2 - STATOR 200V/300HZ
BSD-3604229059.A3
3604229059
|
-
|
|
|
|
3/8 - GROOVE BALL BEARING 12x32x10
BSD-3600905119.A25
3600905119
|
£27.23
|
£32.68
|
|
|
4 - AIR-DEFLECTOR RING
BSD-3600209008.A28
3600209008
|
£8.67
|
£10.41
|
|
|
6 - GROOVE BALL BEARING
BSD-3600905095.A301
3600905095
|
£21.52
|
£25.83
|
|
|
7 - BEARING FLANGE
BSD-3605805009.A246
3605805009
|
£59.53
|
£71.44
|
|
|
14 - THREADED RING
BSD-3603344024.A113
3603344024
|
£16.41
|
£19.69
|
|
|
15 - O-RING 38.1x2.2 MM
BSD-1600210037.A269
1600210037
|
£2.61
|
£3.13
|
|
|
20 - THREAD-FORMING TAP. SCREW
BSD-2914451079.A122
2914451079
|
£2.61
|
£3.13
|
|
|
21 - THREAD-FORMING TAP. SCREW AM 6x80-ST
BSD-3603410007.A14
3603410007
|
£3.72
|
£4.47
|
|
|
23 - COMPRESSION SPRING
BSD-3604611019.A125
3604611019
|
£2.61
|
£3.13
|
|
|
27 - SEALING DISC
BSD-3600100049.A29
3600100049
|
£3.72
|
£4.47
|
|
|
28 - SEALING DISC
BSD-3600100048.A249
3600100048
|
£2.80
|
£3.36
|
|
|
60 - ELEC. CABLE W/CONNECTION
BSD-3604462017.A250
3604462017
|
£54.42
|
£65.30
|
|
|
61 - TAPPING SCREW BZ4.8x63 MM
BSD-1603435008.A120
1603435008
|
£1.32
|
£1.58
|
|
|
62 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A197
2910211220
|
-
|
|
|
|
63 - CABLE ROUTING
BSD-1602388027.A384
1602388027
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303002.A104
3601303002
|
£2.61
|
£3.13
|
|
|
64 - FASTENING CLAMP
BSD-3601303004.A40
3601303004
|
£5.58
|
£6.70
|
|
|
65 - STORAGE LEDGE
BSD-1602388029.A205
1602388029
|
£1.75
|
£2.10
|
|
|
94 - SET SCREW DIN 915-M4x6-45H
BSD-2912081116.A176
2912081116
|
£2.61
|
£3.13
|
|
|
95 - NAMEPLATE
BSD-3601106053.A679
3601106053
|
£5.30
|
£6.36
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A170
3601110047
|
£2.80
|
£3.36
|
|
|
97 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A35
3603133001
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A621
3601119236
|
£3.72
|
£4.47
|
|
|
102 - SPINDLE HOUSING
BSD-3605806079.A6
3605806079
|
£195.26
|
£234.31
|
|
|
103 - GRINDING SPINDLE
BSD-3603523006.A3
3603523006
|
-
|
|
|
|
105 - GROOVE BALL BEARING
BSD-3600905060.A34
3600905060
|
£21.52
|
£25.83
|
|
|
106 - GROOVE BALL BEARING 15x28x7MM
BSD-3600905067.A6
3600905067
|
£23.86
|
£28.63
|
|
|
108 - PINION Z=21
BSD-3606300074.A24
3606300074
|
£72.18
|
£86.62
|
|
|
109 - CLUTCH ELEMENT Z=21
BSD-3606491000.A8
3606491000
|
£6.52
|
£7.83
|
|
|
110 - SPACER SLEEVE
BSD-3600700057.A10
3600700057
|
£45.67
|
£54.80
|
|
|
112 - O-RING 26.0x1.0 MM
BSD-3600210056.A17
3600210056
|
£1.75
|
£2.10
|
|
|
114 - THREADED RING
BSD-3603344024.A111
3603344024
|
£16.41
|
£19.69
|
|
|
115 - O-RING 33.0x2.5 MM
BSD-3600210050.A76
3600210050
|
£2.61
|
£3.13
|
|
|
650 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A33
1907950508
|
£14.91
|
£17.89
|
|
|
651 - SINGLE-HEAD ENG. WRENCH SW22
BSD-1607950505.A59
1607950505
|
£16.41
|
£19.69
|
|
|
700 - COLLET dia 10. M8. SW14
BSD-1608570040.A7
1608570040
|
£37.58
|
£45.10
|
|
|
701 - COLLET dia 8. M8. SW14
BSD-1608570041.A6
1608570041
|
£37.31
|
£44.77
|
|
|
702 - COLLET dia 1/4. M 8. SW 14
BSD-2608570014.A28
2608570014
|
£37.27
|
£44.72
|
|
|
703 - COLLET dia 6. M8. SW14
BSD-1608570043.A6
1608570043
|
£39.41
|
£47.29
|
|
|
801 - MOTOR HOUSING GR.83
BSD-3605108158.A12
3605108158
|
-
|
|
|
|
802 - STATOR 200V/300HZ
BSD-3607031273.A5
3607031273
|
-
|
|
|
|
803 - ROTOR
BSD-3604080027.A2
3604080027
|
-
|
|
|
|
810 - BEARING FLANGE
BSD-3607020109.A28
3607020109
|
£283.50
|
£340.20
|
|
|
810/077 - SET OF EARTLING MATERIAL
BSD-3607031299.A3
3607031299
|
£8.67
|
£10.41
|
|
|
811 - FASTENING PARTS KIT
BSD-3607031287.A5
3607031287
|
£135.25
|
£162.30
|
|
|
823 - SPRING SET
BSD-3607031296.A274
3607031296
|
£16.41
|
£19.69
|
|
|
856 - SWITCH KIT
BSD-3607031298.A152
3607031298
|
£81.81
|
£98.17
|
|
|
858 - HANDLE
BSD-3607031297.A3
3607031297
|
£37.27
|
£44.72
|
|
|
859 - GROMMET
BSD-3607031550.A136
3607031550
|
£13.12
|
£15.75
|
|
