.10 MM
BSD-1420100023.A308
1420100023
|
-
|
|
|
|
47 - COVER DISC
BSD-1600501024.A344
1600501024
|
£16.41
|
£19.69
|
|
|
48 - BEARING COVER
BSD-1600501019.A39
1600501019
|
£23.86
|
£28.63
|
|
|
49 - THREADED RING
BSD-1603344031.A6
1603344031
|
£59.53
|
£71.44
|
|
|
54 - BEARING FLANGE
BSD-3605820002.A14
3605820002
|
£68.42
|
£82.10
|
|
|
55 - GROOVE BALL BEARING 15x35x11
BSD-1900905234.A210
1900905234
|
£31.64
|
£37.97
|
|
|
56 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A84
3603435051
|
£1.75
|
£2.10
|
|
|
57 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A2
3600905147
|
£13.12
|
£15.75
|
|
|
58 - O-RING 22x2 MM
BSD-1900210321.A57
1900210321
|
£5.30
|
£6.36
|
|
|
60 - SEALING CORD
BSD-1601014000.A347
1601014000
|
£2.80
|
£3.36
|
|
|
67 - SEALING PLATE
BSD-1602388006.A137
1602388006
|
£5.58
|
£6.70
|
|
|
68 - GROMMET
BSD-1600306001.A0
1600306001
|
£2.61
|
£3.13
|
|
|
70 - PROTECTIVE RING
BSD-3600222005.A4
3600222005
|
£31.64
|
£37.97
|
|
|
71 - SPACER RING
BSD-3600200021.A6
3600200021
|
£33.74
|
£40.49
|
|
|
72 - SHIM
BSD-3600150008.A3
3600150008
|
£2.61
|
£3.13
|
|
|
73 - SPRING RETAINING RING
BSD-3603435038.A49
3603435038
|
£2.61
|
£3.13
|
|
|
74 - SPACER RING
BSD-3600202014.A4
3600202014
|
£21.68
|
£26.01
|
|
|
75 - O-RING 43.0x2.0 MM
BSD-3600210058.A36
3600210058
|
£1.75
|
£2.10
|
|
|
88 - SPRING WASHER dia4.2 MM
BSD-3600150006.A52
3600150006
|
£2.61
|
£3.13
|
|
|
89 - END SPLICE
BSD-3604477008.A307
3604477008
|
£1.75
|
£2.10
|
|
|
91 - SEAL RING
BSD-1600209004.A144
1600209004
|
£2.80
|
£3.36
|
|
|
93 - PLAIN WASHER
BSD-1600101002.A37
1600101002
|
£13.12
|
£15.75
|
|
|
94 - SET SCREW
BSD-1603402002.A227
1603402002
|
£1.75
|
£2.10
|
|
|
95 - SET SCREW
BSD-1603402004.A219
1603402004
|
£2.61
|
£3.13
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A118
3601110047
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A234
3601119236
|
£3.72
|
£4.47
|
|
|
101 - SHIM 0.05 MM
BSD-1600100601.A3
1600100601
|
-
|
|
|
|
650 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A630
1607950061
|
£5.42
|
£6.50
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW32
BSD-3607950010.A8
3607950010
|
£27.23
|
£32.68
|
|
|
655 - PROTECTIVE COVER dia 125 MM
BSD-3605510030.A5
3605510030
|
£27.23
|
£32.68
|
|
|
656 - CLAMPING-FLANGE
BSD-3605703112.A2
3605703112
|
£48.38
|
£58.06
|
|
|
657 - CLAMPING RING
BSD-3605703077.A23
3605703077
|
£37.27
|
£44.72
|
|
|
800 - SWITCH KIT
BSD-1607000036.A25
1607000036
|
-
|
|
|
|
801 - SEALING PLATE
BSD-1602388007.A53
1602388007
|
£12.04
|
£14.45
|
|
|
802 - MOTOR HOUSING
BSD-3605102079.A0
3605102079
|
£179.37
|
£215.24
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607031222.A4
3607031222
|
£1006.71
|
£1208.05
|
|
|
805 - HANDLE
BSD-3605132048.A322
3605132048
|
£63.50
|
£76.20
|
|
|
811 - FASTENING PARTS KIT
BSD-3607031290.A48
3607031290
|
£120.11
|
£144.13
|
|
